Original user manual
TRUSS WALL
MOUNT 30
Manufacturer:
Rolight Theatertechniek B.V.
Josink Kolkweg 10
7545 PR Enschede , The Netherlands
Phone (+31)53 432 06 44
info@rolight.nl
www.rolight.nl
Distributed by ADMIRAL
www.admiralstaging.com
VERSION 01
September 2024
SKU: RIHTWB30
RIHTWC30
Advertisement
Related Manuals for Admiral Staging TRUSS WALL MOUNT 30
Summary of Contents for Admiral Staging TRUSS WALL MOUNT 30
- Page 1 Original user manual TRUSS WALL MOUNT 30 Manufacturer: Rolight Theatertechniek B.V. Josink Kolkweg 10 7545 PR Enschede , The Netherlands Phone (+31)53 432 06 44 VERSION 01 info@rolight.nl September 2024 www.rolight.nl SKU: RIHTWB30 RIHTWC30 Distributed by ADMIRAL www.admiralstaging.com...
- Page 2 1. INTRODUCTION WARNING: Indicates a hazardous situation which, if not avoided, could result in death or serious injury. The ADMIRAL TRUSS WALL MOUNT 30 allows for the horizontal installation of a truss construction between walls. CAUTION The TRUSS WALL MOUNT 30 is intended for...
- Page 3 Check local legislation for the supporting structure are dry and free of dirt. application of use. • Do not use the TRUSS WALL MOUNT 30 to guide currents for electric potential bonding. • Use appropriate packaging to transport the 4. LIMITATIONS OF USE products.
- Page 4 • Do not use the TRUSS WALL MOUNT 30 in e.g. WARNING swimming pools or other spaces with poluted air conditions. Distribute the load evenly. • Place the truss in the TRUSS WALL MOUNT 30 at least as far as the bolt for the clamp strip will sit behind the end brace.
- Page 5 NEN-EN 1990 (Eurocode 1) Action on structures weight 11 kg NEN-EN 1990 (Eurocode 3) Design of steel structures MAX LOAD TRUSS WALL MOUNT 30 sticker Brand name Batch code* Weight Product name QR code to online manual Article code Max load...
- Page 6 Mount the TRUSS WALL MOUNT 30 to the wall. Drill some holes in the wall (see plate for positions ) and fix the TRUSS WALL MOUNT 30 to the wall Mount the other TRUSS WALL MOUNT 30 at the exact same height on the opposite wall.
- Page 7 1x per year. In case of doubt contact ADMIRAL. WARNING If damaged, mark the item clearly and take it out of service. WARNING Do not use the TRUSS WALL MOUNT 30 outside. Make sure no horizontal forces, like wind, are acting on the system.
- Page 8 ADMIRAL. • The manufacturer is not liable for indirect consequential damage and financial loss. • The manufacturer shall not be liable for any changes made to the TRUSS WALL MOUNT 30 parts nor for any damage resulting from such changes.
- Page 9 7545 PR Enschede The Netherlands Herewith declares that: ADMIRAL “TRUSS WALL MOUNT 30”; article code RIHTWB30 & RIHTWC30 - the following harmonized standards have been used (or parts/clauses of): EN 12100-1-2010 - part/clauses of the following technical regulations , standards and information...
