- Page 1 Infinity DSP Amplifier DSP6840 Owner's Manual Mode d’emploi Manual de propietario Jmdh\h^kl\hihevah\Zl_ey ZH-CH =*[C Panduan Pengguna ”áÇE zw^혓òSê...
- Page 2 THANK YOU FOR YOUR PURCHASE . . . Your product has been designed to provide you the performance and ease of operation you expect from Infinity. Take time to read this manual before operating or installing your amplifier. This manual describes general installation guidelines and operation instructions.
- Page 3 Infinity DSP Amplifier DSP6840 PRODUCT DESCRIPTION The Infinity DSP Amplifier is an audio processor for fine-tuning of aftermarket audio systems. It is a self-contained audio system with 6-channel audio inputs, 8-channel powered audio outputs, an easy-to-use tuning interface a novice can understand, and detailed tuning capabilities to satisfy even experienced installers.
- Page 4 Signal input • Line-level inputs: If your source unit offers preamp outputs, connect the front outputs to inputs 1 and 2 on the amplifier, the rear outputs to inputs 3 and 4, and the subwoofer outputs to inputs 5 and 6 using RCA patch cables. Note: when using low-level signals and remote turn-on lead, set the “Turn-on Mode”...
- Page 5 5. Double-click “setup.exe”. NOTE: Make sure to allow it to make changes to your computer if your anti-virus software requests it. INFINITY DSP Software Welcome to the INFINITY DSP Software Setup Wizard The installer will guide you through the steps required to install INFINITY DSP Software on your computer.
- Page 6 Connecting Infinity DSP Amplifier to your The Infinity tuning software features the following controls: Windows PC 1. Assign speaker locations to channels. With this feature, you can designate the type of speaker and location in the car 1. Connect your Windows PC to the DSP Amplifier with the each output channel of the DSP is connected to.
- Page 7 15. Reset EQ. This button lets you reset the type of speaker, and TROUBLESHOOTING location in the vehicle, of each output channel. 16. EQ Mode. This lets you choose either a 31 band parametric No audio and POWER INDICATOR is off. or graphic EQ to adjust for each channel.
- Page 8 HARMAN International Industries, © 2022 HARMAN International Industries, Incorporated. All rights reserved. Incorporated 8500 Balboa Boulevard, Infinity is a trademark of HARMAN International Industries, Incorporated, Northridge, CA 91329 USA registered in the United States and/or other countries. Features, specifications www.infinityspeakers.com and appearance are subject to change without notice.
- Page 9 Conformal Coated PCB clipping indicator to ensure the audio output is not distorted and ability to save up to 10 Harman Standard Reliability Testing presets. Infinity Industrial Design...
- Page 10 HARMAN International Industries, Incorporated © 2022 HARMAN International Industries, Incorporated. All rights reserved. Infinity is a trademark of 8500 Balboa Boulevard, Northridge, CA 91329 USA HARMAN International Industries, Incorporated, registered in the United States and/or other countries.
