Nordcap EK 6 x GN 1/1 Installation Instructions

A - Included Components
1
6-10 GRIDS
20 GRIDS
B - H2O Connections
2
100 – 600 kPa
(1,0 – 6,0 bar / 14,5 – 87psi)
- min 1 l/min - max 10 l/min
CWI1
H O
2
CWI 2
WTS
H O
2
Water Treatment System
- min 0,25 l/min - max 2,95 l/min for 6-10 GN w/boiler models
- min 0,25 l/min - max 5,75 l/min for 20 GN w/boiler models
C - Drain Connection
3
Drain Hose ø50mm
smooth fitting
AUS only: The appliance
DRAIN
shall be drained to a
certified waste trap
positioned at the drainage
system connection point.
AIR BREAK
min 1.0 mt
I N S T A L L A T I O N
PRESSURE
max 30 °C
max 30 °C
6-10 GRIDS
DRAIN
AIR BREAK
I N S T R U C T I O N S
A
(GAS OVEN ONLY)
20 GRIDS
4
GAS
ø1"
20 GRIDS 1/1
ø1"
20 GRIDS 2 /1
ø1"
10 GRIDS 2/1
ø1/2"
6 GRIDS 1/1
ø1/2" 1
6 GRIDS 2 /1
ø1/2"
10 GRIDS 1/1
DOC. No. 598403801 Ed. 02.2023
IMPORTANT: For compliance with UK Water Supply (Water
Fittings) Regulations the installer technician must provide a
WRAS approved double check valve for each water con-
nection, or other device no less effective that provides back-
flow protection of at least fluid category three.
A
GAS PRESSURE
INSTALLATION MANUAL
GAS PRESSURE
REGULATOR
GAS INLET
CWI2:
H2O
µS/cm, cl - (ppm), °f
WTS
H O
?
2
Water
Treatment
System
INSTALLATION MANUAL INSTALLATION MANUAL
D - Gas Connections
