- Page 1 User Manual All In One Microgrid System 100KW215KWh-Pure Grid Connection / 100KW215KWh-Grid Connection+PV 100KW215KWh-Parallel Off Grid / 100KW215KWh-Parallel Off Grid+PV 100KW215KWh-PV+Load+GRID+GEN User Manual...
- Page 2 About This Manual Change History The manual primarily encompasses product information, along with installation, operation, Changes between document issues are cumulative, meaning that each subsequent document and maintenance guidelines. issue includes all the changes made in earlier issues. It will refer to the device as the "ESS" unless otherwise specified. V1.0 2024-06-24 Target Group...
-
Page 3: Table Of Contents
Contents Contents User Manual User Manual 1 Safety Instructions 5 Operation and Operation 1.1 Safety Symbol Description 5.1 Start Page 1.2 General Safety 5.2 Main Page 5.3 Alarm Page 1.3 Electrical Safety 5.3.1 Real-time Alarm 1.3.1. Wiring Requirements 1.3.2. Grounding Requirements 5.3.2 Historical Alarm 1.3.3. -
Page 4: Safety Instructions
Flyfine Flyfine User Manual User Manual 1 Safety Instructions Except for personnel operating the equipment, please do not approach the equipment, Do not power on the device until it has been installed or confirmed by aprofessional. At least two personnel must be present on site during the first power on or main circuit live operation. -
Page 5: Mechanical Safety
Flyfine Flyfine User Manual User Manual 1.4 Mechanical Safety Battery abnormal handling measures Danger: Pay attention to: The bottom enclosure must be removed without a wooden box fork, Take-off and landing should be handled lightly to In case of electrolyte leakage or abnormal smell, avoid contact with the leaking liquid or gas. Non-professionals do not avoid impact or vibration. -
Page 6: Product Function
Flyfine Flyfine User Manual User Manual 2.4. Product Characteristics 2.2 Product Function System productization, integrated energy storage battery, PCs, energy management and monitoring MonetSeries of outdoor energy storage cabinets integrated energy storage battery, modularPCS, Energy system, power distribution system, environmental control system and fire control system, etc, to fully management and monitoring system, power distribution system, environmental control system and fire control... -
Page 7: Part Introduction
Flyfine Flyfine User Manual User Manual 2.6 Part Introduction 2.6.3 Electrical System The outdoor cabinet energy storage system adopts a modular scheme, and users can configure different 2.6.1 Battery System numbers of power modules according to the project requirements. Power module parameters of the energy storage converter are as follows: Outside 2.2 Battery system parameters... -
Page 8: Environmental Control System
Flyfine Flyfine User Manual User Manual Table 2.5 STS Module Parameters Light storage for islands, mountainous areas, border posts and other remote areas or areas with unstable power supply, or new zero-carbon technology parks system. Users can configure the DC converter power module according to the project requirements to realize the power supply system integrating photovoltaic and energy storage. -
Page 9: Precision Air Conditioning Parameters
Flyfine Flyfine User Manual User Manual 2.6.4.1 Precision Air Conditioning Parameters 2.6.4.3 Water Immersion Detection Device The water immersion detection device detects whether there is any water leakage in theenergy storage Table 2.6 Precision air-conditioning parameters system. Outside 2.7 Immersion sensor parameters 2.6.4.4 Smoke Detector... -
Page 10: Fire Extinguisher System
fire extinguishing agent and ejected, realizing rapid fire extinguishing. Outside 2.10 Fire-fighting aerosol parameters Table 2.12.2 100KW215KWh-Parallel Off Grid+PV 2.6.6 EMS System An intelligent energy management system developed by ES system, mainly used in various capacity energy storage power stations and integrated solar energy storage and charging power stations. -
Page 11: Function Interface Description
Flyfine Flyfine User Manual User Manual 2.8 Function Interface Description Table 2.12.4 100KW215KWh-Grid Connection+PV Table 2.12.5 100KW215KWh-Pure Grid Connection The actual supply configuration shall prevail. -
Page 12: Installation And Wiring
Flyfine Flyfine User Manual User Manual 3.2 Packaging and Storage 3.2.1 Product Packaging In order to make the product in a better protective state during transportation, use a specific wooden box packaging. The following basic parameters are listed on the equipment package... -
Page 13: Preparation Before Installation
Flyfine Flyfine User Manual User Manual 3.5 Mechanical Installation The installation position is far away from the fire source. Do not place inflammable and explosive items around the equipment. lf the equipment is installed in a lush vegetation, in addition to routine weeding, the ground below the equipment needs tobe hardened to prevent weeds. - Page 14 Flyfine Flyfine User Manual User Manual 2) After removing the packing box, remove the bottom panel of the equipment first. There moved panels and screws shall be collected, and they shall be installed after the equipment is installed. 1458.5 1800...
-
Page 15: Electrical Cable Installation
Flyfine Flyfine User Manual User Manual 3.6 Electrical Cable Installation This product adopts an all-in-one machine structure, and the internal wiring on the DC side has been completed. On site, only electrical cables need to be installed on the AC side and external communication. -
Page 16: Boot And Debugging
Flyfine Flyfine User Manual User Manual 4 Boot and Debugging (4) Copper strip inspection: no obvious cracks or deformation in the copper strip, tighten the lap screws, no dislocation of the marking mark, and no debris on the copper strip. -
Page 17: Pilot Run
Flyfine Flyfine User Manual User Manual 5 Operation and Operation 4.3 Pilot Run After the installation of all electrical structures of the equipment meets the startup conditions, in order to This paper introduces the content of this manual. ensure the reliable and stable operation of the energy storage system, the initial operation must be powered up, and the operation mode and related parameters must be set according to the project requirements: The first level menu bar of ElS-access display screen is placed at the bottom of the display screen, and... -
Page 18: Main Page
Flyfine Flyfine User Manual User Manual 5.2 Main Page Figure 5-2-1 AC/DC data Figure 5-2 Main page As shown in the figure, the interface displays is divided into four columns: Status bar: At the top of the page, display contents include: operation mode,battery capacity, ambient temperature, system time. -
Page 19: Alarm Page
Flyfine Flyfine User Manual User Manual 5.3 Alarm Page 5.3.2 Historical Alarm Click the History button in the alarm page to jump to the historical alarm page, as shown in the figure. 5.3.1 Real-time Alarm Click the Alarm menu or click the real-time button in the Alarm page to jump to the real-time alarm page, as shown in the figure. -
Page 20: Data Page
Flyfine Flyfine User Manual User Manual 5.4 Data Page 5.4.1 Report Data Page Click the report button in the data page to jump to the report data page. The report data page contains four sub-pages, as shown in the figure:... -
Page 21: Expense Data Page
Flyfine Flyfine User Manual User Manual 5.4.2 Expense Data Page As shown in the figure, the statisticscontain 2 sub-pages: Daily report of electric energy expense: the bar chart of charge/discharge electric energy expense in the last Click the Data menu or click the fee button in the Data page to jump to the fee data page, as shown. -
Page 22: The Log On Page
Flyfine Flyfine User Manual User Manual 5.5 Settings Page This page requires active query of historical data. As shown in the figure, select the device and signal, select the start/stop period of historical data, click the query button, you can query a historical data information, the results are displayed in the table below, including equipment, semaphore, value, time. -
Page 23: Run The Policy Settings Page
Flyfine Flyfine User Manual User Manual 5.5.2 Run the Policy Settings Page Click the policy button in the Settings page to jump to the Run Policy Settings page, as shown in the picture. As shown in the figure, the Run policy page contains 4 run policies: (1 ) Peak-valley mode: Run according to the set peak-valley time period. -
Page 24: System Configuration Page
Flyfine Flyfine User Manual User Manual Figure 5-5-2-4 Schedule mode Figure 5-5-3-1 System Parameter Settings page Note 1: Charging and discharging periods cannot coincide. System parameters: Set the environment status of the system, such as IP address, system time, and user password. -
Page 25: Startup Page
Flyfine Flyfine User Manual User Manual Figure 5.3-2 Battery parameter setting page 5.5.4 Startup Page Figure 5-5-3-3 System Parameter Settings page Advanced functions Click the power button in the Settings page to jump to the Power on Settings page, as shown in the picture. -
Page 26: Maintenance Page
Flyfine Flyfine User Manual User Manual 5.5.5 Maintenance Page As shown in the figure, this page displays the sottware and hardware versions of the system and modules, as well as restoring factory Settings. Click the maintenance button in the Settings page to jump to the Maintenance page Settings page, If you need to restore factory Settings, click the button to restore factory Settings, and a password as shown in the picture. -
Page 27: System Upgrade
Flyfine Flyfine User Manual User Manual 5.7 System Upgrade 5.8 Password Authentication When you need to deliver commands, such as control Settings on the display, youneed to verify the Keyboard: for number, password entry. password. The verification result can be saved. lf the password has been verified, you do not need to enter the 1.008... -
Page 28: Advanced Settings
Flyfine Flyfine User Manual User Manual 5.10 Advanced Settings 5.10.3 Other Configuration Instructions Battery control indicates that no battery debugging is performed when no battery is connected to the The advanced configuration function requires professional technical personnel. To configure it, contact system by issuing battery control commands and determining no battery debugging according to battery technical support. -
Page 29: Wiring Instructions
Flyfine Flyfine User Manual User Manual Appendix 1: 8-inch EMS-ACCESS Interface Diagram 5.11 Wiring Instructions WiFi/Zigbee Audio LCD_TX LCD_RX 385_3B 485_3A DBG_RX DBG_TX extboard/tty_LCD UARTO extboard/tty_Printer 485_2B UART4 ttyO 电表 液晶屏 打印机 485_2A 485_1B UART2 ttyO2 模块 485_1A 232_TX 232_RX UART3 ttyO3 BT模块... -
Page 30: Warning And Maintenance
Flyfine Flyfine User Manual User Manual 6 Warning and Maintenance The alarm level is defined as follows: Fault: The equipment fails, and the system stops operation (charging/discharge). Alarm: the output power drops or partial function fails due to external factors, but it does not affect the charge and discharge function of the system. - Page 31 Flyfine Flyfine User Manual User Manual Warning: The above alarms and faults are common alarms or faults, if there is a table 6.1 lf any fault occurs, please contact the manufacturer directly.
-
Page 32: Routine Maintenance
Flyfine Flyfine User Manual User Manual 6.2 Routine Maintenance 6.3 Conformally Connected Space Due to the ambient temperature, humidity, dust, vibration, and the aging of the inverter internal components, 6.3.1 Defects liability Period some potential problems may occur during the operation of the system. In order to enable the energy storage...
