I N S T A L L A T I O N G U I D E
FP4 MOBILE Stand
for flat panel Display
*AV Monitor screen not included
WWW•GILKON•COM•AU
All speci�ications are subject to change without notice
© Copyright 2024 OPIE Manufacturing Group PTY Limited. All rights reserved.
GILKON is a part of the OPIE GROUP
Advertisement
Related Manuals for GILKON FP4
Summary of Contents for GILKON FP4
- Page 1 FP4 MOBILE Stand for flat panel Display *AV Monitor screen not included WWW•GILKON•COM•AU All speci�ications are subject to change without notice © Copyright 2024 OPIE Manufacturing Group PTY Limited. All rights reserved. GILKON is a part of the OPIE GROUP...
- Page 2 FP4 MOBILE AV STAND - Assembly Instructions PART ONE - PARTS AUDIT Thank you for purchasing the Gilkon FP4 Mobile AV stand with Power Lift and 360º mobility I am "OP" and I'm here to help you assemble it - Careful when lifting, it weighs 34.9kg WEIGHT:34.9 kg...
- Page 3 FP4 MOBILE AV STAND - Assembly Instructions WITH POWER LIFT & 360º FREE WHEEL MOBILITY The Gilkon FP4 Mobile AV stand comes complete with a Power Lift and can be easily moved with 360º Free wheel Swivel Castors with a total locking latch system...
- Page 4 FP4 MOBILE AV STAND - Assembly Instructions STEP 1 - PARTS AUDIT Make sure you have got all the parts listed and take note of the different sizes and sort - We have supplied 3 trusty Allen Keys. We call them "Big Allen", "Little Al" and "Allison".
- Page 5 FP4 MOBILE AV STAND - Assembly Instructions STEP 2 - PRIMARY PARTS AUDIT Please sort the FP4 primary stand parts on a clear flat surface and take note of the pressed arrows and their orientations on Frame Parts as they are important.
- Page 6 VIEW SCALE ( 1 : 6 ) Plastic End Cap Rectangle 25 x 50 Black Well done! In finishing this step, you have completed the FP4 wheel assembly! FP4 MOBILE AV STAND - Assembly Instructions Copyright ©2024 OPIE Manufacturing Group...
- Page 7 FP4 MOBILE AV STAND - Assembly Instructions STEP 4 - FP4 STAND ASSEMBLY Please Note: Look for arrows on parts that indicate specific orientation and match the direction indicated. Assembly Finished M8 x 65 Cup Head Bolt ZP 1. Gather components listed in the...
- Page 8 5. Attach the Stand and Gusset Assem- bly to the Wheel Assembly with M8 Cup Head Bolts with Flat Washers Wow, how outstanding! You're so much closer to a completed FP4 Mobile AV stand! and M8 Nylock Nuts FP4 MOBILE AV STAND - Assembly Instructions Copyright ©2024 OPIE Manufacturing Group...
- Page 9 FP4 MOBILE AV STAND - Assembly Instructions STEP 6 - AV MOUNT ASSEMBLY Take a big, deep breath and plan your steps - check that the arrows are facing the right way! Please Note: Check Parts & arrows on the drawing that indicate spe-...
- Page 10 FP4 MOBILE AV STAND - Assembly Instructions STEP 7 - AV MOUNT ASSEMBLY TO STAND ASSEMBLY Let's put it all together and let it stand tallish! Please Note: Check Part arrows on the AV Mount Assembly that indicate Finished Assembly...
- Page 11 FP4 MOBILE AV STAND - Assembly Instructions STEP 8 - POWER LIFT INSTALLATION Place bolt into the center hole on the Top actuator support channel and fix the Power lift actuator on the rear side of the AV MOUNT ASSEMBLY.
- Page 12 FP4 MOBILE AV STAND - Assembly Instructions STEP 9 - POWER LIFT LOOM ASSEMBLY Click Plugs and Sockets: Some sockets come with locking mechanisms to hold the connection. Match the Locking Sockets with the plugs correctly and join; listen for a "click" sound to ensure the connection is secure.
- Page 13 FP4 MOBILE AV STAND - Assembly Instructions STEP 10 - INSTALL LOCKING BRACKET AND MONITOR BRACKET Locking Bracket : Slide Locking Bracket at the bottom of the Screen Mount Brackets and secure with Wing Nut washers (Leave Locking Bracket in open position).
- Page 14 FP4 MOBILE AV STAND - Assembly Instructions STEP 11 - CONFIRM BRACKET SPACING IS OPTIMAL Confirm that your monitor brackets match the correct width of the Vesa Mount indicator holes. VESA MOUNT INDICATOR HOLES You might need a lifting helper next! FP4 MOBILE AV STAND - Assembly Instructions Copyright ©2024 OPIE Manufacturing Group...
- Page 15 8mm HOLE SUITS PADLOCK UP TO 7mm SHACKLE lock with Lock Brackets L & R (PADLOCK NOT SUPPLIED) Well done! You are a star! - Enjoy your FP4 Mobile stand for flat panel display! FP4 MOBILE AV STAND - Assembly Instructions Copyright ©2024 OPIE Manufacturing Group...
