- Page 1 TEMPVIEWER3600 MANUAL...
- Page 2 Congratulations! On choosing this FUTECH instrument. FUTECH provides measuring instruments of precision and quality. Contributions from professional end users enable us to offer innovative, easy-to-use equipment. TEMPVIEWER 3600 IMPORTANT! Read the instructions for use carefully before using the instrument. Keep them in a safe place for consultation when necessary.
- Page 3 TEMPVIEWER3600 MANUAL 27.3 °C 3810MB 0.95 18:55 Parts of housing Display Power / Menu button Battery compartment Selection / Enterbutton Micro SD card Navigation (, , ‘, ’) Infrared sensor Camera LED light 10. Record button 11. Thread 1/4” Menu Temperature unit (°C/°F)
- Page 4 How does an infrared thermometer work? Each object transmits infrared rays. The power of these rays depends on the type of material (expressed as “radiation coefficient” or “emissivity” of a material) and of course the temperature of the object. An infrared detector absorbs these rays and the ASPHALT 0,90 - 0,98 electrons in the device turn them into temperature (°...
- Page 5 TEMPVIEWER3600 MANUAL How big is the measuring area? The further you are of the object whose temperature you want to measure, the gre- ater the measurement area. The larger the measuring surface, the less the accuracy. We therefore recommend using the camera as close as possible to the objects to be measured.
- Page 6 / visual image. (See min. / Max. Value) ∙ To save images on the MicroSD card, aim the Tempviewer3600 on the surface to measure and press the “Recording key.” “Store photos yes no” will appear on the screen.
- Page 7 ∙ Press the “Power / Menu key” to exit the menu. a. - Unit (°C / °F) The Tempviewer3600 can measure in both °C and °F. To switch between these units, press the “Power / Menu key”. Move with the Navigation buttons ~ and € to the “Tem- perature Unit (°C / °F)”...
- Page 8 Here you can see how much MB is still available on the Micro SD card (if placed). d. - Color palette There are 5 different color settings for the thermal image on the Tempviewer3600. To set the preferred pallet press the “Power / Menu key”. Move with the Navigation but- tons ~ and €...
- Page 9 TEMPVIEWER3600 MANUAL h. - Date and time Stored images are provided with Date and Time. This can be set very easily via the menu. Press the “Power / Menu key”. Move with the Navigation buttons ~ and € To the “Date / Time Settings” (h) option and confirm with the “Select / Enter” key. Two lines of values appear on the screen.
-
Page 10: Limits Of Use
∙ Use of products with obviously recog- in hazardous areas, or in close proximity ∙ To inform FUTECH immediately if the nizable damages or defects. to electrical installations or similar sit- product and the application becomes ∙... - Page 11 TEMPVIEWER3600 MANUAL HAZARDS OF USE by lightning. international rules and regulations are WARNINGS ∙ Do not use the product in a thunder- observed. Before transportation or ∙ The person responsible for the product storm. shipping contact your local passenger must ensure that it is used in accord- ∙...
-
Page 12: Technical Information
-20°c ~ 50°c for service. Repairs carried out by unau- power supply 4x aa alkaline thorised personnel will automatically in- relative humidity 10% ~ 80%rh validate the guarantee. JOIN US Facebook @futechtools LinkedIn futech-tools World Wide Web futech-tools.com YouTube futech-tools...
