- Page 1 79564 FINISHING SANDER INSTRUCTION MANUAL 220W 230V~50HZ SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
-
Page 2: Important Safety Information
SAFETY IMPORTANT SAFETY INFORMATION General power tool safety warnings WARNING: read all safety warnings and instructions.Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.Save all warnings and instructions for future reference.The term ”power tool” in the warnings refers to your mains-operated (corded) power tool. Work area safety 1. -
Page 3: Personal Safety
SAFETY Personal safety 1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. - Page 4 9.Maintain labels and nameplates on the tool. These carry important safety information. If unreadable or missing, contact Tolsen Tools for a replacement. 10.Avoid unintentional starting. Prepare to begin work before turning on the tool.
- Page 5 SAFETY This tool vibrates during use. repeated or long-term exposure to vibration may cause temporary or permanent physical injury, particularly to the hands, arms and shoulders. to reduce the risk of vibration-related injury: 1.Anyone using vibrating tools regularly or for an extended period should first be examined by a doctor and then have regular medical check-ups to ensure medical problems are not being caused or worsened from use.
-
Page 6: Specifications
SPECIFICATIONS SPECIFICATIONS Electrical input 230VAC / 50 Hz No load speed 6000--12000 OPM Input power 220W Pad size 187x92.5mm Note: Symbology Double Insulated WARNING mark concerning Risk of Eye Injury. Wear ANSI-approved safety goggles with side shields Read the manual before set-up and/or use. -
Page 7: Setup - Before Use
SETUP SETUP - BEFORE USE: Read the entire important safety information section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Warning:toprevent serious injury form accidental operation: Make sure that the power switch is in the off-position and unplug the tool from its electrical outlet before performing any procedure in this section. - Page 8 SETUP OPERATING INSTRUCTIONS Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Tool set up Warning:toprevent serious injury form accidental operation: Make sure that the power Switch is in the off-position and unplug the tool from its electrical outlet before performing any procedure in this section.
-
Page 9: Work Piece And Work Area Set Up
Work piece and work area set up 1.Designate a work area that is clean and well-lit. The work area must not allow access by children or pets to prevent distraction and injury. 2.Route the power cord along a safe route to reach the work area without creating a tripping hazard or exposing the power cord to possible damage. -
Page 10: Maintenance And Servicing
MAINTENANCE AND SERVICING procedures not specifically explained in this manual must be performed only by a qualified technician. To prevent serious injury from accidental operaiton: Ake sure that the trigger is in the off-position and unplug the tool from its electrical outlet before performing any procedure in this section. -
Page 11: Troubleshooting
MAINTENANCE AND SERVICING TROUBLESHOOTING problem possible causes Likely Solutions Tool will 1.Cord not connected. 1.Check that cord is plugged in. not start. 2.No power at outlet. 2.Check power at outlet. If outlet is unpow- 3.Internal damage or wear. ered,turn off tool and check circuit breaker. If (Carbon brushes or Trigger, for breaker is tripped, make sure circuit has right example.) -
Page 12: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product 79564 Finishing sander 230V~, 50Hz, 220W, n0:6000-12000/min Serial number: N/A Complies with the essential health and safety requirements of the following Directices:... - Page 13 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. SCAN TO VISIT TolsenWorld MADE IN CHINA PRODUCT LINK...
