Summary of Contents for Slane T-08
- Page 1 USER’S MANUAL Read this manual completely before riding your electric tricycle...
- Page 2 CONTENTS 一、FOREWORD............................3 二、RIDING SAFELY...........................4 三、TECHNICAL INFORMATION........................7 四、PRODUCTION INTRODUCTION......................8 1、Main components..........................9 2、Instruments and indicators........................10 3、Left switch assembly.........................11 3、Right switch assembly........................12 4、Driving control system........................12 5、Charging the battery..........................13 五、RIDING POINTS..........................15 六、MAINTAINANCE AND ADJUSTMENT......................16...
- Page 3 FOREWORD This product is designed for transportation and is environmental friendly. Below are the characteristics and advantages of the electric scooter. * High-efficient brushless DC motor. * Digital controller with protection from over voltage and under voltage. * Brake system with power cut-off ability to ensure safe riding. * Sealed Lead acid battery with high performance offering stronger current and longer distance for drive.
- Page 4 RIDING SAFELY General Rules Don’t use the electric car until you read the manual carefully and understand the performance of the electric tricycle; Don't lend it to people who can't operate the electric tricycle. For the safety of you and others, please drive carefully, consciously abide by the traffic rules and drive in the non motorized lane.
- Page 5 Concentrate on the path ahead. Avoid potholes, gravel, wet road markings, oil, curbs, speed bumps, drain grates and other obstacles. Please keep the proper air pressure in the tire, so as not to increase the resistance,increase the tire wear and ...
- Page 6 Night Riding Ensure that the front lights are on. Wear reflective and light colored clothing. Ride at night only if necessary. Slow down and use familiar roads with street lighting, if possible. CAUTION: Modification is illegal. A modified vehicle will affect its structure or performance, which will result in shortening the vehicle’s life.
- Page 7 TECHNICAL INFORMATION Model name : T-08 Product size : 3110 (L) × 1190 (W) ×1860 (H) mm Wheelbase mm : 1990 mm Product Weight : 265kg Carrying capacity : 603kg Single charge : Approximately 50-60km Max speed : Approximately 30-35 km/h...
- Page 8 PRODUCTION INTRODUCTION...
- Page 9 Main components: 1. Front wheel 2. Front fender 3. Front turning lamp 4. Head lamp 5. Speed meter 6. Rear view mirror 7. Handle bar 8. Grip 9. Backrest 10. Armrest 11. Cargo box 12. Rear wheel 13. Motor 14. Seat 15.
- Page 10 Instruments and indicators 1. Speed meter: indicates the mileage of the mileage of the vehicle per hour. 2. Direction indicator: when the turn signal switch is left or right, the direction indicator will flash correspondingly. 3. Headlamp high beam indicator: when the headlamp high beam is turned on, the indicator will be on. 4.
- Page 11 Power switch: When the key is turned to the " " position, the circuit is on , the vehicle can run and the key can not be pulled out. When the key is turned to the “ ” position, the circuit is off, the vehicle can not be used, and the key can be pulled out.
- Page 12 Right switch assembly 1. Light on/off switch: when the electric vehicle need turn off the light, twirl the switch to ” ” position; Twirl the switch to ” ” position to turn on the light; When some faults happen to the electric vehicle and need emergency parking , twirl the switch to the emergency flasher switch ”...
- Page 13 2. Handle brake:When you want to stop and park the tricycle, please pull the handle brake lever to move the gear back. 3. Climbing shifter: When the vehicle climbs, you can adjust the climbing shifter gear to make it easily. Charging the battery The Power Switch Lock must be in the Off position when the electric scooter is being charged.
- Page 14 Turn off the scooter by pointed the key to ”. Insert the output plug to the charging socket of the scooter（refer ①） and connect the input plug 220V-230V to the wall socket ( refer ②). The battery in fully charged when the charger indicator shows green.
- Page 15 RIDING POINTS Check below spare parts before riding the scooter: A. checks tire condition such as worn-out or break. B. checks the transmission system condition. C. checks tire pressure. D. check bugle and rear reflector condition. E. checks all the standard spare parts such as nuts and screws if tighten well. Check if the brake cable lanyard functions in smooth condition.
- Page 16 MAINTAINANCE AND ADJUSTMENT Regular maintenance Because electric vehicles in the process of driving, electric vehicles will produce varying degrees of looseness and mechanical wear, if not regular maintenance, will lead to the decline of power economy, reliability, safety of electric vehicles, but also shorten the service life of electric vehicles, so the driver of electric vehicles must carry out the correct regular maintenance of electric vehicles, to ensure the best performance of electric vehicles.
- Page 17 6. Each lubricating point is fully lubricated without oil leakage. 7. The battery connection is not loose and the fixation is reliable. Daily check The condition of vehicles may change everyday. In order to ensure driving safety, the following items should be checked before driving every day: 1.
- Page 18 During use, the shock absorb shall be inspected carefully. If there is any damage or failure, it shall be replaced in time. Clean the front fork handle regularly. Inspection of tire The correct use of tire pressure can ensure the comfort and stability of electric vehicle driving, and extend the service life of the inner and outer tires of electric vehicle.
- Page 19 Do not dismantled or dispersed the battery cells. ② Keep away the battery from children. ③ Do not connect cathode and anode of charger during charging and discharge process. Prohibited to use any conductor to connect both cathode and anode. This will cause short circuit. ④...
- Page 20 Regular maintenance: check● adjust◆ replace▲ lubricate ■ Parts to be tested Daily 60days 180days 1.accelerator ●■ ●■ 2.turning parts ●■ ●■ 3.tire and full set of bulbs ● 4.chain ● ●■ 5.brake shoes ◆ 6.rims ● ● 7.front fork ● ●...
