- Page 1 79568 BELT SANDER INSTRUCTION MANUAL 230V~50Hz 810W SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
- Page 2 SAFETY IMPORTANT SAFETY INFORMATION General Power Tool Safety Warnings Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool”...
- Page 3 1. Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. 2. Maintain labels and nameplates on the tool. These carry important safety information. If unreadable or missing, contact TOLSEN Tools for a replacement.
- Page 4 SAFETY AND SPECIFICATIONS Belt sander and drum sander safety warnings Hold the power tool by insulated gripping surfaces, because the sanding surface may contact its own cord. Cutting a “live” wire may make exposed metal parts of the power tool “live” and could give the operator an electric shock. Vibration Safety This tool vibrates during use.
- Page 5 SETUP SAFETY SAFETY SAFETY SAFETY SAFETY SAFETY SAFETY SAFETY SPECIFICATIONS SETUP - BEFORE USE Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Functions Front handle Trigger...
- Page 6 SETUP Operating Instructions Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Tool Set Up TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Make sure that the Trigger is in the off-position and unplug the tool from its electrical outlet before performing any procedure in this section.
- Page 7 SETUP Maintenance and Servicing instructions Procedures not specifically explained in this manual must be performed only by a qualified technician. TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Make sure that the trigger is in the off-position and unplug the tool from its electrical outlet before performing any procedure in this section.
- Page 8 TROUBLESHOOTING SAFETY SAFETY SAFETY SAFETY SAFETY SAFETY SAFETY SAFETY TROUBLESHOOTING Problem Possible Causes Likely Solutions Tool will not start 1. Cord not connected. 1. Check that cord is plugged in. 2. No power at outlet. 2. Check power at outlet. If outlet is unpowered, 3.
- Page 9 PARTS LIST PARTS LIST part Description part Description Speed controller cable jacket Blocking ring Le housing Capacitance brand label Blocking ring 10 Column melt 3×16 Switch round pin Stator washer 8 Bearing washer 8 Tension spring φ12 adjustable knob Screw ST4.2×45-F spring Bearing carbon brush cover...
- Page 10 ASSEMBLY DIAGRAM ASSEMBLY DIAGRAM...
- Page 11 CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. No.198, Huashan Road, Jinfeng Town,Zhangjiagang City, Jiangsu Province, China Declare that the product Belt Sander 230V~ 50Hz, 810W Serial number: N/A Complies with the essential health and safety requirements of the following Directices:...
- Page 12 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. SCAN TO VISIT TolsenWorld MADE IN CHINA PRODUCT LINK...
