- Page 1 EMF EMT EMTR EMX Series STEREO MICROSCOPES INSTRUCTION MANUAL...
- Page 2 CONTENTS NOMENCLATURE AND FUNCTION 2 - 3 THE USE AND CARE Unpacking How to Rotate the Head OPERATION PROCEDURES 5 - 7 How To Operate Illuminators Focusing Capability Precise Focus On Specimen Focusing Procedure Interpupillary Distance Adjustment Changing The Magnification On EMT, EMTR And EMX Models How To Use Eyeshield PHOTOGRAPHY AND TELEVISION 7 - 8...
- Page 3 NOMENCLATURE AND FUNCTION MEIJI EMF EMT EMTR EMX Series STEREO MICROSCOPE Photo Tube Lever Eyepieces for switching the with Eyeshield image from one of the binocular eyepieces vertically up to the film plane Diopter Adjustment Ring EMTR-2 Trinocular Stereo Body Eyetube Inclination : 45 。 ...
- Page 4 Model EMX-1 with SWF10X mounted on PX Stand Eyeshield Diopter Eyepieces Adjustment Ring with Eyeshield Set screw Prism House Focusing Knob Fixed objective Clamp Stage Clips Collar Set Screw Stage Plate Set Screw Base Reversible Stage Plate Black / White Model EMF-1 with SWF10X mounted on P Stand...
- Page 5 THE USE AND CARE OF MEIJI EM Series "MEIJI" EMF, EMT, EMTR AND EMX SERIES WIDEFIELD STEREO MICROSCOPE The MEIJI EM Series (EMF,EMT, EMTR and EMX Series) Widefield Stereo Microscope consists of two converging compound microscopes which are combined as a unit to focus simultaneously on the same field of object.
- Page 6 IMPORTANT! Before plugging the illuminator into any electric outlet, make sure that transfomers and illumination bases supplied to you are suitable to the current available. (When shipped, these will be labelled as to mains voltage and cycles specification.) Main voltage label MAINS AC100V-120V OPERATION PROCEDURES HOW TO OPERATE ILLUMINATORS...
- Page 7 The Rigid arm type focusing stands (except the The Rigid arm type ABE focusing stand is with model ABE) have a focusing capability only by integral focus block and extendable working rack and pinion adjustment. This means that the distance. Provides transmitted and incident available range of specimen sizes/depths which halogen illumination.
- Page 8 Photographic documentation of microscope visual images is most conveniently achieved by using the trinocular (photo-binocular) bodies offered for use with MEIJI TECHNO microscpoes. In the case of the EMTR Stereo series a trinocular is supplied with lever-switching of the image from one of the binocular eyepieces vertically up to the film plane of a 35mm SLR camera with adaptor mounted on the vertical photo tube.
- Page 9 35mm SLR CAMERA OPERATION T2-1 Canon Camera Body T2-2 Minolta Fix your 35mm SLR camera on the MA150/50 T2-3 Pentax K or MA150/60 Camera Attachment, then T2-4 Pentax S mounting this assembly on the straight tube of T2-5 Nikon ...
- Page 10 MAINTENANCE AND CARE BULB REPLACEMENT When changing light bulbs in the illuminators, always disconnect the plug from the electrical source. Never work on the electrical system without first disconnecting. When a bulb replacement is necessary in the Incident Illuminator, remove the lamp cover by turning it counterclockwise and remove the old bulb by twisting it 1/3 turn counterclockwise by pushing it toward the socket so that the bulb will be sprung out from its socket.
- Page 11 EM Series SYSTEM DIAGRAM EM Series VIEWING HEADS EMF-1, EMF-2, SPECIAL STANDS EMT-1, EMT-2, EMT-3, EMT-4, EMTR-1, EMTR-2, EMTR-3, EMTR-4, ※ZOOM HEADS EMZ-1, EMZ-2, EMZ-5, EMZ-5D, EMZ-6, EMZ-9, EMZ-10, Z-7100, EMZ-2TR, EMZ-5TR, EMZ-5TRD, EMZ-8TR, EMZ-8TRD FX Holder FC Holder FS Holder F Holder w/coaxial coares and w/illuminator port...
- Page 12 EM Series SYSTEM DIAGRAM VIDEO MICROSCOPY CK3900N or CK3900P MK300N or MK300P CK3900N or CK3900P MK300N or MK300P CCD Camera B/W CCD Camera CCD Camera B/W CCD Camera MA151/35/03 0.3 X MA151/35/04 0.4 X "C"Mounts* "C"Mounts MA151/35/15 1.0 X MA151/5N with Lens MA151/35/20 0.7 X Existing photo tube should...
- Page 13 EM Series SYSTEM DIAGRAM EMF EMT EMTR EMX Series MA550/05 MA533 Polarizing filter Protective glass (Analyzer) Adapter MA515 EMF-1 EMF-2 EMT-1 EMTR-1 EMT-2 EMTR-2 STAND PBH Pole type PB Pole type PC Plain Pole PX Pole type PL Pole type P Plain A Plain w/halogen 6V 10W w/tungsten 6V 7W w/coaxial focusing...
- Page 14 EYEPIECES, Paired MA501 MA502 MA520 MA503 MA535 MA504 MA521 MA519* MA600 SWF5X SWF10X SWF12.5X SWF15X HSWF15X SWF20X SWF30X SWF10X-F EYESHIELD *(Piece) Auxiliary lens Auxiliary lenses MA550/10 MA537 Polarizing filter Protective glass MA658 (Analyzer) Protective glass MA518 MA527 MA513 MA514 0.5X 0.75X 1.5X 2.0X...
- Page 15 322-1,Chikumazawa Miyoshi-machi, Iruma-gun Saitama 354-0043, Japan E-mail : meiji@meijitechno.co.jp Phone : (0)49-259-0111 Fax : (0)49-259-0113 2186 Bering Drive San Jose, CA., 95131, USA E-mail : sales@meijitechno.com Phone : 408-428-9654 Fax : 408-428-0472 Toll free : 800-832-0060 http ://w w w .me ijite chno.com 03.10.2,000 V1 Printed in Japan...
