WARNING

This furnace is equipped with an ignition control

factory enabled for use with Lennox A2L refrigerant

systems.

Disabling

functionality on A2L system is prohibited by safety

codes. Refer to furnace installation instructions for

non-A2L and non-Lennox refrigerant system setup.

Contents

Unit Dimensions - inches (mm) ......................................2

ML180UHEK Gas Furnace .............................................3

Shipping and Packing List ..............................................3

Safety .............................................................................3

Use of Furnace as a Construction Heater ......................4

General ...........................................................................4

Combustion, Dilution, Ventilation Air...............................5

Setting Equipment ..........................................................8

Filters ............................................................................ 11

Duct System .................................................................12

Venting..........................................................................13

Gas Piping ....................................................................20

the

refrigerant

detection

INSTALLATION

INSTRUCTIONS

ML180UHEK

MERIT

SERIES GAS FURNACE

UPFLOW / HORIZONTAL AIR DISCHARGE

508541-01

11/2024

THIS MANUAL MUST BE LEFT WITH THE

HOMEOWNER FOR FUTURE REFERENCE

This is a safety alert symbol and should never be

ignored. When you see this symbol on labels or in man-

uals, be alert to the potential for personal injury or death.

As with any mechanical equipment, contact with

sharp sheet metal edges can result in personal

injury. Take care while handling this equipment and

wear gloves and protective clothing.

IMPORTANT

DO NOT use the heat exchanger bracket to lift, drag

or pull the furnace to its installation location. Doing

so will loosen the bracket causing noise and or

unsafe operation.

Bracket

Electrical .......................................................................23

Ignition Control .............................................................25

Twinning .......................................................................30

Low GWP Application ...................................................31

Unit Start-Up .................................................................34

Gas Pressure Measurement.........................................35

Proper Combustion.......................................................35

High Altitude .................................................................35

Other Unit Adjustements...............................................36

Service..........................................................................37

Repair Parts List ...........................................................39

Start-Up Checklist.........................................................40
