Translated from German to English - www.onlinedoctranslator.com
stone cutting machine STM 350-800
Art. No.: STM350-800
D
operating instructions
2
stone cutting machine
PL
Instructions for use
26
fireplace stove
NL
user manual
50
stone sawing machine
www.lumag-maschinen.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Lumag STM 350-800
Summary of Contents for Lumag STM 350-800
- Page 1 Translated from German to English - www.onlinedoctranslator.com stone cutting machine STM 350-800 Art. No.: STM350-800 operating instructions stone cutting machine Instructions for use fireplace stove user manual stone sawing machine www.lumag-maschinen.com...
- Page 4 1. Blade protective cover 10. Stopper 2. On / off switch 11th guide rail 3. Handle on the cutting arm 12. Carrying handle 4. Cutting head unit 13. Stand 5th drive motor 14. Machine frame 6. Roller carriage with rubber pad 15.
- Page 5 TABLE OF CONTENTS TABLE OF CONTENTS Illustration of the controls Table of contents Intended use Safety instructions General safety instructions Special safety instructions Residual risks Symbols used controls assembly and installation scope of delivery Installing the feet Install the extension of the cutting head swivel device Install the roller carriage Install the longitudinal stop Install the water pump...
- Page 6 SAFETY INSTRUCTIONS INTENDED USE The LUMAG stone cutting machine STM 350-800 is a versatile and robust machine tool. The device is suitable for fast and clean cutting (with the appropriate diamond cutting disc) of tiles, stoneware, bricks, natural and hard stone, general construction site materials and similar abrasive building materials.
- Page 7 SAFETY INSTRUCTIONS 4. Keep other people away - Do not let other people, especially children, touch the power tool or cord. Keep them away from your work area. 5. Store unused power tools safely - When not in use, power tools should be stored in a dry, high or locked place, out of the reach of children.
- Page 8 SAFETY INSTRUCTIONS - Check extension cords regularly and replace them if they are damaged. - Keep handles dry, clean and free from oil and grease. 15. Unplug the appliance - When the power tool is not in use, before maintenance and when changing tools such as cutting discs, saw blades, drills, milling cutters.
- Page 9 SAFETY INSTRUCTIONS Special safety instructions for stone cutting machines • Before use, place the stone cutting machine on a level and stable work surface. Ensure there is sufficient freedom of movement. • To avoid the risk of dust, the machine may only be used in wet areas. This is also essential because the diamond cutting disc is only suitable for wet cutting.
- Page 10 SAFETY INSTRUCTIONS • Replace faulty diamond cutting discs immediately. Deformed or cracked cutting discs must not be used. • Only use diamond cutting discs recommended by the manufacturer that comply with EN 13236. The use of saw blades is prohibited. •...
- Page 11 SAFETY INSTRUCTIONS SYMBOLS USED - Injuries caused by breakage or ejection of the diamond cutting disc or a faulty diamond attachment. - Injuries caused by touching live parts when electrical components are open or defective. - Impairment of hearing when working for long periods without hearing protection. Residual risks can be minimized if the "Intended Use"...
- Page 12 CONTROLS ASSEMBLY AND INSTALLATION CONTROLS (Figure 1, page 2) 10. Plug for water tray 1. Blade protective cover with cooling water connections 2. On / off switch 11. Carrying handle 12. Stand 3. Handle on the cutting arm 4. Cutting head unit 13th guide rail 5th drive motor 14.
- Page 13 ASSEMBLY AND INSTALLATION However, when setting up and connecting the machine, please observe the following instructions and the general safety regulations. Due to its heavy weight, it is recommended that only two people carry the machine. Select installation location The machine must be set up securely and secured against slipping. Make sure there is enough space to operate the machine safely.
- Page 14 ASSEMBLY AND INSTALLATION COMMISSIONING Mount the roller carriage (Figure 4) • Place the roller carriage (cutting table) (6) on the roller table guide rail (13) with the frame of the two right-hand guide rollers enclosing the guide rail. Simply place the two left-hand guide rollers onto the guide rail. •...
- Page 15 COMMISSIONING • The diamond cutting disc must be checked to ensure it is firmly seated and running smoothly. • Check the water hoses from the pump to the water control valve and the blade protection cover. • Fill the water tray with clean water. The pump must be completely submerged. •...
- Page 16 COMMISSIONING * Overload protection If the motor heats up too much, the overload protection is activated. The stone cutting machine switches off automatically. Wait about 15 minutes until the motor has cooled down. Start the machine again by pressing the green switch. Attention! Mains connection Do not connect the machine to the power supply until all test steps have been carried out.
- Page 17 OPERATION OPERATION Read the safety instructions carefully (see safety instructions). The stone cutting machine may only be operated by one person. Other people must keep a sufficient distance from the machine. Power On/Off (Figure 8) Power • Open the yellow cover with the red “EMERGENCY STOP button” (F) at the side and press the green switch (D).
- Page 18 OPERATION • Place the workpiece to be cut on the roller carriage (6) and place the stationary cutting disc (16) with a full segment loosely on the workpiece. • Pull the workpiece back with the roller carriage (6) until you can lower the diamond cutting disc (16) slightly.
- Page 19 MAINTENANCE AND CARE MAINTENANCE AND CARE Before all maintenance and cleaning work: - Switch off the machine. - Wait until the diamond cutting disc comes to a standstill. - Unplug the power cord. Only use original parts as spare parts, especially for safety devices and cutting tools. Parts that have not been tested and approved by the manufacturer can lead to unforeseeable damage.
- Page 20 MAINTENANCE AND CARE the open-end wrench (included in delivery) the clamping nut.Left-hand thread! Remove the clamping nut, the pressure flange and carefully the diamond cutting disc (16). 5. Before installing the new diamond cutting disc (16), clean the cutting shaft and the blade flange with a cloth or brush.Danger!Do not use cleaning agents that may damage the components.
- Page 21 MAINTENANCE AND CARE swivel segments. • The water pump (8) is largely maintenance-free. • The diamond cutting disc (16) is largely maintenance-free. If the cutting performance decreases, the cutting disc can be resharpened by making a few cuts in sandstone or similar material. Check the cutting discs for wear and damage before each use.
- Page 22 MAINTENANCE AND CARE electrical system Work on the machine’s electrical equipment may only be carried out by a qualified electrician. Switch Protection- switch Motor distributor pump...
- Page 23 COMPONENTS OF THE MACHINE...
- Page 24 TROUBLESHOOTING TROUBLESHOOTING Before any troubleshooting: - Switch off the device. - Unplug the power cord. There is no power reaching the machine. Check power supplier and supply line. Engine does not start: Engine switches during The motor switches off due to Wait until the engine has cooled down (5-10 the work: overload, e.g.
- Page 25 TECHNICAL DATA ENVIRONMENTAL PROTECTION TECHNICAL DATA STM 350-800 Model name: 230 V ~ 50 Hz Operating voltage: 2000 W - S6 40% Engine power: 8.0 A Operating current: Protection class: IP 54 Protection class: Weight: 92 kg Dimensions (L x W x H):...
- Page 26 WARRANTY / CUSTOMER SERVICE WARRANTY / CUSTOMER SERVICE warranty The statutory warranty period is 2 years from the date of purchase. In the event of any defects in the product, please contact our customer service directly. For this purpose, we recommend that you carefully keep your purchase receipt. The warranty is provided in such a way that defective parts will be repaired or replaced with flawless parts free of charge at our discretion.
- Page 27 NT G SU E N RD EN GG E EG-KONFW K LPÄFRLU OARRMTIU veterinarian EC DECLARATION OF CONFORMITY In accordance with the provisions of the EC directives - Electromagnetic Compatibility 2004/108/EC - Low Voltage Directive 2006/95/EC - Machinery Directive 2006/42/EC the company explains: LVG Hartham GmbH Robert-Bosch-Ring 3...
- Page 30 LVG Hartham GmbH Robert-Bosch-Ring 3 D-84375 Kirchdorf am Inn Phone: + 49 (0)85 71 / 92 556 - 0 Fax: + 49 (0)85 71 / 92 556 - 19...
