CCV A920 Quick Start Manual

CCV A920 Quick Start Manual

Telecash from fiserv
Hide thumbs Also See for A920:

Advertisement

Quick Links

Download this manual
Technical Document
A920 of TeleCash
From Fiserv
Quick start guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the A920 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CCV A920

Summary of Contents for CCV A920

  • Page 1 Technical Document A920 of TeleCash From Fiserv Quick start guide...
  • Page 2 A920 of TeleCash From Fiserv A920 ...............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 3 A920 of TeleCash From Fiserv A920 Introduction This is the user manual for the A920 terminal with the TeleCash from Fiserv app (TeleCash app) version 2.03.03. Product scope Terminal A920 4G Terminal Charging Cradle A920 A920 power adapter with power plug and micro-USB cable...
  • Page 4 A920 of TeleCash From Fiserv Printer flap lock Printer flap Rear camera (5 megapixels including barcode reader for 1D and 2D barcodes) Contact for charging cradle Accumulator/Battery SIM card slot (SIM card must be inserted into slot 1 [left]) Power plug with plugged-in...
  • Page 5 A920 of TeleCash From Fiserv Datasheet Dimensions (L x W x H) 175.7 x 78 x 55 mm 458 g Memory 2 GB RAM, 16 GB Flash (expandable up to 32 GB through micro SD) Printer Thermal printer paper roll: Ø 40mm...
  • Page 6 A920 of TeleCash From Fiserv Inserting thermal paper The thermal paper, printed on the back, is inserted at the top of the terminal. The paper tray is situated at the back of the top and can be opened by pulling on the latch (1). The pre-printed paper side (maximum size: 58 mm width, 40 mm diameter) should be loaded as shown in (3).
  • Page 7 A920 of TeleCash From Fiserv Start Upon booting up the terminal, the TeleCash app launches automatically. If there are additional apps to be installed on the terminal, close the TeleCash app and open the CCVStore. Start screen App version Start area...
  • Page 8 A920 of TeleCash From Fiserv Standard payment process 1. The payment process is initiated by tapping on the TeleCash logo or the starting area. 2. The amount to be paid is entered through the numeric keypad. The cent amounts should be entered without a comma.
  • Page 9 A920 of TeleCash From Fiserv Amount entry screen/interface Amount display Digit input pad Okay button Cancel button Delete button Amount display: Displaying the amount entered Digit input pad: Enter keys for entering amounts (without comma) Cancel button: Cancels the transaction process...
  • Page 10 A920 of TeleCash From Fiserv History With the history button on the home page or through the Softkeys button in the revenue tab, the transaction history of the terminal can be viewed. There are options of printing a copy of the receipt or cancelling a transaction for each entry.
  • Page 11 A920 of TeleCash From Fiserv Void (Cancellation) To cancel a transaction, the “Void” function can be selected in the VAS tab. After inputting the cashier’s password, the “Transaction ID” must be entered. The “Transaction ID” , printed as “TA-No. ” on the merchant or customer receipt, is required.
  • Page 12 100,000 customers in a wide range of industries and sales channels. Other useful functions and explanations can be found in the A920 user manual. This can be found in the TeleCash Download Center on our website: telecash.de/service/downloads If you have any further questions, please do not hesitate to contact us by email or by phone! Regardless of the duration of the call, €0.20 from German landlines and...
