- Page 1 AIR CONDITIONING SYSTEMS PORTABLE • USER’S MANUAL MODELS: CLCO290-09 CLCO290-09BS CHLCO-09WK ENGLISH...
- Page 2 |Contents Safety Precautions ..............................3 Cautions ...................................4 Warnings (for using R290/R32 refrigerant only) ...................5 Preparation ................................10 Installation ................................11 Operation ................................14 LED display ................................15 Operation ................................16 Maintenance ............................... 17 Troubleshooting ..............................18 Design and Compliance Notes ........................19 Sociable Remark ..............................
- Page 3 |Safety Precautions WARNING: “Safety Hazard Symbol”, it is very important to please pay close attention to the below, to avoid any serious injury. WARNING: To avoid any serious injuries or possible unit damage, please read carefully and follow the below safety guidelines: - The installation of this unit must be according to this manual, as improper installation may cause water leakage, electrical shock or even a fire.
- Page 4 |Cautions CAUTIONS -This appliance can be used by children aged from 8 years and ^ above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 5 |Warnings (for using R290/R32 refrigerant only) -Do not use any other means other than the recommended to expedite the defrosting process or to perform a cleaning of the unit, other than those recommended by the manufacturer. - This device should never be stored in an area in combination with other ignition sources (for example: a gas appliance an electrical heater, open flames etc.) - Do not attempt to penetrate the unit with a tool or try to burn - Be extra cautious as refrigerant gas may be odorless.
- Page 6 |Warnings (for using R290/R32 refrigerant only) 1. Transport of equipment containing 6) No ignition sources flammable refrigerants See transport Work that is in relation to a refrigeration regulations system which involves exposing any pipe works 2. Marking of equipment using signs See local that contains or has contained flammable regulations refrigerant gases should be carried out be...
- Page 7 |Warnings (for using R290/R32 refrigerant only) The repair and the maintenance to the electrical are the only type that can be worked on, while components must include safety checks and live in the presence of flammable atmosphere. also component inspection procedures. If The test apparatus should be at the correct there is any fault, that may compromise the rating.
- Page 8 |Warnings (for using R290/R32 refrigerant only) in order to make any repairs or for any other OFN. The system must also be leak tested purposes, conventional procedures should on completion of charging but prior to be applied. However, it is strongly suggested commissioning.
- Page 9 |Warnings (for using R290/R32 refrigerant only) de-commissioned and emptied of refrigerant. is drained from a system, it shall be carried out The label must be dated and signed. Ensure safely. that there are labels on the equipment stating the equipment contains flammable refrigerant. Important Note Regarding Fluorinated 16.Recovery Gasses...
- Page 10 |Preparation control panel handle horizontal louver control (both sides) lever (adjust manually) air filter (behind the grille) vertical louver control upper lever (adjust manually) air intake drain outlet air outlet panel lower air intake bottom tray drain outlet Caster Front rear...
- Page 11 |Installation Choosing The Right Location -The air conditioner should be placed on sturdy grounds to minimize noise and vibration. For safe and secure positioning, place the unit on a smooth, level floor strong enough to support the unit. -The unit must be placed near a properly rated grounded outlet.
- Page 12 |Installation Europe Part Description Quantity Part Description Quantity Unit Adaptor 1 pc Bolt 1 pc Exhaust Hose 1 pc Security Bracket and Screw 1 set Drain Hose 1 pc Window Slider Adaptor 1 pc Wall Exhaust Adaptor A Foam Seal C (Non-adhesive) 1 pc 1 pc (only for wall installation)
- Page 13 |Installation Note: Once the Exhaust Hose assembly and Type 2: Wall Installation (optional) Adjustable Window Slider are prepared, choose 1.Cut a 125mm (4.9inch) hole into the wall from one of the following installation methods. for the Wall Exhaust Adaptor B. 2.Secure the Type 1: Hung Window or Sliding Window Wall Exhaust Adaptor B to the wall using the Installation(optional)
- Page 14 |Operation Control panel NOTE: The unit that you have purchased may look similar to one of the following:...
- Page 15 |Operation MODE button Exhaust hose installation Choose the desired operating mode. By The exhaust hose and its adaptor should be pressing the MODE button each time installed or removed according to the usage an operation is selected in the following mode.
- Page 16 |Operation Other features Water drainage SLEEP/ECO operation When under dehumidifying mode, remove the This feature can be activated with the use of drain plug for the back of the unit and install the the remote control only. When SLEEP mode is drain connector (5/8 universal female mender) activated the set temperature will increase by with a 3/4 hose (may be purchased locally).
- Page 17 |Maintenance Clean the Unit WARNING: Use a damp lint-free cloth to clean the unit -Be sure to unplug the unit before cleaning or enclosure. Dry with a clean and lint free cloth servicing cloth. -DO NOT use flammable liquids or chemicals to clean the unit.
- Page 18 |Troubleshooting Please refer to the below prior to contacting customer support. Problem Possible Cause Troubleshooting P1 Error Code The Water Collection Tray is full. Turn off the unit, drain the water from the Water Collection Tray and restart Unit does not turn on when the unit.
- Page 19 17-35°C (62-95°F) 13-35°C (55-95°F) NOTE: To be in compliance EN 61000-3-11, the product CLCO290-09 / CLCO290-09BS /CHLCO-09WK shall be connected only to a supply of the system impedance: | Zsys|=0.437 ohms or less, Before connect the product to public power network, please consult your local power supply...
- Page 20 |Sociable Remark When using this unit in the European countries, the following information must be followed: DISPOSAL: Do not dispose this product as unsorted municipal waste. This appliance requires special treatment for disposal. It is prohibited to dispose of this appliance in domestic household waste. There are several possibilities for disposal: A.
- Page 21 Postal Code* Invoice Number* Phone Number* Additional Details E-mail* Subscribe to Inventor's Newsletter * Required field With the current warranty card you accept the terms and conditions. SEND once the warranty submission has been completed a confirmation message will be þ...
- Page 22 AIR CONDITIONING SYSTEMS PORTABLE v 1.1...
- Page 23 AIR CONDITIONING SYSTEMS REMOTE CONTROLLER • USER’S MANUAL MODEL: CLCO290-09 CLCO290-09BS CHLCO-09WK ENGLISH...
- Page 24 CONTENTS Remote control specifications ..............2 Function buttons ..................3 Using the remote control ................4 Remote LED screen indicators ..............5 How to use the basic functions ..............6 How to use the advanced functions ............13...
- Page 25 Remote Control Specifications Model RG57H(B)/BG(C)E;RG57H1(B)/BG(C) E;RG57H2(B)/BG(C)EF;RG57H3(B)/ BG(C)EFU1; RG57H3(B)/BG(C)EF; RG57H1 (B)/BG(C)E-M; RG57H(B)/ BG(C)EU1; RG57H4(B)/BG(C)EFU 1; RG57H (B)/BGC E-M; RG57H (B)/BGC EU1 -M Rated Voltage 3.0V(Dry batteries R03/LR03X2) Signal Receiving Range Environment -5°C~60°C(23°F~140°F) O N /OF F S HO R T O N /OF F S HO R T O N /OF F S HO R T...
- Page 26 Function Buttons Before you begin using your new air conditioner, make sure to familiarize yourself with its remote control. The following is a brief introduction to the remote control itself. For instructions on how to operate your air condi- tioner, refer to the How to Use Basic Functions section of this manual. ON/OFF SHORT CUT Turns the unit on or off.
- Page 27 Using The Remote Control TIPS FOR USING REMOTE CONTROL NOT SURE WHAT A FUNCTION DOES? • The remote control must be used within 8 me- Refer to the How to Use Basic Functions and ters of the unit. How to Use Advanced Functions sections of •...
- Page 28 Remote LED Screen Indicators Transmission Indicator Lights up when remote sends a signal to the unit ON/OFF display Appears when the unit is turned MODE display on, and disappears when it is Displays the current turned off mode, including: • AUTO TIMER ON display TIMER OFF display •...
- Page 29 How To Use The Basic Functions SETTING TEMPERATURE The operating temperature range for units is 17-30°C (62oF-86°F). You can increase or decrease the set temperature in 1°C (1°F) increments. AUTO operation O N /O F F S HO R T C U T In AUTO mode, the unit will automatically select the COOL, FAN, HEAT or DRY mode Dased on the...
- Page 30 How To Use The Basic Functions DRY operation (dehumidifying) 1. Press the MODE button to select DRY mode. 2. Setyour desired temperature using the Temp▲ orTemp ▼ button. 3. Press the ON/OFF button to start the unit. NOTE: FAN SPEED can t be changed in O N /O F F S HO R T C U T...
- Page 31 How To Use The Basic Functions HEAT operation (Not available) 1. Press the MODE button to select HEAT mode. 2. Setyour desired temperature using the Temp ▲ or Temp ▼ button. 3. Press the FAN button to select the fan speed: AUTO, LOW, MED, or HIGH.
- Page 32 Setting the TIMER function Your air conditioning unit has two timer-related func- tions: TIMER ON- sets the amount of time when the unit will automatically turn on. TIMER OFF- sets the amount of time when the unit will automatically turn off. TIMER ON TIMER ON TIMER ON function...
- Page 33 TIMER OFF function The TIMER OFF function allows you to set a time when the unit will automatically turn off, such as NOTE: When setting the TIMER ON or TIMER when you wake up. OFF functions, up to 10 hours, the time will in- crease in 30-minute increments with each press.
- Page 34 Setting both TIMER ON and TIMER OFF at the same time Keep in mind that the time periods you set for both functions refer to hours after the current time. For exam- ple, say that the current time is 1:00 PM, and you want the unit to turn on automatically at 7:00 PM. You want it to operate for 2 hours, then automatically turn off at 9:00 PM.
- Page 35 Example: Setting the unit to turn on after 6 hours, operate for 2 hours, and then turn off (see the figure below) Your remote display T imer on Timer is set to turn ON 6 hours from current time T imer off Timer is set to turn OFF 8 hours from current time Timer starts...
- Page 36 How To Use The Advanced Functions SLEEP Function The SLEEP function is used to decrease energy use while you sleep (if you don’t need the same temperature settings to stay com- fortable). This function can only be activated via remote control. Note: The SLEEP function is not available in FAN or DRY mode.
- Page 37 NOTE: - Button design is based on a typical model and might be slightly different from the actual one you purchased. - The unit can complete all the functions described. If the unit does not have the feature then the corre- sponding button on the remote control will not work.
- Page 38 AIR CONDITIONING SYSTEMS REMOTE CONTROLLER...
