- Page 1 Owner ’s Manual REFRIGERATOR FREEZER Please read carefully the manual instruction and safety caution before operating your refrigerator and retain it for future reference GR-M648GSHX GR-M678GSHX www.lg.com P/NO : MFL67239907...
- Page 2 CONTENTS IMPORTANT SAFETY INFORMATION ....3 INSTALLATION ............11 INNER PARTS ............12 OPERATIONS ............14 Starting Before Setting The Temperature Door Alarm Self Test Controls For Refrigerator Compartment Fast Freezing Child Lock Shabbath Hygiene Fresh (Optional) Controls For Freezer Compartment Ice Making Defrosting Vegetable Drawer...
- Page 3 IMPORTANT SAFETY INFORMATION WARNING Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit. Do not use electrical appliances inside the food storage compartment of the appliance, unless they are of the type recommended by the manufacturer.
- Page 4 IMPORTANT SAFETY INFORMATION BASIC SAFETY PRECAUTIONS This guide contains many important safety messages. Always read and obey all safety messages. This is the safety alert symbol. It alerts you to safety messages that inform you of hazard that can hurt you or others or cause damage to the product. All safety messages will be preceded by the safety alert symbol and the hazard signal word WARNING, or CAUTION.
- Page 5 IMPORTANT SAFETY INFORMATION 1. When connecting the power Unplug the power plug when cleaning, Do not extend or modify the length of the handling or replacing the interior lamp of the power plug. refrigerator. It causes electric shock or fire •...
- Page 6 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Do not cling to the door or the shelves of the Do not place the heavy object or the door or the Family Homebar or the cool dangerous object chamber. (container with liquid) on It may make the refrigerator the refrigerator.
- Page 7 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Install in places away from the fire such as Do not use drier to dry the inside, nor light a the place where candle to remove odor. flammable gas is It may cause explosion or fire.
- Page 8 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Do not allow any person except the qualified When any strange smell or smoke is engineer to disassemble, repair or alter the detected from the refrigerator, disconnect refrigerator. the power plug Service It may cause injury, immediately and Down-block center...
- Page 9 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Place all the components in the right places Do not remove the cover before connecting the power. on the back. Do not use an Adapter Never leave lit candles or incense on the on the back.
- Page 10 IMPORTANT SAFETY INFORMATION Do not use products such as grinding Do not put any living animal in the sponge, brush, iron, or even special refrigerator. products to clean stainless steel, soap It may cause the animal products such as alcohol, kerosene, died.
- Page 11 THIS REFRIGERATOR IS MANUFACTURED WITH GREAT CARE, AND UTILIZES THE LATEST IN TECHNOLOGY. WE ARE CONFIDENT THAT YOU WILL BE FULLY SATISFIED WITH IT'S PERFORMANCE AND RELIABILITY. BEFORE YOU START YOUR REFRIGERATOR, PLEASE READ THIS BOOKLET CAREFULLY . IT PROVIDES EXACT INSTRUCTIONS FOR INSTALLATION, OPERATION AND MAINTENANCE, AND ALSO SUPPLIES SOOME USEFUL HINTS.
- Page 12 INNER PARTS INTERNAL CONTROLLER MODEL Twisting Ice Serve FREEZER Type Ice Making COMPARTMENT Lamp Shelf Freezer Temperature Freezer Door Rack Control Dial REFRIGERATOR COMPARTMENT Deodorizer Optional) Refrigerator Refrigerator Door Temperature Control Rack Egg Tray Lamp Shelves Optional) Refrigerator Door Rack Vegetable Drawer Vegetable Partitioner Levelling Screw...
- Page 13 INNER PARTS EXTERNAL CONTROLLER MODEL FREEZER Twisting Ice Serve Type Ice Making COMPARTMENT Lamp Shelf Freezer Temperature Freezer Door Rack Control Dial REFRIGERATOR COMPARTMENT Refrigerator Door Rack Deodorizer (Optional) Green Ion Door Cooling Fresh Zone Egg Tray Lamp Shelves Refreshment Center Optional) (Optional) Hygiene Fresh...
- Page 14 OPERATIONS STARTING When your refrigerator is first installed, allow it 2-3 hours to stabilize at normal operating temperatures prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. BEFORE SETTING THE TEMPERATURE The temperature of the refrigerator is kept constant regardless of changes in room temperature.
- Page 15 OPERATIONS FOR EXTERNAL CONTROLLER MODEL Display graphic can be different, depend on the type of your refrigerator. Type a Type b Press 'REFRIGERATOR' button to control refrigerator temperature. Whenever pressing the button, the LED emits light. Press ‘HYGIENE FRESH’ button to operate hygiene motor (optional). The number showing up on the LED luminesce indicate the temperature of refrigerator compartment.
- Page 16 OPERATIONS SHABBATH Shabbath mode is the function designated for use of the refrigerator during Shabbath. To set the Shabbath mode on, Press the Shabbath button for 3 Seconds. Then, initially 8 shows in the display as well as lamp and alarm turn off. Shabbath mode will automatically turned off after 96 hours.
- Page 17 OPERATIONS How to install the new filter Install the new filter. Insert the new HYGIENE FRESH filter in the separated • filter cover so that the hooks around the filter are visible.. (If the filter is inserted in reverse direction, it will not be assembled.) Insert the filter cover to its original position and then turn •...
- Page 18 OPERATIONS CONTROLS FOR FREEZER COMPARTMENT To lower the temperature in the freezer, turn the knob counter-clockwise and set to a higher number. To raise the temperature in the freezer, turn the knob clockwise and set to a smaller number. When the freezer compartment is not cold enough in winter, adjust the control for the freezer to High ( Knob is for quick freezing in the freezer compartment.
- Page 19 OPERATIONS VEGETABLE DRAWER Vegetable Partitioner Fix the partitioner by inserting it at the rear side of vegetable box as shown in the figure. How to use Vegetable drawer can be used through the control of knob. Check the position of knob prior to store the food. Do not locate the knob on the middle point.
- Page 20 SUGGESTIONS ON FOOD STORAGE STORING FOOD Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavor. Do not store food which goes bad easily at low temperatures, such as bananas, pineapples, and melons.
- Page 21 CLEANING It is important that your refrigerator be kept clean WARNING to prevent undesirable odors. Spilled food should be wipe up immediately, since it may acidify and Always remove power cord from the wall stain plastic surfaces if allowed to settle. outlet prior to cleaning in the vicinity of electrical parts(lamps, switches, controls, etc.).
- Page 22 GENERAL INFORMATION VACATION TIME ANTI-CONDENSATION PIPE During average length vacations, you will probably The outside wall of the refrigerator cabinet may find it best to leave the refrigerator in operation. sometimes get warm, Place freezable items in freezer for longer life. especially just after When you plan to be away for an extended period, installation.
- Page 23 IMPORTANT WARNINGS DO NOT USE AN EXTENSION CORD ABOUT GROUNDING (EARTHING) If possible, connect the refrigerator to its own In the event of an electric short circuit, grounding individual electrical outlet to prevent it and other (earthing) reduces the risk of electric shock by appliances or household lights from causing an providing an escape wire for the electric current.
- Page 24 BEFORE CALLING FOR SERVICE SERVICE CALLS CAN OFTEN BE AVOIDED! IF YOU FEEL YOUR REFRIGERATOR IS NOT OPERATING PROPERLY, CHECK THESE POSSIBLE CAUSES FIRST : PROBLEM POSSIBLE CAUSES REFRIGERATOR DOES Has a house fuse blown or circuit breaker tripped? NOT OPERATE Has the power cord plug been removed or loosened from the electrical wall outlet? Temperature control not set on proper position.
- Page 25 It is recommended to install the earth to prevent electric shock in case of electricity leakage. How to connect the earth wire: • Connect the earth wire's metal ring end to the earth screw on the back of the refrigerator. •...
