Installation Instructions
Model:
Description:
Part Number:
Assembly Time:
It is always a best practice to disconnect your negative battery terminal prior to any electronics
installations to avoid damaging the vehicle's electrical system. Before you begin, read through
these instructions and check that all parts are present.
This installation may require special skills and tools to complete and it may be necessary to seek
a trained installation technician to complete this installation. Please note that MB Quart cannot
assume any responsibility for damage resulting from incorrect installation.
No.
1
6.5" Coaxial Speaker and Enclosure Assembly
2
Mounting Brackets
3
M6 x 24.5mm Cutting Torx Screw
4
M4.2 x 13mm Hi-Lo Torx Screw
4
Drill
5
T20 & T40 Torx Bit
Polaris RZR Pro XP, Turbo R, Pro R
Rear Speaker Install
MBQRP-R116
30 Min (0.5-Hours)
Parts List
Component Name
Tools Required
Page 1 of 5
Parts List
Qty
2
2
4
2
Advertisement
Related Manuals for MB QUART MB QUART MBQRP-R116
Summary of Contents for MB QUART MB QUART MBQRP-R116
- Page 1 This installation may require special skills and tools to complete and it may be necessary to seek a trained installation technician to complete this installation. Please note that MB Quart cannot assume any responsibility for damage resulting from incorrect installation.
- Page 2 Installation ● Unlatch passenger seat. ● Remove (2) M6 Torx screws with a T40 Torx bit. (These will be reused in the next step.) ● Some vehicles may have an additional M6 Torx screw that will need to be removed. ●...
- Page 3 Installation ● Connect enclosure wiring to vehicle wiring. ● If adding to MB Quart Stage 3 Audio kit refer to that manual for wire routing. ● Some vehicles were pre-wired if adding to vehicle OEM audio. ● Latch rear of enclosure into tab pictured below.
- Page 4 Harness Installation ● Install last M6 Torx screw with a T40 Torx bit (If your vehicle had this screw). ● Repeat process on driver side of vehicle. Page 4 of 5...
- Page 5 Maxxsonics, LLC. This warranty is limited to defective parts and specifically excludes any incidental or consequential damages connected therewith. To view the full warranty, please visit the website. MB Quart products are designed and engineered in the USA by www.maxxsonics.com...
