- Page 1 USER EN ENGLISH MANUAL Manual in your TM8120 INFRARED THERMOMETER language? Check the back cover...
- Page 2 OVERVIEW DISPLAY DEVICE Environmental temperature 01 Alarm indicator Environmental humidity 02 LCD screen Dew temperature 03 Down button Surface temperature 04 Laser control button / Mode button Laser symbol “On” 05 Up button Temperature unit 06 Infrared sensor K-Type thermocouple 07 Laser light Measurement indicator 08 K-type thermocouple socket...
- Page 3 SAFETY FIRST TIME USAGE Please read the safety instructions provided as separate booklet Remove all protection foils. with the device. MEASUREMENT METHODS While the product is in operation, be careful not to expose your eyes to the emitting laser beam. Class 2 laser radiation, do not stare into beam! Remove all protection foils.
- Page 4 The alarm indicator [01] will indicate the probability of conden- · Insert the K-type thermocouple probe into the thermocouple sation moisture occuring. When there is no risk of condensation socket [08] of the thermometer the alarm indicator [01] will turn green. ·...
- Page 5 emissivity on measurement results. The measurement result will remain. · Press the mode button [04] three times to set the emissivity When holding the trigger [09], the instrument will display the setting mode maximum value of the measured temperature. The emissivity indication [I] area will flash. When the measured value is higher than the upper measure- ment limit, or less that the lower measurement limit, the red ·...
- Page 6 EMISSIVITY TABLE COPPER, ELECTRICAL TERMINAL BLOCKS NICKEL, OXIDIZED 0.2 - 0.5 COPPER, OXIDIZED 0.4 - 0.8 PAINT ADHESIVE TAPE 0.96 FERRO-NICKEL, ABRASIVE BLASTING 0.3 - 0.6 PAPER 0.70 - 0.99 ALUMINIUM PLATE 0.09 FERRO-NICKEL, ELECTRO POLISHING 0.15 PAPER, WHITE 0.68 ALUMINUM, A3003 ALLOY (OXIDIZED) FERRO-NICKEL, OXIDIZED 0.7 - 0.95...
- Page 7 TECHNICAL SPECIFICATIONS MODEL TM8120 DECLARATION OF CONFORMITY LCD screen Color LCD dispay Futech (Belgium) declares under its own responsibility that this device: 12:1 - TM8120 INFRARED THERMOMETER Emissivity 0.10 ~1.00 Response spectrum 8 -14 µm is in conformity with the standards...
- Page 8 USER MANUAL other languages: DANSK ITALIANO DEUTSCH NEDERLANDS ESPAÑOL NORSK EESTI KEEL PORTUGUÊS SUOMEN KIELI SLOVENŠČINA FRANÇAIS SVENSKA ÍSLENSKA Facebook @futechtools LinkedIn futechtools World Wide Web futech-easy.com YouTube @futechtools...
