Summary of Contents for FLYFINE FP5000
- Page 1 User Manual 5kWh Mobile Energy Storage Generator Model: FP5000 User Manual...
- Page 2 User Manual Catalogs Preface Precautions Product Size Technical Parameters Steps for Usage Packaging, Transportation and Storage User Manual...
- Page 3 User Manual Preface Welcome to use the portable power statio FP5000. This short manual will help you. Please take the time to read this manual and use this product according to the instructions below. Just read through it once and you will fully understand how to use this product.
- Page 4 User Manual Product Size 337mm 292mm 543mm User Manual...
- Page 5 User Manual Technical Parameters Model: FP5000 Category ltems US Version EU Version 1680W/120V*14A AC input Power 3450W/230V 15A 2160W/240V*9A PV Input Power(Max.) 3000W MPPT Voltage Range 30V-150V Input PV Input Current(Max.) 3000W(Single Phase) EV Input Power(Max.) 5000W 5000W(Split Phase) AC Input Power 5000W(Max.);...
- Page 6 User Manual Cooling Method Air Cooling Certificate UN38.3,MSDS,UL UN38.3,MSDS,CE The system Weight 70±3KGs Dimensions (W*D*H) 543*337*677(mm) Accessories User Manual, AC plug Steps for Usage Power on and off: Open the anti-accidental touch cover and press the power button. REMAINING TIME...
- Page 7 User Manual When the system power is low, the output is best not to carry high power.If con- tinued use, the product will be over discharged and it may cause automatic shutdown protection. After the shutdown, you need to wait for 2 minutes and then press the switch to restart it.
- Page 8 User Manual PV IN AC IN AC IN PV input: it has two groups of positive and negative interaces. The total input power of the two groups is 3000W. Each group of interaces suppors maximum 15A current. There fore, when the PV input current is too large, the PV array needs to be divided into two groups, and connects to the two groups of interaces at the same time.
- Page 9 OUT3 shall be 2500W(Max.), the output power of OUT4 shall be 5000W(Max.), and the total output power of the four AC output ports shall be 5000W(Max.). 120V NEMA TT-30 OUT1 OUT2 120V OUT3 NEMA 5-20 OUT4 120V/240V NEMA 14-30 FP5000 （US Version） User Manual...
- Page 10 OUT2 230V TYPE F OUT3 FP5000 （EU Version） Warning: Overpower output will trigger an alarm and turn off the output If you need to charge the EV with this product, press the ground switch above the outputs before charging. If no device is connected to the AC output within 1 minute after you press the ground switch, the ground will be cut off.
- Page 11 User Manual Packaging, Transportation and Storage 1. Packaging There are product name, model, manufacturer's logo, inspection certificate from the manufacturer's quality department, manufacturing date, etc. on the box; There is a list of accessories inside the packaging box. Cushioning Material...
