REFRIGERATOR
SERVICE MANUAL
CAUTION
BEFORE SERVICING THE UNIT, READ THE "SAFETY
PRECAUTIONS" IN THIS MANUAL.
MODEL : GR-M652Y*A/M712Y*A
GR-M652Y*Y/M712Y*Y
GR-B652Y*B/B712Y*B
GR-B652Y*Y/B712Y*Y
GR-B652Y*C/B712Y*C
GR-M652Y*X/M712Y*X
GR-M652Y*Q/M712Y*Q
GR-B652Y*S/B712Y*S
GR-B652Y*Q/B712Y*Q
