Toto TX403MMD Manual

(BUBBLE & SPRAY), W/ AUTO STOP VALVE (CHROME)
SPECIFICATIONS
Flex. Hose
L = 1200
68
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75 MPa.
2. Ensure that water supply is clean
( No Sand, Dirt, Etc.).
ATTENTION
Don't use abrasive cleaners or solvents on faucets
1.
and fittings.
2.
As the product model is constantly updated, the
actual product may not look the same as it shown
in the diagram, but the basic installation principles
are the same.
3. Make sure the shower spray is pressed down
to ensure the valve is closed
4. Flow Regulator should not be discarded because it
could damage the system.
S060534Z
LUXURY METAL 2 MODE SHOWER SPRAY
INSTALLATION
1.
Use Seal Tape
(Not Include)
G½
2.
*Tigthen the nut by hand
35
Water Supply
Cover
Water Outlet
Shower Spray
Packing
Nut*
Flexible Hose
Packing
Nut*
TX403MMD
TROUBLESHOOTING
CHECK
PROBLEM
POINT
Water leaks around the body 1
Water leaks around the hose 2, 3
2.NUT
3. NUT
MAINTENANCE
All Finishes : Clean the finish with mild soap and
warm water. Wipe entire surface completely dry with
clean soft cloth. Many cleaners may contain
chemicals, such as ammonia, chlorine, toilet cleaner
etc. which could adversely affect the finish and are
not recommended for cleaning
SOLUTION
Tighten
Tighten
Flow Regulator Inside
(Don't remove)
1. VALVE
R5
