USER MANUAL FOR
STRONG
BOY MINI
ON THE OTHER SIDE
STRONG BOY
USER MANUAL
Admiral Staging the Netherlands
www.admiralstaging.com +31 534 301 201
USE
Use Admiral truss carriers
to stack the truss.
Store your Admiral
30 truss carriers
WARNING
Don't load higher than
2 meters to prevent instability.
Always use the dolly on a
flat surface.
castor
castor
Ø100 mm
Ø125 mm
Secure with sufficient
lashing straps.
The Strong Boy is stack-
able for easy storage.
The intended use of the Strong Boy is to transport 30 or 40 truss.
Always use two carts when transporting 2 meters of truss or
longer. Each badge of truss needs to be secured with straps.
CAUTION
1.99 m or less
1
2
1 x frame:
Strong Boy frame WASBC34
1
4 x castor:
Swivel castor 100 with break ZEWACW14
2
1 x bolt set:
Assembly kit Strong Boy (mini) ZEM2SV35
ASSEMBLY
The Strong Boy hardly needs any maintenance
under normal use and environmental circumstances.
For safety reasons however, all parts must be checked
regularly for dirt, damages, loss and corrosion.
•
Check all components for damage and corrosion.
Damaged and corroded parts shall be rejected and
thrown away.
Replaced component shall be genuine Admiral only.
2 m or more
Advertisement
Table of Contents
Related Manuals for Admiral Staging STRONG BOY
Summary of Contents for Admiral Staging STRONG BOY
- Page 1 SCOPE The intended use of the Strong Boy is to transport 30 or 40 truss. Always use two carts when transporting 2 meters of truss or USER MANUAL FOR STRONG longer. Each badge of truss needs to be secured with straps.
- Page 2 SCOPE The intended use of the Strong Boy mini is to transport 30 truss. Always use two Strong Boy mini per badge of truss. Each badge USER MANUAL FOR of truss needs to be secured with straps at any time.
