Predator Orion X-650
Desktop Computer Service Guide
Service guide files and updates are available on the
Acer/CSD web site; for more information, go to
http://gcsd.acer.com.tw/GCSD_Portal/
SG V1.02
PRINTED IN TAIWAN

Advertisement

loading
Need help?

Need help?

Do you have a question about the Predator Orion X-650 and is the answer not in the manual?

Questions and answers

Related Manuals for Acer Predator Orion X-650

Summary of Contents for Acer Predator Orion X-650

  • Page 1 Predator Orion X-650 Desktop Computer Service Guide Service guide files and updates are available on the Acer/CSD web site; for more information, go to http://gcsd.acer.com.tw/GCSD_Portal/ SG V1.02 PRINTED IN TAIWAN...
  • Page 2 Revision History Refer to the table below for changes made on this version of the Predator Orion X-650 Desktop Computer Service Guide. Date Version Chapter Updates 08-09-2023 First Draft 08-11-2023 V1.00 09-26-2023 V1.01 Updated the System Assembly and Disassembly information.
  • Page 3 Any Acer Incorporated software described in this guide is sold or licensed as is. Should the programs prove defective following their purchase, the buyer (and not Acer Incorporated, its distributor, or its dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the software.
  • Page 4 Alerts you to any physical risk or system damage that might result from doing or not doing specific actions. CAUTION Gives precautionary measures to avoid possible hardware or software problems. IMPORTANT Reminds you to do specific actions relevant to the accomplishment of procedures. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 5 FRU list of this printed service guide. You MUST use the list provided by your regional Acer office to order FRU parts for repair and service of customer machines. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 6 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 7 Removing the HDD1 Module ........49 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 8 Predator Orion X-650 FRU List ........
  • Page 9 Approved Vendor List (AVL) ......... . .147 Online Support Information................151 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 10 Table of Contents Predator Orion X-650 Desktop Computer Service Guide...
  • Page 11 Chapter 1 Features and Specifications This chapter lists the features and specifications of the Predator Orion X-650 Desktop Computer. NOTE The items listed in this section are for reference only. The exact configuration of your PC depends on the model purchased.
  • Page 12 Packed: -20 to 60 °C (-4 to 140 °F) Unpacked: -10 to 60 °C (14 to 140 °F) Humidity Item Description Operating 15% to 80% RH non-condensing Non-operating 10% to 90% RH non-condensing at 40 °C Predator Orion X-650 Desktop Computer Service Guide...
  • Page 13 Zone 2 Release Latch Zone 1 Release Latch Power button/LED Portable SSD Device USB 3.2 Gen1 Type A port Headset combo jack (does not support microphone only device) Microphone jack USB 3.2 Gen1 Type C port Predator Orion X-650 Desktop Computer Service Guide...
  • Page 14 Microphone jack Line-out jack Line-in jack USB 3.2 Gen2x2 Type C port USB 3.2 Gen1 Type A port LAN connector USB 3.2 Gen2 Type A port USB 2.0 ports Graphics card Power connector Predator Orion X-650 Desktop Computer Service Guide...
  • Page 15 Population Matrix Table. Hard Disk Drive Item Specification Controller Integrated in the Intel H770 chipset Number of HDD bays Form factor 2.5-inch Interface SATA 3.0 Supported capacities Vendor and models Western Digital – 1TB WD10SPZX-21Z10T0 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 16 • Killer 1690i WLAN AX + BT Form factor M.2 2230 Interface PCIe V3.0 Protocol WLAN M.2 2X2 AX + BT 5.2 SATA Interface Item Specification SATA Controller Integrated in the Intel H770 chipset Connectors Two SATA 3.0 ports Predator Orion X-650 Desktop Computer Service Guide...
  • Page 17 Seven USB ports (two in front and five on rear) Power Supply Unit Item Specification Type FR 850W power supply unit (Active PFC) Input 100-240V Output (max.) 850W Vendor and models FSP FSP850-57SBB 850W Active PFC SFX Predator Orion X-650 Desktop Computer Service Guide...
  • Page 18 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 19 Chapter 2 System Utilities This chapter lists the system utilities installed in Predator Orion X-650 Desktop Computer. CMOS Setup Utility CMOS Setup Utility is a hardware configuration program built into the system ROM. Since most systems are already properly configured and optimized, there is normally no need to run this utility.
  • Page 20 Some options (marked with a) lead to submenus that enable you to change the values for the option. Use the Up/Down/Left/Right arrow keys to scroll through the items in the submenu Predator Orion X-650 Desktop Computer Service Guide...
  • Page 21 • On one of the primary menu screens, the Exit menu displays. • On a submenu screen, the previous screen displays. • When you are making selections from a pop-up menu, closes the pop- up without making a selection. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 22 System Serial Number System serial number. Base Board Serial Number Base board serial number. Asset Tag Number System asset tag number System Date Sets the system date. System Time Sets the system time. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 23 I/O controllers. PC Health Status Access this submenu to view current level of system/processor/PCH temperature, voltages, and fan speed. BIOS Flash Select this option to manually update the BIOS using a USB flash drive. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 24 GPU frame buffer at once and improve performance. NOTE: This option is only available when Above 4G Decoding is enabled. GNA Device Enable or disable Intel® Gaussian & Neural Accelerator Enabled (Intel® GNA). Disabled Predator Orion X-650 Desktop Computer Service Guide...
  • Page 25 Disabled Intel (R) Rapid Storage Select to configure the Intel Rapid Storage Technology (RST) function. Technology Killer E2600 Gigabit Select to configure the Killer E2600 LAN configuration. Ethernet Controller Predator Orion X-650 Desktop Computer Service Guide...
  • Page 26 Enabled Temperature function. Disabled Smart Fan Enables or disables the smart system fan control Enabled function. Disabled CPU TCC Activation Enables or disables the processor’s Thermal Control Enabled Circuit (TCC) activation function. Disabled Predator Orion X-650 Desktop Computer Service Guide...
  • Page 27 USB keyboard or mouse. Disabled Restore On AC Power Enables or disables the system to reboot after a power Power Off Loss failure or interrupt occurs. Power On Last State Predator Orion X-650 Desktop Computer Service Guide...
  • Page 28 Displays the current system boot status. Setup User • Setup - Secure keys not installed. • User - Secure keys installed Secure Boot Mode State Displays the current system boot mode status. Enabled Disabled Predator Orion X-650 Desktop Computer Service Guide...
  • Page 29 Enables or disables the secure boot function. Enabled Disabled Secure Boot Mode Select the secure boot mode when secure boot is Standard enabled. Custom Default Key Provisioning Enables or disables the default key provisioning Enabled function. Disabled Predator Orion X-650 Desktop Computer Service Guide...
  • Page 30 Press Enter twice without entering anything in the new and confirm password fields. You will be prompted to confirm the password removal. Press Enter. Press F10 to save the changes you made and close the Setup Utility. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 31 • All, but Keyboard – If a keyboard error is detected, No Errors BIOS will pause the system. • All Errors –- Any error detected will pause the system. • No Errors – BIOS will ignore any errors detected during POST Predator Orion X-650 Desktop Computer Service Guide...
  • Page 32 Save as User Default Select this option and press Enter to save changes that you have made as Settings user defaults. Load User Default Settings Select this option and press Enter to restore user defaults. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 33 Unplug the power cord from the computer. Unplug the network cable and all connected peripheral devices from the computer. Place the computer on a flat, steady surface with the rear cover facing upward. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 34 Disassembly Procedures Removing the Portable SSD Device Open the portable SSD device slot cover. Pull out the portable SSD device from the chassis. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 35 Detach the top and front cover of the portable SSD device. Remove the screw securing the SSD module to the portable SSD device. Quantity Color Torque Part Number Screw Type Black 1.5 ± 0.3 kgf-cm Predator Orion X-650 Desktop Computer Service Guide...
  • Page 36 Note: WEEE Annex VII component. A circuit board >10 cm2 has been highlighted with the yellow rectangle as shown above. Please follow local regulations for disposal of detached circuit boards. Detach the thermal pad from the portable SSD device. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 37 Removing the Left Side Panel Remove the two screws securing the left side panel to the chassis. Quantity Color Torque Part Number Screw Type Black 4.0 ± 0.5 kgf-cm Detach the left side panel. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 38 Disconnect the power cable from the graphics card. Remove the three screws securing the graphics card brackets to the chassis. Quantity Color Torque Part Number Screw Type Black 6.0 ± 0.5 kgf-cm 86.SR2D1.001 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 39 Detach the graphics card from the PCIe x16 extension slot. Note: WEEE Annex VII component. A circuit board >10 cm2 has been highlighted with the yellow rectangle as shown above. Please follow local regulations for disposal of detached circuit boards. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 40 Removing the Right Side Panel Remove the two screws securing the right side panel to the chassis. Quantity Color Torque Part Number Screw Type Black 4.0 ± 0.5 kgf-cm Detach the right side panel. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 41 Disconnect the heatsink fan and LED cables from the mainboard. Loosen the four captive screws securing the thermal module to the mainboard. Quantity Color Torque Part Number Screw Type Silver 6.0 ± 0.5 kgf-cm Thermal Screws Predator Orion X-650 Desktop Computer Service Guide...
  • Page 42 Remove the thermal module. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 43 WARNING: The processor becomes very hot when the system is on. Allow it to cool off first before handling. Press the load lever and move it to the right to release the load lever from the retention tab. Pull the load lever to release the processor from its socket. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 44 Lift the processor from the socket. Note: WEEE Annex VII component. A circuit board >10 cm2 has been highlighted with the yellow rectangle as shown above. Please follow local regulations for disposal of detached circuit boards. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 45 Note: WEEE Annex VII component. A circuit board >10 cm2 has been highlighted with the yellow rectangle as shown above. Please follow local regulations for disposal of detached circuit boards. Repeat Step 1 to remove the remaining memory module. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 46 Removing the SSD2 Module Remove the screw securing the SSD2 module assembly to the mainboard. Quantity Color Torque Part Number Screw Type Black 1.5 ± 0.3 kgf-cm 86.BFZD1.001 Remove the SSD2 module assembly from the mainboard. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 47 Note: WEEE Annex VII component. A circuit board >10 cm2 has been highlighted with the yellow rectangle as shown above. Please follow local regulations for disposal of detached circuit boards. Detach the thermal pad from the SSD heatsink. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 48 Removing the SSD Board Disconnect the SSD cable from the SSD board. Remove the three screws securing the SSD board to the mainboard. Quantity Color Torque Part Number Screw Type Black 1.5 ± 0.2 kgf-cm 86.E3SD1.002 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 49 Note: WEEE Annex VII component. A circuit board >10 cm2 has been highlighted with the yellow rectangle as shown above. Please follow local regulations for disposal of detached circuit boards. Disconnect and remove the SSD cable from the mainboard. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 50 Removing the SSD1 Module Remove the screw securing the SSD1 module assembly to the mainboard. Quantity Color Torque Part Number Screw Type Black 1.5 ± 0.3 kgf-cm 86.BFZD1.001 Remove the SSD1 module assembly from the mainboard. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 51 Note: WEEE Annex VII component. A circuit board >10 cm2 has been highlighted with the yellow rectangle as shown above. Please follow local regulations for disposal of detached circuit boards. Detach the thermal pad from the SSD heatsink. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 52 NOTE: For reference during machine reassembly, note which cable color corresponds to the main and auxiliary connectors. Remove the screw securing the WLAN module to the mainboard. Quantity Color Torque Part Number Screw Type Black 1.5 ± 0.3 kgf-cm 86.BFZD1.001 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 53 Remove the WLAN module from the mainboard. Note: WEEE Annex VII component. A circuit board >10 cm2 has been highlighted with the yellow rectangle as shown above. Please follow local regulations for disposal of detached circuit boards. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 54 Removing the Top Cover Remove the two screws securing the top cover to the chassis. Quantity Color Torque Part Number Screw Type Black 4.0 ± 0.5 kgf-cm Detach the top cover from the chassis. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 55 Removing the Front Bezel Release the cables from the cable tie and plastic clips that secure them to the chassis. Disconnect the power button/LED cable from the mainboard. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 56 Remove the four screws securing the front bezel to the chassis. Quantity Color Torque Part Number Screw Type Black 6.0 ± 0.5 kgf-cm 86.SR2D1.001 Disengage the latches securing the front bezel to the chassis. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 57 Detach the front bezel from the chassis. Pull out the power button/LED cables from the chassis. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 58 Removing the Bottom Cover Remove the two screws securing the bottom cover to the chassis. Quantity Color Torque Part Number Screw Type Black 4.0 ± 0.5 kgf-cm Detach the bottom cover from the chassis. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 59 Disconnect the power and data cables from the HDD1 module. Remove the four screws securing the HDD1 module to the chassis. Quantity Color Torque Part Number Screw Type Silver 4.0 ± 0.3 kgf-cm 86.3A534.4R0 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 60 Detach the HDD1 module from the chassis. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 61 Disconnect the power and data cables from the HDD2 module. Remove the four screws securing the HDD2 module to the chassis. Quantity Color Torque Part Number Screw Type Silver 4.0 ± 0.3 kgf-cm 86.3A534.4R0 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 62 Detach the HDD2 module from the chassis. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 63 Removing the PCIe x16 Extension Cable Remove the adhesive tape. Disconnect the PCIe x16 extension cable from the mainboard. Remove the two screws securing the PCIe x16 extension cable to the chassis. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 64 Quantity Color Torque Part Number Screw Type Black 6.0 ± 0.5 kgf-cm 86.B9AD1.001 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 65 Remove the PCIe x16 extension cable from the chassis. Note: WEEE Annex VII component. A circuit board >10 cm2 has been highlighted with the yellow rectangle as shown above. Please follow local regulations for disposal of detached circuit boards. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 66 Removing the System Fans Disconnect the system fan power and LED cables from the mainboard. Detach the upper chassis assembly. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 67 Remove the eight screws securing the system fans to the upper chassis assembly. Quantity Color Torque Part Number Screw Type Black 4.0 ± 0.5 kgf-cm 86.E3SD1.001 Detach the system fans from the upper chassis assembly. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 68 Removing the Power Supply Module Disconnect the power cable extension from the power supply module. Disconnect the power supply cables from the mainboard. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 69 Remove the three screws securing the power supply module to the chassis. Quantity Color Torque Part Number Screw Type Black 6.0 ± 0.5 kgf-cm 86.SR2D1.001 Pull the power supply module out of the chassis. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 70 Removing the HDD SATA Cables Disconnect and remove the HDD SATA cables from the mainboard. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 71 Removing the Front I/O Module Disconnect the front I/O and audio cables from the mainboard. Pull out the front I/O and audio cables from the chassis. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 72 Remove the two screws securing the front I/O bracket to the chassis. Quantity Color Torque Part Number Screw Type Black 6.0 ± 0.5 kgf-cm 86.SR2D1.001 Detach the front I/O bracket from the chassis. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 73 Pull out the front I/O and audio cables from the chassis. Remove the two screws securing the front I/O board to the bracket. Quantity Color Torque Part Number Screw Type Black 1.5 ± 0.2 kgf-cm 86.E3SD1.002 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 74 Remove the front I/O board from the bracket. Note: WEEE Annex VII component. A circuit board >10 cm2 has been highlighted with the yellow rectangle as shown above. Please follow local regulations for disposal of detached circuit boards. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 75 Removing the Mainboard Disconnect the portable SSD device cable from the mainboard. Remove the four screws securing the mainboard to the chassis. Quantity Color Torque Part Number Screw Type Black 6.0 ± 0.5 kgf-cm 86.B9AD1.001 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 76 Please follow local regulations for disposal of used batteries. Caution: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 77 Removing the WLAN Antenna Cables Detach the WLAN antenna cover from the rear chassis. Release the WLAN antenna cable from the adhesive tape that secures them to the chassis. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 78 Gently peel off the WLAN antenna from the chassis. Pull and remove the WLAN antenna cables from the chassis. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 79 Reassembly Procedures Reinstalling the WLAN Antenna Cables Insert the WLAN antenna cables into the chassis. Use double sided adhesive tape to secure the WLAN antenna into the chassis. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 80 Secure the WLAN antenna cable to the chassis using adhesive tape. Insert the WLAN antenna cover into the rear chassis and press it down until it latches into place. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 81 Use a double sided tape to secure the RTC battery to the side of the RJ45 connector (1), then connect the RTC battery cable to the mainboard (2). Insert the mainboard towards the rear of the chassis, making sure the I/O ports of the mainboard are extruding from their port holes. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 82 Secure the mainboard to the chassis using four screws. Quantity Color Torque Part Number Screw Type Black 6.0 ± 0.5 kgf-cm 86.B9AD1.001 Connect the portable SSD device cable to the mainboard. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 83 Reinstalling the Front I/O Module Insert the front I/O board into the bracket. Secure the front I/O board to the bracket using two screws. Quantity Color Torque Part Number Screw Type Black 1.5 ± 0.2 kgf-cm 86.E3SD1.002 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 84 Insert the front I/O and audio cables into the chassis. Place the front I/O bracket into the chassis. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 85 Secure the front I/O bracket to the chassis using two screws. Quantity Color Torque Part Number Screw Type Black 6.0 ± 0.5 kgf-cm 86.00P64.A686.SR2D 1.0010 Insert the front I/O and audio cables into the chassis. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 86 Connect the front I/O and audio cables to the mainboard. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 87 Reinstalling the HDD SATA and Power Cables NOTE: Some Predator Orion X-650 systems will not ship with 2.5-inch HDD modules installed. However, the HDD power and SATA cables are included in the original accessory box. Connect the HDD SATA cables to the mainboard.
  • Page 88 Slide the power supply module into its socket in the chassis. Secure the power supply module to the chassis using four screws. Quantity Color Torque Part Number Screw Type Black 6.0 ± 0.5 kgf-cm 86.SR2D1.001 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 89 Connect the power supply cables to the mainboard. Connect the power cable extension to the power supply. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 90 Insert the system fans into the upper chassis assembly. Secure the system fans to the upper chassis assembly using eight screws. Quantity Color Torque Part Number Screw Type Black 4.0 ± 0.5 kgf-cm 86.E3SD1.001 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 91 Replace the upper chassis assembly and push it down until it latches into place. Connect the system fan power and LED cables to the mainboard. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 92 Place the PCIe x16 extension cable into the chassis. Secure the PCIe x16 extension cable to the chassis using two screws. Quantity Color Torque Part Number Screw Type Black 6.0 ± 0.5 kgf-cm 86.B9AD1.001 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 93 Connect the PCIe x16 extension cable to the mainboard. Secure the PCIe x16 extension cable using adhesive tape. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 94 Reinstalling the HDD2 Module Place the HDD2 module into the chassis. Secure the HDD2 module to the chassis using four screws. Quantity Color Torque Part Number Screw Type Silver 4.0 ± 0.3 kgf-cm 86.3A534.4R0 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 95 Connect the power and data cables to the HDD2 module. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 96 Reinstalling the HDD1 Module Place the HDD1 module into the chassis. Secure the HDD1 module to the chassis using four screws. Quantity Color Torque Part Number Screw Type Silver 4.0 ± 0.3 kgf-cm 86.3A534.4R0 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 97 Connect the power and data cables to the HDD1 module. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 98 Reinstalling the Bottom Cover Place the bottom cover into the chassis. Secure the bottom cover to the chassis two screws. Quantity Color Torque Part Number Screw Type Black 4.0 ± 0.5 kgf-cm Predator Orion X-650 Desktop Computer Service Guide...
  • Page 99 Reinstalling the Front Bezel Insert the power button/LED cables into the chassis. Push the front bezel into the chassis until the latches lock into place. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 100 Secure the front bezel to the chassis using four screws. Quantity Color Torque Part Number Screw Type Black 6.0 ± 0.5 kgf-cm 86.SR2D1.001 Secure the power button/LED cables to the chassis using the metal clip. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 101 Connect the power button/LED cables to the mainboard. Secure the cables to the chassis using the cable tie and plastic clips. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 102 Place the top cover into the chassis push it towards the front until it latches into place. Secure the top cover to the chassis using two screws. Quantity Color Torque Part Number Screw Type Black 4.0 ± 0.5 kgf-cm Predator Orion X-650 Desktop Computer Service Guide...
  • Page 103 Insert the WLAN module into its slot in the mainboard. Secure the WLAN module to the mainboard using one screw. Quantity Color Torque Part Number Screw Type Black 1.5 ± 0.3 kgf-cm 86.BFZD1.001 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 104 Connect the WLAN antenna cables to the WLAN module. NOTE: Refer to your machine disassembly note to determine which cable color corresponds to the main and auxiliary connectors. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 105 Reinstalling the SSD1 Module Place the thermal pad into the SSD heatsink. Insert the SSD1 module into the SSD heatsink. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 106 Insert the SSD1 module into the mainboard. Secure the SSD1 module to the mainboard using one screw. Quantity Color Torque Part Number Screw Type Black 1.5 ± 0.3 kgf-cm 86.BFZD1.001 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 107 Reinstalling the SSD Board Connect the SSD cable to the mainboard. Insert the SSD board into the mainboard. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 108 Secure the SSD board to the mainboard using three screws. Quantity Color Torque Part Number Screw Type Black 1.5 ± 0.2 kgf-cm 86.E3SD1.002 Connect the SSD cable to the SSD board. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 109 Reinstalling the SSD2 Module Place the thermal pad into the SSD heatsink. Insert the SSD2 module into the SSD heatsink. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 110 Insert the SSD2 module into the mainboard. Secure the SSD2 module to the mainboard using one screw. Quantity Color Torque Part Number Screw Type Black 1.5 ± 0.3 kgf-cm 86.BFZD1.001 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 111 Insert the memory module into the DIMM slot (1) then press it down until it latches into place (2). Repeat Step 1 to install the other memory module. IMPORTANT When installing DIMM modules, populate the DIMM slots according to the table below: Size DIMM1 DIMM2 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 112 NOTE: Make sure the gold arrow on the corner of the processor is aligned with the beveled corner of the socket. The processor will easily fit into the socket if it is properly oriented. Replace the CPU cover plate. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 113 Pull down the load lever to secure the processor into its socket. Slide the load lever to the left until it latches into the retention tab. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 114 Place the thermal module into the mainboard. Tighten the four captive screws to secure the thermal module to the mainboard. Quantity Color Torque Part Number Screw Type Silver 6.0 ± 0.5 kgf-cm Thermal Screws Predator Orion X-650 Desktop Computer Service Guide...
  • Page 115 Connect the heatsink fan and LED cables to the mainboard. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 116 Insert the right side panel into the right side of the chassis and push until it latches into place. Secure the right side panel to the chassis using two screws. Quantity Color Torque Part Number Screw Type Black 4.0 ± 0.5 kgf-cm Predator Orion X-650 Desktop Computer Service Guide...
  • Page 117 Reinstalling the Graphics Card Insert the graphics card into the PCIe x16 extension slot, then press it down until it latches into place. Use the metal clip to secure the graphics card bracket to the chassis. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 118 Secure the graphics card brackets to the chassis using three screws. Quantity Color Torque Part Number Screw Type Black 6.0 ± 0.5 kgf-cm 86.SR2D1.001 Connect the power cable to the graphics card. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 119 Insert the left side panel into the left side of the chassis and push until it latches into place. Secure the left side panel to the chassis using two screws. Quantity Color Torque Part Number Screw Type Black 4.0 ± 0.5 kgf-cm Predator Orion X-650 Desktop Computer Service Guide...
  • Page 120 Insert the SSD module into the portable SSD device. Secure the SSD module to the portable SSD device using one screw. Quantity Color Torque Part Number Screw Type Black 1.5 ± 0.3 kgf-cm Predator Orion X-650 Desktop Computer Service Guide...
  • Page 121 Secure the portable SSD device cover using four screws. Quantity Color Torque Part Number Screw Type Black 1.5 ± 0.2 kgf-cm Insert the portable SSD device in its slot and push it until it latches into place. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 122 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 123 This chapter provides instructions on how to troubleshoot system hardware problems. Hardware Diagnostic Procedure IMPORTANT The diagnostic tests described in this chapter are only intended to test Acer products. Non- Acer products, prototype cards, or modified options can give false errors and invalid system responses.
  • Page 124 Verify that all power and data cables are firmly and properly attached to the installed drives. Verify that all cable connections inside the system are firmly and properly attached to their appropriate mainboard connectors. Verify that all components are Acer-qualified and supported. 10. Reinstall the side panel. 11. Power on the system.
  • Page 125 Erase the flash part. Program the flash part. The flash has been updated successfully. Make flash write disabled. Disable ATAPI hardware. Restore CPUID value back into register. Give control to F000 ROM at F000:FFF0h. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 126 Display total memory in the system. Mid POST initialization of chipset registers. Detect different devices (Parallel ports, serial ports, and coprocessor in CPU, ... etc.) successfully installed in the system and update the BDA, EBDA…etc. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 127 Uninstall POST INT1Ch vector and INT09h vector. Deinitializes the ADM module. Prepare BBS for Int 19 boot. End of POST initialization of chipset registers. Save system context for ACPI. Passes control to OS Loader (typically INT19h). Predator Orion X-650 Desktop Computer Service Guide...
  • Page 128 IMPORTANT: If your system fails after you make changes in the Setup menus, reboot the computer, enter Setup again and load Setup defaults to correct the error. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 129 The IDE/ATAPI device configured as Secondary Master could not be properly Hard Disk Error initialized by the BIOS. This message is typically displayed when the BIOS is trying to detect and configure IDE/ATAPI devices in POST. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 130 The IDE/ATAPI device configured as Slave in the 4th IDE controller failed an ATAPI ATAPI Incompatible compatibility test. This message is typically displayed when the BIOS is trying to detect and configure IDE/ATAPI devices in POST. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 131 Detection is enabled in AMIBIOS setup. VIRUS: Continue  If the BIOS detects possible virus activity, it will prompt the user. This message will (Y/N)? only be displayed if Virus Detection is enabled in AMIBIOS setup. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 132 CMOS battery is low. This message usually indicates that the CMOS battery needs to be replaced. It could also appear when the user intentionally discharges the CMOS battery. CMOS Settings CMOS settings are invalid. This error can be resolved by using AMIBIOS Setup. Wrong Predator Orion X-650 Desktop Computer Service Guide...
  • Page 133 Error code = 004Ah ROM. Unknown BIOS error. This message is displayed when language module is not present in the AMIBIOS8 Error code = 004Bh ROM. Floppy Controller Error in initializing legacy Floppy Controller. Failure Predator Orion X-650 Desktop Computer Service Guide...
  • Page 134 Blinking cursor only; system does not work. • IDE drive connection/cables • IDE disk drives • See “Undetermined Problems”. • Mainboard NOTE: Ensure the memory modules are installed properly and the contact leads are clean before diagnosing any system problems. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 135 • CD/DVD-ROM drive. NOTE: Make sure the optical disc drive is configured correctly in CMOS Setup, the cable/jumper are set correctly and the drive’s optical lens is clean before diagnosing any optical drive problems. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 136 • Missing, broken, or incorrect characters • Mainboard • Blank monitor (dark) • Blank monitor (bright) • Distorted image • Unreadable monitor Display changing colors. • Monitor signal connection/cable • Video adapter card • Mainboard Predator Orion X-650 Desktop Computer Service Guide...
  • Page 137 Windows Start menu does not turn off the • Reload software from Recovery CD. system. (Only pressing power button can turn off the system). No system power, or power supply fan is • Power supply not running. • Mainboard Predator Orion X-650 Desktop Computer Service Guide...
  • Page 138 • Setup Settings error, CMOS Damaged checksum error or CMOS battery loss occurs. • Default settings loaded System Ready All light on 3 sec Once OEM logo display and keyboard function are ready (Red, Yellow, White, Green Predator Orion X-650 Desktop Computer Service Guide...
  • Page 139 If the problem does not recur, reconnect the removed devices one at a time until you find the failed FRU. If the problem persists, replace the mainboard. Do not replace a non-defective FRU. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 140 The system will now execute the BIOS recovery process. You will hear a long beep followed by a short beep. Wait for the program to finish with the recovery. Press any key to reboot system. The BIOS recovery is now completed. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 141 During POST, press Delete to enter BIOS Setup Utility. If you fail to press Delete before POST is completed, you will need to restart the computer. Press F9 to Load Default Setting. Select OK to load default setting. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 142 Press F10 to Exit setup. Select SAVE & EXIT and press Enter. Select Yes to Restart. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 143 Go to the Security page, select Secure Boot and press Enter. Select Disabled to disable Secure Boot. Press F10 to Exit setup. Select SAVE & EXIT and press Enter. Select Yes to Restart. Press the F12 hot key to enter Boot Menu, then select USB thumbdrive. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 144 Choose the Removable BlockDevice group. The Removable BlockDevice location is dynamic. In the screen shot below, user should key in fs5: in Shell command line. Enter the “EFI” folder, then enter the “AFU” sub-folder Type flash_x64.nsh and press Enter to flash the ROMs Predator Orion X-650 Desktop Computer Service Guide...
  • Page 145 13. During POST, press Delete to enter BIOS Setup Utility. If you fail to press Delete before POST is completed, you will need to restart the computer. 14. Press F9 to Load Default Setting. Select OK to load default setting. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 146 15. Press F10 to Exit setup. Select SAVE & EXIT and press Enter. 16. Select Yes to Restart. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 147 13. During POST, press Delete to access the Setup Utility. 14. Press F9 to load the system default values. 15. Press F10 to save the changes you made and close the Setup Utility. Predator Orion X-650 Desktop Computer Service Guide...
  • Page 148 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 149 Chapter 5 System Architecture This chapter shows the block diagram and board layout of the Predator Orion X-650 Desktop Computer. Block Diagram The core subsystems of the Predator Orion X-650 computer are depicted in the following block diagram: Predator Orion X-650 Desktop Computer Service Guide...
  • Page 150 Front I/O header FAN3 4-Pin system fan header USB3F2 Key-A header (for portable SSD) FAN2 4-Pin CPU fan header CN6301 SSD BD connector FAN1 4-Pin system fan header PCIES1 PCI Express Gen5 x16 Slot Predator Orion X-650 Desktop Computer Service Guide...
  • Page 151 Chapter 6 Field Replaceable Unit (FRU) List This chapter gives you the FRU (Field Replaceable Unit) listing of the Predator Orion X-650 Desktop Computer global configurations. Refer to this list when ordering for repair parts or for RMA (Return Merchandise Authorization).
  • Page 152 SSD Module KN.01K04.005 Power Supply Unit DC.85018.001 PSU Bracket 334.0GX0B.0001 Front I/O Bracket 360.0GX0A.0001 Front Bezel 360.0GX08.0001 Right Side Panel 360.0GX0D.0001 Thermal Module DC.10811.028 Rear I/O Shielding 360.0GX02.0001 Main Chassis 360.0GX05.0001 System Fan DC.10911.00P Predator Orion X-650 Desktop Computer Service Guide...
  • Page 153 POWER CORD 250V ARGENTINE BK 1.8M 27.SLSD1.002 POWER CORD 250V ISRAEL BK 1.8M 27.VEHD1.001 POWER CORD 250V ITALY BK 1.8M 27.VG6D1.001 CABLE 60MM SSD BOARD TO MAIN BOARD 50.E3SD1.001 CABLE SATA 380MM HDD TO MAIN BOARD 50.E3SD1.002 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 154 CPU Intel Core i7 13700F LGA 2.1 GHz 25M 3200 KC.13701.FI7 1700 65W B0 Alder Lake-S Cooler Master Predator FrostBlade 21Q2 12cm DC.10911.00P ARGB fan DF1202512RFUN Black frame 7 blades 8pcs ARGB Rifel bearing (sleeve) HEATSINK HEATSINK FOR SSD RIMAC 24.E3SD1.001 Predator Orion X-650 Desktop Computer Service Guide...
  • Page 155 Keyboard PRIMAX KBCY21 USB Polish support DK.USB1P.0M2 RGB, USB KB, brown box Keyboard PRIMAX KBCY21 USB Arabic/French DK.USB1P.0M3 support RGB, USB KB, brown box Keyboard PRIMAX KBCY21 USB Spanish Latin DK.USB1P.0M4 support RGB, USB KB, brown box Predator Orion X-650 Desktop Computer Service Guide...
  • Page 156 SCREW MECH TRUSS M3*L4 NI 86.3A534.4R0 SCREW,6-32X1/4,HEX,TF,ZPS,BLK 86.B9AD1.001 SCREW M2X4 KSH MS BLO NYLOK 86.BFZD1.001 SCREW TAP FLAT D5 L10 BLACK 86.E3SD1.001 SCREW WAFER M2*L3.5 BZN BH RP 86.E3SD1.002 SCREW MA HEX 6-32 L5 BLACK 3NOD 86.SR2D1.001 Predator Orion X-650 Desktop Computer Service Guide...
