RESISTANCE CHART "M" SERIES EXCITER TYPE
KW
17.5
Main Stator
Less Than 1.0
Ohm / Phase
Main Rotor
2.00
Exciter Stator
23.0 – 28.0
Exciter Rotor
0.655 – 0.720
Aux. Winding
1.0 – 1.4
120 / 240 VOLT CONNECTION "M" SERIES EXCITER TYPE
20
Marks
Less Than 1.0
T1-T2 T3-
Ohm / Phase
T4
2.10
N/A
23.0 – 28.0
F+ – C
0.655 – 0.720
N/A
1.0 – 1.4
E1 – E4
Color
Black / Black
N/A
Black / Black
N/A
Black / Black
