Installation Instructions

Hansgrohe E

15700XXX

Hansgrohe S

15701XXX

Need help?

Do you have a question about the E 15700 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Hans Grohe E 15700 Series

Page 1 Installation Instructions Hansgrohe E 15700XXX Hansgrohe S 15701XXX...
Page 2 Bester Service, beste Preise Ihr Online-Fachhändler für: • Kostenlose und individuelle Beratung • TOP Bewertungen • Hochwertige Produkte • Exzelenter Kundenservice • Kostenloser und schneller Versand • Über 20 Jahre Erfahrung E-Mail: info@unidomo.de Tel.: 04621 - 30 60 89 0 www.unidomo.de uniDomo GmbH &...
Page 3 Contents Safety and Important Information Pack Contents Diniensions Technical Data Supply Conditions TMV2 Supply Conditions TMV3 Installation Requirements Installation Thermostat Commissioning and in-service tests Commissioning In-service tests Frequency of in-service tests Thermostatic Adjustement Temperature Limitation The Th e rm os t at Kit s 15 700 X X X and Callibrating Thermostat 15701XXX meet the requirements of the TMV2 Setting Thermostat Max.
Page 4 Safety and Important Information Hansgrohe products are safe provided they are installed, used and maintained in accordance with these instructions and recornrnendations. Please read these instructions thoroughly and retain for future use. The plumbing installation of this thermostat mixing valvemust comply with the requirements of UK Water Regulations/Bylaws (Scotland), Building Regulations or any other regulations specified by the local Water Authority and supplier.
Page 5 Dimensions Pack Contents Please check that you have been supplied with the following: Hansgrohe E 15700XXX Hansgrohe S 15701XXX 1 Thermostat cartridge block 2 Fixing screws 3 Fixing plate 4 Fixing screws 5 Sleeve for thermostatic element 6 Sleeve for shut off valve 7 Face plate 8 Spindle extension for shut off valve 9 Allen screw for shut off valve...
Page 6 Technical Data NB. If a water supply is fed by gravity then the supply pressure should be verified to ensure the conditions of use are appropriate for the valve. Hansgrohe E + S Valves operating outside of these supply conditions This thermostatic valve will suit supplies of: cannot be guaranteed to operate as a TMV2 or HIGH PRESSURE (HP-S)
Page 7 Installation Requirements This thermostatic mixer valve must be installed in compliance with current Water Regulations. If you have any doubts about the Water Regulation requirements contact your local water services provider or use the services of a professional plumber. This mixer valve is suitable for use with the following water supply systems: Gravity Fed Hot and Cold (pressure balanced) 0.1 - 1.0 bar Gas Combination Boiler (multi-point) 1.0 - 10 bar*...
Page 8 Unvented System (pressure balanced) Pumped System...
Page 9 Installation Thermostat The thermostatic mixing valve must be installed in a position that is easily accessible for commissioning and future servicing. 1. When the iBox fitted and the surface tiled, cut back the plastic rim to within 2mm of the tiles (fig.
Page 10 4. Place the fixing plate over the valve and fix with the 4 x 50mm screws supplied (fig. 4). 5. Push the thermostat sleeve onto the thermostat cartridge ensuring the notch on the sleeve is in the 12 o'clock position. Push the small sleeve onto the shut off valve cartridge.
Page 11 Commissioning and in-service tests Commissioning record the equipment, thermometer etc. used for the measurements Purpose Table A: Guide to maximum stabilised Since the installed supply conditions are likely to temperatures recorded during site be different from those applied in the laboratory tests tests it is appropriate, at commissioning, to carry Application...
Page 12 In-service tests Frequency of in-service tests TMV3* Purpose General In the absence of any other instruction or guidance The purpose of in-service tests is to regularly monitor on the means of determining the appropriate and record the performance of the thermostatic frequency of in-service testing, the following mixing valve.
Page 13 Thermostatic Adjustment Temperature Limitation The temperature is limited by the safety stop to 40°C. If a higher temperature is required, it is possible to over ride the safety stop by depressing the safety 40° button. NB. It is recommended that for private domestic use the maximum mixed water temperature be set at the following factory set values: Shower Mixer 43°C...
Page 14 Setting thermostat to a maximum temperature (Optional) The desired maximum temperature (43°C) can be preset using the safety function. Proceed as follows: 1. Undo the screw and pull off the handle. Undo the fixing screw. (fig.1). 2. Remove the faceplate, the sleeve and the spindle extension (fig.2).
Page 15 Operating your Shower Cleaning Cleaning materials for Mixers and Flow ON/OFF Control Showers Turn the flow control handle (fig.1a) anti-clockwise Acids are necessary ingredients of cleaning to turn the water on and to increase the flow. Turn it materials for removing lime. However please pay clockwise to decrease the flow and turn off.
Page 16 Spare Parts Thermostat kit 30x5 48x5 Handle for thermostatic element 36391XXX 14 Spindle extension for shut off valve 96451000 Handle for thermostatic element 38391XXX 15 Spindle extension for thermostatic Handle for shut off valve 96449XXX element 96435000 Handle for shut off valve 96421XXX 16 Fixing screws 96525000 Face plate 96550XXX 17 Sealing set 95037000 Sleeve for thermostatic element 96439XXX Sleeve for shut off valve 96446XXX Fixing screws 96454000 Fixing plate 96447000 XXX = Colors 10 Thermostatic element 94282000 000 chrome plated...
Page 17 Trouble Shooting Fault Cause Remedy Insuffient water flow - Supply pressure inadequate - Check mains pressure - Shower filter seal dirty - Clean filter seal between shower and hose - Thermostat cartridge filters dirty - Remove cartridge & clean the filters on the barrel ,Crossflow‘, hot water is forced - check valves dirty or leaking...
