Pre-Ride
Checklist
Before you head out on your
2X2, always check that your
bike is ready to ride.
1. Battery
Ensure there is enough
charge to carry out your
work or journey. Check
that the battery strap is
secured tightly.
2. Brakes
Check the brakes are
working and inspect their
brake pads for wear.
3. Lights
Ensure the headlight, rear
light, and brake light are
working.
4. Kickstand
Check the kickstands are
functional, especially if
the bike is loaded up, and
check it stays up when
retracted. Retract the
kickstand before riding.
5. Horn
Sound the horn to ensure
it's working.
DO NOT ride the bike if it is materially
defective in operation, damaged, or missing
safety-related equipment. Physically check
off each of the above before you ride.
6. Tires
Check the condition and
pressure of the tires.
7. Loose Fixings
Ensure all the fixings
( nuts & bolts ) are done
up correctly and secure.
8.Load
Ensure all functional
parts of the bike are not
obstructed by any load
you may be carrying.
9. Wear Safe
For your safety, please
wear a helmet and
appropriate riding gear.
10. Keys
Remember to take your
key fob with you ( unless
you've turned security
mode off ) .
Have Fun!
