OWNER'S MANUAL
FRIDGE & FREEZER
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
GR-B6681SE / GR-M6682SE
MFL71817211
Rev.01_032224
Copyright © 2024 LG Electronics Inc. All Rights Reserved.
Scan the QR code to see the manual.
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GR-B6681SE and is the answer not in the manual?

Questions and answers

Related Manuals for LG GR-B6681SE

Summary of Contents for LG GR-B6681SE

  • Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH GR-B6681SE / GR-M6682SE www.lg.com MFL71817211 Rev.01_032224 Copyright © 2024 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    Before Use ......................15 Product Features....................18 Control Panel ....................21 Shabbath Mode ....................24 Water Dispenser....................25 Icemaker ......................26 Automatic Icemaker ..................27 Fridge Drawer....................29 Door Basket ......................29 Shelf ........................29 SMART FUNCTIONS LG ThinQ Application ..................31 Smart Diagnosis ....................32 MAINTENANCE Cleaning ......................34 TROUBLESHOOTING Before Calling for Service................35...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk.
  • Page 4 SAFETY INSTRUCTIONS appliance. Cleaning and user maintenance shall not be made by children without supervision. • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 5 SAFETY INSTRUCTIONS • If the power cord is damaged or the hole of the outlet socket is loose, it must be replaced. Do not use the power cord and contact an authorized service centre in order to avoid a hazard. •...
  • Page 6 SAFETY INSTRUCTIONS • Only qualified service personnel from LG Electronics service centre should disassemble or repair the appliance. Risk of Fire and Flammable Materials • If a leak is detected, avoid any naked flames or potential sources of ignition and air the room in which the appliance is standing for several minutes.
  • Page 7 • Ensure that the outlet socket is properly grounded, and that the earth pin on the power cord is not damaged or removed from the power plug. For more details on grounding, inquire at an LG Electronics customer information centre.
  • Page 8 • Do not bend the power cable excessively or place a heavy object on it. • Immediately unplug the power plug and contact an LG Electronics customer information centre if you detect a strange sound, odour, or smoke coming from the appliance.

  • Page 9: Caution

    SAFETY INSTRUCTIONS • Connect to potable water supply only. - If connected to a water supply, connect to a potable water supply only. • Fill with potable water only. - If using an icemaker or dispenser water tank, make sure to fill it with potable water only.
  • Page 10 They may shatter if exposed to sudden temperature changes. • Do not insert the shelves upside down. The shelves may fall. • If ice forms in the freezer compartment, please contact LG Electronics customer service. Do not use sharp-edged objects to remove any frost or ice build-up.
  • Page 11 SAFETY INSTRUCTIONS • Dispose of the ice inside the ice bucket in the freezer compartment during an extended power outage.

  • Page 12: Installation Before Installation

    INSTALLATION INSTALLATION Before Installation Ambient Temperature • The appliance is designed to operate within a Dimensions and Clearances limited range of ambient temperatures, depending on the climate zone. Too small of a distance from adjacent items may result in the degradation of freezing capability and •...

  • Page 13: Turning On The Power

    INSTALLATION Moving the Appliance for Turn the levelling leg clockwise to raise that Relocation side of the appliance or counterclockwise to lower it. Moving the Appliance Remove all food from inside the appliance. Fix the power plug. • Models with a power plug hook: Pull the power plug out, insert and fix it into the power plug hook at the rear or on top of the appliance.
  • Page 14 INSTALLATION CAUTION - Do not move the appliance in zigzags. After installing the appliance, connect the power plug into a mains outlet socket and switch it on.

  • Page 15: Operation

    3 cm from the sensor. completely closed. NOTE Storing Foods Effectively • Contact the LG Electronics customer information • Food may freeze or spoil if stored at the wrong centre if the alarm sound continues even after temperature. Set the refrigerator to the correct closing all doors.
  • Page 16 OPERATION • Do not store food for a long period of time if it • In the event of a blackout, call the electricity spoils easily at a low temperature. company and ask how long it is going to last. •...
  • Page 17 OPERATION Freezing the Maximum Amount of Food If large quantities of food are to be stored, the icemaker should be taken out of the appliance and the food should be stacked directly on the freezer shelves in the freezer compartment. NOTE •...

  • Page 18: Product Features

    OPERATION Product Features The appearance or components of the appliance may differ from model to model. Interior (Two Star *1 This feature is only available on some models. Control panel Sets the fridge temperature. Water Dispenser Freezer Shelf Stores frozen foods such as meat, fish, and icecream. Moving Icemaker This is where ice is manually produced and stored.
  • Page 19 Air filter Reduces odours inside the fridge compartment. NOTE • Do not disassemble the air filter. If you want to replace it, please contact the LG Electronics customer information centre. Fresh Room This is where food items are stored at a colder temperature than the regular fridge area.
  • Page 20 OPERATION • You can move it to and use it at a desired position as needed. However, do not use it as the ice bin or place it on the shelf on top of the fridge or the vegetables drawer.

  • Page 21: Control Panel

    OPERATION Control Panel The actual control panel may differ from model to model. Control Panel and Functions *1 This control panel is only available on some models. Control Panel 1: On the Freezer Door Freezer Press this button repeatedly to select a desired temperature between -23 ℃ and -15 ℃. •...
  • Page 22 Wi-Fi This button allows the appliance to connect to a home Wi-Fi network. Refer to Smart Functions for information on the initial setup of the LG ThinQ application. Ice On/Off Press the Ice On/Off button to turn the icemaker on/off.
  • Page 23 OPERATION • Press this button for 3 seconds. When the left LED light lit, press the Fridge button repeatedly to select a desired temperature between Cold and Coldest. • Press this button for 3 seconds to disable Convertible function, as LED light off. Fridge Press this button repeatedly to select a desired temperature between Cold and Coldest.

  • Page 24: Shabbath Mode

    OPERATION Control Panel 3: Inside the Freezer Turn the dial to select a desired temperature between Min and Max. NOTE • For optimal food preservation, increasing or decreasing one level from the default temperature is recommended. Setting the Freezer • Wait until 2 or 3 hours have passed after connecting the appliance to the outlet before Temperature Level (1-5) storing food in the appliance.

  • Page 25: Water Dispenser

    OPERATION • Selecting Shabbath mode automatically turns off • Wipe the dispenser outlet frequently with a clean the Alarm functions. cloth as it may get dirty easily. Water Dispenser This feature is only available on some models. Using the Dispenser You can dispense water by pressing the lever.

  • Page 26: Icemaker

    OPERATION Remove the water valve in the water tank by CAUTION turning it clockwise. • Do not apply excessive force or impact when removing or assembling the water dispenser tank. NOTE • The water tank should be washed before filling it with potable water.

  • Page 27: Automatic Icemaker

    • If discolored ice is dispensed, check the water water on the ice tray. tank and the water supply for a possible source. If the problem continues, contact the LG Electronics customer information centre. Do not use the ice or water until the problem is...
  • Page 28 OPERATION Turning the Automatic CAUTION Icemaker On or Off • Do not touch the automatic icemaker with your To turn the automatic icemaker On/Off, press the hand or a tool. Ice On/Off button on the control panel. • Do not remove the cover of the automatic icemaker.

  • Page 29: Fridge Drawer

    OPERATION Fridge Drawer Door Basket Removing and Refitting the Removing/Refitting the Door Fresh Vegetable Drawer Basket Remove the contents of the drawer. Hold the Hold both edges of the basket and remove it by handle of the vegetable drawer and gently pull lifting it upward.
  • Page 30 OPERATION CAUTION • Do not place food on the marked area of the bottom shelf. The fridge door may not close completely.

  • Page 31: Smart Functions

    • Functions may vary by model. from the Google Play Store or Apple App Store on a smartphone. Run the LG ThinQ application and sign in with your existing account or create an LG account to sign in. Touch the add ( ) button on the LG ThinQ application to connect your LG appliance.

  • Page 32: Smart Diagnosis

    Internet service provider or refer to your Open Source Software Notice wireless router manual. Information • LG ThinQ is not responsible for any network connection problems or any faults, To obtain the source code that is contained in this malfunctions, or errors caused by network product, under GPL, LGPL, MPL, and other open connection.
  • Page 33 SMART FUNCTIONS • Launch the LG ThinQ application and select the Control Panel 2: Inside the Fridge Smart Diagnosis feature in the menu. Follow the instructions provided in the LG ThinQ Open the fridge door. application. Close and open the fridge door 5 times within Using Audible Diagnosis to 8 seconds.

  • Page 34: Maintenance Cleaning

    MAINTENANCE MAINTENANCE Cleaning Cleaning the Interior • Before removing a shelf or drawer from inside General Cleaning Tips the appliance, remove all stored foods from the shelf or drawer to prevent injury or damage to • Performing manual defrosting, maintenance or the appliance.

  • Page 35: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING Before Calling for Service Cooling Symptoms Possible Cause & Solution There is no Is there a power interruption? refrigeration or • Check the power of other appliances. freezing. Appliance is unplugged. • Plug the power plug in the outlet properly. A fuse in your home may be blown or the circuit breaker tripped.
  • Page 36 TROUBLESHOOTING Symptoms Possible Cause & Solution The appliance contains Did you put in food with a strong smell? a bad smell. • Store foods with strong smells in sealed containers. Vegetables or fruit may have spoiled in the drawer. • Throw away rotten vegetables and clean the vegetable drawer. Do not store vegetables too long in the vegetable drawer.
  • Page 37 Lamp failure appliance does not • Close the door and re-open. If the lamp does not turn on, please contact turn on. the LG Electronics customer information centre. Do not attempt removal of the lamp. Noises Symptoms Possible Cause & Solution...
  • Page 38 TROUBLESHOOTING Symptoms Possible Cause & Solution Your home appliance The distance between the appliance and the router is too far. and smartphone are • If the distance between the appliance and the router is too far, the signal not connected to the may be weak and the connection may not be configured correctly.
  • Page 39 Memo...
