- Page 2 Návod k použití Benutzerhandbuch Brugervejledning User manual Manual del usuario Käyttöopas Mode d'emploi Baby monitor Εγχειρίδιο χρήση Használati útasítás BE1491 Manuale utente Gebruiksaanwijzing Brukerhåndbok Instrukcja obsługi Manual do utilizador Bruksanvisning Návod na použitie Installer’s guide...
- Page 3 Oversigt Installation Tænd/Sluk og indstillinger Lysdioder Ext. trig indgang Mikrofon 1 Fjern beskyttelses lmen ved batteriet inden baby overvågningen tages I brug. 2 Placér baby overvågningen på natbordet eller montér den på væggen vha. med- følgende skrue og rawplug. Den anbefalede afstand fra barnet er 0,5 – 2,0 meter, udenfor barnets rækkevidde.
- Page 4 Test: Indstillinger 1 Stil Dem ved barnets seng og lav noget lyd. Knapperne for følsomhed og forsinkelse ndes på baby overvågningens venstre side. Ved tryk på knappen indikerer lysdioden den aktuelle indstilling. Tryk gentagne 2 Baby overvågningens modtager indikerer med ”Sut” symbol, lys eller gange for at ændre indstillingerne.
- Page 5 Installation af Træde måtte Teknisk information Strømforsyning Batterier: 2 x 1.5 V AA (LR6) lithium eller alkaline batterier. Ved brug af trædemåtten, kan man blive alarmeret, hvis barnet forlader sengen. Strømforbrug Aktiv < 70 mA, Stand-by position < 400 A Placér måtten ved sengen og tilslut denne til baby overvågningen, som aktiveres Driftstid Alkaline ~ 6 måneder, Lithium ~ 1 år...
- Page 6 Fejlsøgning Problem Løsningsforslag Problem Løsningsforslag To lysdioder lyser • Udskift batterierne. Kun 1.5 V AA (LR6) lithium eller Baby overvågningen • Formindsk følsomheden eller yt baby overvågningen orange hvert 10. sek aktiveres for ofte/nemt endnu længere væk fra sengen, se Indstillinger. alkaline batterier kan benyttes.
- Page 7 Installer’s Guide 133 Introduction 135 Installation 137 Testing 139 Settings 140 Default indication and signals 141 Changing the radio key 145 Trouble shooting 147 Technical information Installer’s Guide Installer’s Guide...
- Page 8 Introduction Overview Function On/O and settings LED lights Ext trig input Microphone The baby monitor is part of the Visit alerting system that helps people with hearing loss to notice signals in their home. When your child cries, the baby monitor signals the Visit receiver that noti es you with sound, lights or vibra- tions (depending on the receiver).
- Page 9 Installation Installing a contact mat 1 Remove the battery pull tab to start the baby monitor. By using a contact mat, you can also be noti ed if your child gets out of bed. Just place the mat in front of the crib, connect it to the baby monitor and it will 2 Place the baby monitor on the nightstand or hang it on the wall with the tell you when your child steps on it.
- Page 10 Testing Advanced testing 1 Stand by the child’s bed and make a noise. Testing the baby monitor is easy. First, make sure that the baby monitor is installed properly. For instructions, read the section Installation. 2 The Visit receiver lights up a paci er symbol and indicates with sound, lights or vibrations (depending on the receiver).
- Page 11 Settings Default indication and signal Transmitter indication The buttons for sensitivity and delay are located on the baby monitor’s left When the baby monitor is activated, the LED indicator lights up in green. This side. When you press the button, the LED shows the current setting. Then press means that the batteries are in good condition.
- Page 12 Changing the radio key Customizing the signal If you install multiple systems, you can set The baby monitor controls the signal pattern on a unique radio key for each system to avoid the receiver. By moving a signal switch up=on interference.
- Page 13 Signal output for 868 MHz and 315 MHz Signal output for 433 MHz Baby monitor Receiver signal pattern Baby monitor Receiver signal pattern Switch Source Sound Vibration Flash Switch Source Sound Vibration Flash Test button or Test button or Orange light Baby melody Fast Orange light...
- Page 14 Trouble shooting Try this Try this Two orange lights • Change the batteries. Only use 1.5 V AA (LR6) lithium The baby monitor is • Reduce the sensitivity or move the baby monitor appear every 10s or alkaline batteries. activated too easily further away from the crib, see Settings.
- Page 15 Technical information accept any interference, including interference that may cause unde- Hereby, Bellman & Symfon Use and disposal of batteries sired operation of the device. Power supply Battery power: 2 x 1.5 V AA (LR6) lithium or alkaline batteries. de- clares that this Baby Replace only with the same or equi- monitor is in compliance with valent type recommended by the...
- Page 16 DESIGN FOR EARS ™ bellman.com...
