MB QUART Polaris Sound Bar 8 Quick Start Manual

Congratulations on your choice of Polaris Sound Bars by
MB Quart.This "Quick Start" Installation guide is meant to
help you complete a basic installation. For more detailed
information about the product, please visit our website at
MBQuart.com
Wiring
The wiring and connections should be secure and away
from any moving parts or extremely hot surfaces.
3.5mm AUX IN
AUDIO OUTPUT Polaris Harness
Connection Plug
Controls
1
Power - Will turn the unit on or off. / Three second press will switch audio inputs.
2
PLAY / PAUSE - Press once to pause. Press again to play.
3
Volume DOWN - Each press will decrease the volume.
4
Volume UP - Each press will increase the volume.
5
Track DOWN - Press to restart the current track or to back up to previous tracks.
6
Track UP - Press to advance to the next track.
Power
1
Volume DOWN
3
Track DOWN
Bluetooth Device Pairing
The pairing process can vary based on your particular device. Refer to the
operating instructions of your device. Below is the general process to connect.
The Polaris Sound bar unit can be powered on either with the power button or with the
orange remote turn on wire.
During unit power up, the blue LED on the left of the control panel will blink indicating
that it is in Bluetooth search mode.
During this process "POLARIS" should show up in your list of Bluetooth devices when
the search has connected with your device. When the connection is made the blue
LED will change to solid.
Once a device has been paired the unit will reconnect at power up if the device is in
range.
To connect to a different device, the first device will need to be disconnected.
When a phone call is received, the audio signal will mute but not disconnect.
To switch to 3.5mm press the power button for three sec.
To switch back to BT press the power button again for three sec.
PLAY / PAUSE
Volume UP
Track UP
5 6
2
4
