JK-Products ergoline PASSION 40/3 TURBO POWER Operating Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
PA S S I O N 4 0 / 3 T U R B O P O W E R
15 min
O P E R AT I N G I N S T R U C T I O N S

Advertisement

loading
Need help?

Need help?

Do you have a question about the ergoline PASSION 40/3 TURBO POWER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JK-Products ergoline PASSION 40/3 TURBO POWER

Summary of Contents for JK-Products ergoline PASSION 40/3 TURBO POWER

  • Page 1 PA S S I O N 4 0 / 3 T U R B O P O W E R 15 min O P E R AT I N G I N S T R U C T I O N S...
  • Page 2 Operating Instructions (Part II) PASSION 40/3 TURBO POWER 1006351-01 / us / 09.2009...
  • Page 3 See also Operating Instructions Part I: Contents 1 General 2 Information for the studio operator 3 Operation 4 Cleaning and maintenance 5 JK-Products, Inc. – Limited Warranty 6 Appendix WARNING! AVERTISSEMENT! Read these Veuillez lire les présentes operating instructions.
  • Page 4 Important information on tanning Table of contents Important information on tanning ............4 1.1 Skin types ....................4 1.2 Tanning times ..................4 General ....................5 2.1 Definitions....................5 2.2 Identify your tanning device..............5 Safety notices ..................6 3.1 Description of warning signs..............6 3.2 Instructions pertaining to a risk of fire, electric shock, or injury ....
  • Page 5 General Important information on tanning Skin types Skin type I (Sensitive): Invariably gets sunburn, accepts little natural sunlight and does not tan. Skin type II (Fair): This is the individual that usually burns easily and severely, tans minimally or lightly and peels. Skin type III (Average): Often referred to as “Average”...
  • Page 6 Important information on tanning General Definitions (Studio) operator People who provide tanning devices to users on a commercial basis. The operator is responsible for the orderly operation of the device as well as the compliance with the maintenance intervals. User A person who uses the tanning device at a commercial location.
  • Page 7 Safety notices Safety notices Description of warning signs Danger notices, damage to persons: DANGER! DANGER! Type and source of danger, Type et source de danger, par ex e.g. “DANGER – High voltage!” “DANGER – haute tension !” DANGER! / DANGER! Description of the consequences, e.g.
  • Page 8 Safety notices Caution notices, damage to property: CAUTION! ATTENTION! CAUTION! / ATTENTION! The word “Caution” with this label points out that danger for devices, materials and the environment can be expected here. Le mot "ATTENTION" sur cette étiquette indique un danger potentiel pour les équipements, le matériel et l'environnement.
  • Page 9 Safety notices Instructions pertaining to a risk of fire, electric shock, or injury DANGER – HIGH VOLTAGE! DANGER – HAUTE TENSION ! You can be killed or injured Danger de mort ou de blessures by an electric shock! des suites d'un choc électrique! DANGER! / DANGER! Assembly and electrical connection must comply with national and local regulations.
  • Page 10 Safety notices WARNING! - AVERTISSEMENT! - ULTRAVIOLET RADIATION! RAYONS ULTRAVIOLETS ! WARNING! / AVERTISSEMENT! Follow Instructions Respecter les instructions. Failure to use protective eyewear may result in severe burns or other eye injury. If discomfort develops, discontinue use and consult a physician. –...
  • Page 11 Safety notices – Comme avec les rayons du soleil, une surexposition peut causer des dommages des yeux et de la peau, ainsi que des allergies. – Une exposition répétée peut entraîner un vieillissement anticipé et un cancer de la peau. –...
  • Page 12 Safety notices For hygienic and proper cleaning, use a specially developed disinfectant cleaner. Après chaque séance de bronzage, tous les éléments et composants avec lesquels l’utilisateur peut entrer en contact pendant la séance de bronzage, doive nt être désinfectés : les lunettes de Protection •...
  • Page 13 Safety notices – L’intensification du bronzage nécessite l’allongement de la durée d’exposition (c’est-à-dire de la durée de radiation) ; après avoir atteint un certain degré de bronzage, toute intensification devient impossible. Toutefois la durée d'exposition au rayonnement ne doit pas être prolongée sans considération à...
  • Page 14 Description Description Device description PASSION 40/3 TURBO POWER 1. Facial tanner (3 UV high-pressure lamps) 2. UV low-pressure lamps, base 3. Operating panel 4. Intermediate panel (only sunbeds with air condition) 5. Acrylic cover, base 6. Adjustable air nozzles face cooling 7.
  • Page 15 Description Accessories (optional) 11 12 11855 / 0  A udio system (Stereo Sound System PLUS or Stereo Sound System) 12. Headphone connection (only with Stereo Sound System PLUS) 13. MP3 connection (only with Stereo Sound System PLUS) Function description The primary technical components of a tanning device are an artificial source of UV radiation, a variety of filters and reflectors as well as a mechanical structure with a defined active surface.
  • Page 16 Operation Operation Operation overview 5.1.1 Navigation The device is operated with the navigation ring. Switch on UV lamps: – Press the button once. Switch off UV lamps/pause tanning: – Hold the button down. Select device function (go to pictogram) e.g. MUSIC Adjust the intensity/setting of the function selected.
  • Page 17 Operation Start The device is started automatically with an internal or external timer. NOTE: Timer instructions see separate manual (order 0070923801-..) REMARQUE : Les instructions de réglage de la minuterie figurent dans le manuel séparé (n° de référence 0070923801-..). 5.3.1 Preparation time WARNING! AVERTISSEMENT !
  • Page 18 Operation Before the UV lamps turn on, you have a few minutes to prepare yourself. During the preparation time you can switch on the UV lamps at any time by pressing the START/STOP button. – Remove your clothes and all jewelry. –...
  • Page 19 Operation Studio customers can connect their own MP3 player to the device when the “Stereo Sound System PLUS” accessory is available Jack plug (JK Part # 4630911001-..) provided for use by the studio operator (2 x 3.5 mm stereo jack plug). 2.
  • Page 20 Cleaning and maintenance Cleaning and maintenance For a description on how to carry out cleaning and maintenance work, see Operating Instructions Part I (1006322). Cleaning plan 12098 / 0 Component Interval Activity Chap. Handle Clean and disinfect Control panel Clean and disinfect Base Clean and...
  • Page 21 Cleaning and maintenance Component Interval Activity Chap. Air nozzles Clean 7-8 Surfaces Clean 1) See Operating Instructions Part I NOTE: Cleaning must be confirmed after each tanning session by pressing the START/STOP button (when the cool-down time for the main fan has finished).
  • Page 22 Cleaning and maintenance Maintenance plan Component Interval Activity Chap. UV high-pressure Replace 4.10 lamps UV low-pressure Replace lamps base UV low-pressure Replace 4.10 lamps canopy UV low-pressure Replace 4.10 lamps face tanner Starter Replace Starter Replace 4.10 Starter Replace 4.11 Starter Replace 4.12...
  • Page 23 Technical data Technical data Power rating, electrical specifications and noise level Conformity mark (see name plate on page 22). PASSION 40/3 TURBO POWER Rated power without air condition: 9000 W with air condition – Rated frequency: 60 Hz Rated voltage: 230 V Fuse rating: 40 amp 3-pole or...
  • Page 24 Technical data Dimensions B = 47 4/16 in 1200 mm B1 = 30 11/16 in 780 mm H = 48 7/16 in 1230 mm H1 = 62 3/16 in 1580 mm 84 10/16 in 2150 mm (without Sound System) (without Sound System) 88 9/16 in 2250 mm (with Sound System)
  • Page 25 Technical data Lamp configuration CAUTION! The use of other UV lamps and filter panels voids the operating license! The UV high-pressure lamps fitted are broadband radiators that can be operated at different outputs (approx. 240-400 W). 7.3.1 PASSION 40/3 TURBO POWER Installed lamps Num.
  • Page 26 Technical data 7.3.2 Accent lighting Num. Lamp name, starter Power Order no. Low-pressure lamp blue 36 W 12969-.. Starter S10 10047-.. Low-pressure lamp white 18 W 1002513-.. Starter S10 10047-.. Spare parts and accessories Num. Name Order no. Acrylic base 1503569-..
  • Page 27 Appendix Appendix Signs and labels on the device Signs which warn of danger areas are attached to the device. The signs shown below are examples. Ensure that the instruction signs are always clearly recognizable and easily legible. 1 Nameplate MODEL NO. JK Products and Services, Inc.
  • Page 28 Appendix 2 Warning label 12076 / 0 3 USA mains connection label (1504659-..) The label is visible when the front panel is removed and the control unit cover opened. 4 USA power supply units label The sticker is visible when the front panel is removed and the control unit cover opened.
  • Page 29 Index Index Accessories ....................11 Acrylic cover, load ..................18 Cleaning ......................15 Cleaning intervals..................15 Cleaning plan ....................15 Definitions ....................... 5 Description ....................10 Device description ..................10 Dimensions ....................19 Electric shock ....................7 Electrical specifications ................. 18 Filter Cleaning intervals ..................
  • Page 30 Index Overheating of the device ................9 Power rating ....................18 Power input ....................23 Risk of fire ......................7 Safety notices ....................6, 7 Settings on start-up ..................13 Signs and stickers ..................22 Skin types ......................4 Spare parts ....................17 Order numbers ..................21 Start of tanning....................13 Starter ......................20 Tanning times ....................4 Technical data....................18...
  • Page 31 Index 1006351-02...
  • Page 33 J K- P R O D U C T S & S E R V I C E S , I N C . 1 Walter Kratz Drive Jonesboro, AR 72401 Phone: 800.643.0086 (Toll-free) Fax: 870.935.3618 Website: www.sunergoline.com E-Mail: ergoline@sunergoline.com...
