FLYFINE FAB10240-5K User Manual

Single phase hybrid all in one ess
Hide thumbs

Advertisement

Quick Links

Download this manual
User Manual
Single Phase Hybrid All In One ESS
FAB10240-5K / FAB20480-6K
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the FAB10240-5K and is the answer not in the manual?

Questions and answers

Related Manuals for FLYFINE FAB10240-5K

Summary of Contents for FLYFINE FAB10240-5K

  • Page 1 User Manual Single Phase Hybrid All In One ESS FAB10240-5K / FAB20480-6K User Manual...
  • Page 2 Software Licenses the following requirements. It is prohibited to use data contained in firmware or software developed by FLYFINE, in part or in full, Possess knowledge of electronics, electrical wiring, and mechanical expertise, and be familiar with electrical for commercial purposes by any means.
  • Page 3 Contents Contents User Manual User Manual 1 Safety Instructions 5 Mechanical Mounting 1.1 Unpacking and Inspection 5.1 Safety during Mounting 1.2 Installation Safety 5.2 Location Requirements 5.2.1 Environment Requirements 1.3 Electrical Connection Safety 5.2.2 Carrier Requirements 1.4 Operation Safety 5.2.3 Angle Requirements 1.5 Maintenance Safety 5.2.4 Clearance Requirements 1.6 Disposal Safety...
  • Page 4 User Manual User Manual flyfine flyfine 1 Safety Instructions NOTICE Upon receiving the product, conduct a thorough inspection to verify the condition of the device's Before using please read all instructions and cautionary markings on the unit and this manual.
  • Page 5 User Manual User Manual flyfine flyfine 1.5 Maintenance Safety DANGER There is a risk of high voltage inside the ESS that can be life-threatening. Please take note of the DANGER following precautions! Use specialized insulation tools during cable connections. There is a risk of ESS damage or personal injury resulting from incorrect service procedures! Follow and strictly adhere to the warning labels on the product and the safety instructions.
  • Page 6 User Manual User Manual flyfine flyfine 2 Product Description NOTICE 2.1 System Introduction In a TT utility grid, ensure that the N line voltage to ground is 30V or below. For off-grid applications, the utility grid must be a TN system.
  • Page 7 2.4 Hybrid Inverter The following table shows the dimensions of the ESS 2.4.1 LED Panel Model The LED panel with a display screen and an indicator is on the front of the inverter. FAB10240-5K 1300 FAB20480-6K 1900 Figure 2-3 LED Panel...
  • Page 8 User Manual User Manual flyfine flyfine 2.5.2 BMS Comm. Address WARNING After all wiring installation is complete, set up ID for each battery module. The ID code for each Please be aware that voltage may still be present in the AC side circuits even after the indicator is battery module MUST be unique.
  • Page 9 Compatible with monocrystalline silicon, polycrystalline PV strings Chart 1: Pack led indicate silicon, and thin-film modules without grounding. All in one ESS FAB10240-5K / FAB20480-6K Metering device Meter cupboard with power distribution system. Alarm Utility grid TT, TN-C, TN-S, TN-C-S...
  • Page 10 User Manual User Manual flyfine flyfine Energy Management during Daytime The energy management system defaults to self-consumption mode. The following scenarios illustrate the energy management process: Scenario 1: PV power generation > Load power consumption: - First,PV power is prioritized for the EPS loads first, followed by normal loads and then the battery.
  • Page 11 User Manual User Manual flyfine flyfine 3.2 Energy Conversion and Management 3.2.4 Reactive Power Regulation The ESS offers reactive power regulation modes to provide grid support. The specific reactive power The ESS efficiently transforms the DC power derived from either the PV array or the battery into AC regulation mode can be configured and adjusted through the SOLARMAN Smart App.
  • Page 12 User Manual User Manual flyfine flyfine 4 Unpacking and Storage 3.4.1 Charge Management EPS Charge Management 4.1 Unpacking and Inspection The purpose of the emergency charge management function is to safeguard the battery against The product undergoes comprehensive testing and rigorous inspection prior to shipment. However, damage resulting from prolonged excessive discharge.
  • Page 13 User Manual User Manual flyfine flyfine 4.2 Scope of Delivery Hybrid Inverter: Iterm Name Quantity Battery Module Battery Cable B+/B Top Bracket Mounting screws M4 Flat-head screws Base Fixed Connection Sheet Parallel communication line Iterm Name Quantity IM4 combination screw...
  • Page 14 User Manual User Manual flyfine flyfine The ESS, if it has a protection rating of IP65, can be installed both indoors and outdoors, providing flexibility in NOTICE choosing the mounting location. Install the ESS in a location that allows for easy electrical connection, operation, and maintenance. This will It is crucial to store the ESS in accordance with the specified storage requirements.
  • Page 15 User Manual User Manual flyfine flyfine 5.4 Moving the ESS 5.2.4 Clearance Requirements 300MM Allow ample clearance around the ESS to ensure When transferring the ESS to the installation location, please adhere to the subsequent guidelines: proper heat dissipation. Install the ESS at a suitable Maintain constant awareness of the ESS's weight.
  • Page 16 User Manual User Manual flyfine flyfine Step 2 Lay the battery pack flat, connect the base to the battery pack with 4 screws. Step 5 Similarly, fix the battery module 2 fixing bracket with M4 screws. Simultaneously install the accessories shown in the diagram (if purchasing a 10KWH energy storage system, step 3 requires...
  • Page 17 User Manual User Manual flyfine flyfine 6 Electrical Connection Step 7 Install the inverter bracket according to the position shown in the diagram and secure it with screws. Install the inverter onto the top of'the module 2 battery by pressing the positioning bracket position.
  • Page 18 User Manual User Manual flyfine flyfine 6.2 The battery module connects to the inverter Suggested cable requirement for AC wire 6.2.1 Preparation Before connecting the module to the module, it is necessary to check whether the battery module is in a shutdown state.
  • Page 19 User Manual User Manual flyfine flyfine Step 6: 6.4 PV Module (DC) Connection Make sure the wires are securely connected.The reference tightening torque is 0.6N.m NOTICE 1. Before connecting to PV modules, please install separately DC circuit breakers between ESS and PV modules.
  • Page 20 User Manual User Manual flyfine flyfine Prepare the cable and follow the connector assembly process: Step 5: ESS Communication Function： Strip one cable 8 mm on both end sides and be careful NOT to nick conductors. PV1- PV1+ DRM-COM PV2-...
  • Page 21 User Manual User Manual flyfine flyfine 7 Commissioning 7.4 Registration Go to SOLARMAN Smart and sign up. 7.1 Inspection before Commissioning Click on "Sign up" and create your account here. Please note that use an email address to register for anaccount.
  • Page 22 User Manual User Manual flyfine flyfine 7.6 Add a Logger step 2: Please wait for a few minutes. Afterward, click on "Done" to complete the setup and view the plant data. step 1: Manually enter the serial number (SN) of the logger.
  • Page 23 User Manual User Manual flyfine flyfine 7.9 Logger Status 7.9.1 Check Indicator light When the router is connected to the network normally, the stick logger should exhibit the following normal operation status: 1. Connection to the server succeeded: The NET light will remain illuminated after the logger is powered on.
  • Page 24 9.1 Technical Data Risk of burn injuries and electric shock! Model FAB10240-5K FAB20480-6K Do not come into contact with any internal live components until at least 10 minutes have elapsed after disconnecting the ESS from the utility grid and PV input.
