- Page 1 Translated from German to English - www.onlinedoctranslator.com stone cutting machine STM 450-700 Art. No.: STM450-700 original operating instructions stone cutting machine STM 450-700 www.lumag-maschinen.com...
- Page 2 DANGER! When delivered, the device does not contain any engine oil. Graphics, images, texts and layouts created by LUMAG GmbH are subject to copyright and the laws protecting intellectual property. Reproduction or use of such graphics, images, texts and layouts in other electronic or printed publications is not permitted without the express consent of LUMAG GmbH.
- Page 3 TABLE OF CONTENTS TABLE OF CONTENTS Table of contents Intended use Safety instructions General safety instructions Special safety instructions Residual risks Symbols used controls assembly and installation scope of delivery Select installation location Unfold the feet Install the extension of the cutting head swivel device Install the roller carriage Install the longitudinal stop Install the water pump...
- Page 4 SAFETY INSTRUCTIONS INTENDED USE The LUMAG stone cutting machine STM 450-700 is a versatile, stationary and robust machine tool. The device is suitable for fast and clean cutting (with the appropriate diamond cutting disc) of tiles, stoneware, bricks, natural and hard stone, general construction site materials and similar abrasive building materials.
- Page 5 SAFETY INSTRUCTIONS - Do not let other people, especially children, touch the power tool or cord. Keep them away from your work area. 5. Store unused power tools safely - When not in use, power tools should be stored in a dry, high or locked place, out of the reach of children.
- Page 6 SAFETY INSTRUCTIONS - Keep handles dry, clean and free from oil and grease. 15. Unplug the appliance - When the power tool is not in use, before maintenance and when changing tools such as cutting discs, saw blades, drills, milling cutters. 16.
- Page 7 SAFETY INSTRUCTIONS Special safety instructions for stone cutting machines • Before use, place the stone cutting machine on a level and stable work surface. Ensure there is sufficient freedom of movement. • Always ensure there is adequate lighting when working with the machine. •...
- Page 8 SAFETY INSTRUCTIONS • Replace faulty diamond cutting discs immediately. Deformed or cracked cutting discs must not be used. • Only use diamond cutting discs recommended by the manufacturer that comply with EN 13236. The use of saw blades is prohibited. •...
- Page 9 SAFETY INSTRUCTIONS residual risks Even when used as intended, the following residual risks may still occur: – Risk of injury to fingers and hands from the rotating tool. – Injuries caused by workpieces being thrown away due to improper posture or guidance.
- Page 10 SYMBOLS USED SYMBOLS USED Danger of cuts!Never Danger! reach into the work area during operation. Before commissioning the Wear hearing protection Read the manual Wear protective gloves Wear eye protection wear a dust mask Wear safety shoes Warning of hot surface! Danger high voltage, of burns! Danger to life!
- Page 11 CONTROLS CONTROLS 10. Plug for water tray 1. Blade protective cover with cooling water connections 2. On / off switch 11. Carrying handle 12. Stand, foldable 3. Handle on the cutting arm 13th guide rail 4. Cutting head unit 14. Machine frame 5th drive motor 6.
- Page 12 ASSEMBLY AND INSTALLATION ASSEMBLY AND INSTALLATION Unpack the machine and check all parts for transport damage before assembling. If any damage has occurred, this must be reported immediately upon delivery. Check that the delivery is complete. Inform the seller immediately of any missing parts. Lay out all parts on a flat surface.
- Page 13 ASSEMBLY AND INSTALLATION unfold the feet 1. Loosen the screws on the feet slightly. 2. Carefully lift the frame of the stone cutting machine and first fold up the two rear and then the two front feet (under the cutting head unit). Make sure the feet are in the right position! The feet spread out towards the ground.
- Page 14 ASSEMBLY AND INSTALLATION Install the longitudinal stop 1. Place the longitudinal stop (15) on the stop rail with measuring scale (7) on the roller carriage (6). 2. Adjust the longitudinal stop (15) at the appropriate distance from the cutting disc (16). 3.
- Page 15 COMMISSIONING COMMISSIONING Read the safety instructions carefully (see safety instructions). • All covers and safety devices must be properly installed before operation. • The diamond cutting disc must be checked to ensure it is firmly seated and running smoothly. • Check the water hoses from the pump to the water control valve and the blade protection cover.
- Page 16 COMMISSIONING safety devices * Sheet protection The blade guard (1) protects against contact with the diamond cutting disc (16) and against dangerous parts being thrown out that may be created during cutting. The blade guard (1) must always be fitted during operation. * For your safety The stone cutting machine is equipped with a PRCD plug as standard.
- Page 17 OPERATION Lay the power cable so that it cannot be damaged during work. Protect the power cable from heat, aggressive liquids and sharp edges. Only use extension cables with a sufficient cross-section. Do not pull the power cord to unplug the appliance. A notice: First of all - after switching on the saw - pay attention to the direction of rotation of the diamond cutting disc.
- Page 18 OPERATION DANGER! The water pump starts automatically when the drive motor is switched on! You can regulate the water flow to the diamond cutting disc using the shut-off valve (18). Preparing for cutting 1. Stand in front of the stone cutting machine. 2.
- Page 19 OPERATION Cutting with undetermined cutting depth To make cutting deeper cuts easier, we recommend using an unlocked cutting depth. This puts less strain on the motor and protects the diamond cutting disc. During this cut, the workpiece is moved back and forth with the roller carriage under the unlocked cutting head.
- Page 20 MAINTENANCE AND CARE MAINTENANCE AND CARE Before all maintenance and cleaning work: – Switch off the machine. – Wait until the diamond cutting disc comes to a standstill. – Unplug the power cord. Only use original parts as spare parts, especially for safety devices and cutting tools. Parts that have not been tested and approved by the manufacturer can lead to unforeseeable damage.
- Page 21 MAINTENANCE AND CARE 4. Hold the cutting shaft with the supplied mandrel and loosen the clamping nut with the open-end wrench (included).Left-hand thread! Remove the clamping nut, the pressure flange and carefully the diamond cutting disc (16). 5th Fig. 3 Before installing the new diamond cutting disc (16), clean the cutting shaft and the blade flange with a cloth or brush.Danger! Do not use cleaning agents that may damage the components.
- Page 22 MAINTENANCE AND CARE cleaning the machine • Before carrying out any work on the device, unplug the power cord. • Fix the cutting head (see "cutting disc change" , point 2). • If the machine is used continuously, clean the tub and the deposited sludge at least 3 times a day.
- Page 23 MAINTENANCE AND CARE – Lock the cutting head unit (4) – Empty the water pan (9) and cooling system – Fig. 1-4 Loosen the screws on the support feet and fold them in as shown. First fold in the support feet under the cutting head unit. See also the illustration directly on the frame on the machine.
- Page 24 MAINTENANCE AND CARE NOTE ON ENVIRONMENTAL PROTECTION electrical system Work on the electrical equipment of the machine may only be carried out by a qualified electrician. Switch Protection- switch Motor distributor pump NOTE ON ENVIRONMENTAL PROTECTION Old electrical devices are recyclable materials and therefore do not belong in household waste! We would therefore like to ask you to support us with your active contribution to conserving resources and protecting the environment and to hand this device in to the collection...
- Page 25 COMPONENTS OF THE MACHINE COMPONENTS OF THE MACHINE...
- Page 26 TROUBLESHOOTING TROUBLESHOOTING Before any troubleshooting: – Switch off the device. – Unplug the power cord. There is no power reaching the machine. Check power supplier and supply line. Engine does not start: Engine switches during The motor switches off due to Wait until the engine has cooled down (5-10 the work: overload, e.g.
- Page 27 TECHNICAL DATA MAINTENANCE AND CARE TECHNICAL DESCRIPTION TECHNICAL DATA STM 450-700 Model name: 230 V ~ 50 Hz Operating voltage: 2000 W - S6 40% Engine power: 9.0 A Operating current: Protection class: IP 54 Protection class: Weight: 92 kg...
- Page 28 LUMAG guarantees impeccable quality and, without prejudice to the statutory warranty, provides a guarantee in the event of material or manufacturing defects. The guarantee for LUMAG products is 24 months for exclusively private use, and 12 months for commercial or professional use or rental, from the date of delivery.
- Page 29 Please clearly label the shipping box with the SERVICE NUMBER to ensure quick identification. Warranty work is carried out exclusively by our LUMAG service workshop. Defects that occur within the warranty period due to material or manufacturing defects must be remedied by repair if they have occurred despite proper use and care of the device.
- Page 30 Fax: 0049 / (0)8571 / 92 556-19 that the product Designation: stone cutting machine STM 450-700 Device type: meets the essential protection requirements of the above-mentioned EC directives. Conformity is based on the following standards: EN 12418/A1:2009, EN 61029-1/A11:2010, ZEK 01.4-08 EN...
- Page 31 NOTE...
- Page 32 LUMAG GmbH Robert-Bosch-Ring 3 D-84375 Kirchdorf am Inn Telephone: +49 (0)85 71 / 92 556 - 0 Fax: + 49 (0)85 71 / 92 556 - 19 Status: 09/2014 - STM450-700v2...
