Summary of Contents for Tennant S960
- Page 1 S960 Sweeper Tennant S960...
- Page 2 Please make sure to do a good job in recycling. Tennant S960...
- Page 3 Replacing/installing the filter screen ··12 Replacing/installing the water filter screen ···································· 13 Machine operation ·············· ··············14 Pre-operation inspection ············· 14 Before operation ························14 During machine operation ··········· 15 Sweeping method ······················15 Battery level ····························· 16 Reset insurance ·························16 Timer ······································ 17 Tennant S960...
- Page 4 This machine is not equipped with an explosion-proof motor. During start- up and operation, the electric motor of this machine may generate sparks. If this machine is used in places with flammable gases, liquids, or dust, it may cause flash fire or explosion. Tennant S960...
- Page 5 2% Operation. -Lower the brush plate motor to the 4.Before leaving or repairing the lowered position. machine: -Use ropes to secure the machine. -Park the machine on a stable surface. -Turn off the machine. -Take out the key. Tennant S960...
- Page 6 6.Bucket type water inlet 7.Charging port 8.Rear wheel 9.Cylindrical brush 10.Side brush 11. Front rubber pedal 12. Brake pedal 13. Drive pedal 14. Operation panel 15. DC power supply 16.Main brush reset insurance 17. Edge brush reset insurance 18. Hopper Tennant S960...
- Page 7 6.Water pump switch 7.Side brush switch 8.Side brush lifting switch 9.Fan switch Control panel symbols Water spray switch Side brush switch Main brush switch Vibration dust switch Side brush lifting switch Fan switch Left and right turn signal switches Tennant S960...
- Page 8 There are two available side brushes and one cylindrical brush, with a diameter of 500mm side brush, a diameter of 320mm cylindrical brush and a length of 700mm cylindrical brush. Tennant S960...
- Page 9 (as shown in Figure 7) Figure 1 Figure 5 Figure 2 Figure 6 Figure 3 Note: Regularly inspect the drive chain. If any looseness is found, adjust the bolts at this point. Figure 7 Tennant S960...
- Page 10 Figure 8-1 Installation and replacement of accessories Replacing/installing the front side brush Figure 9 1.Park the machine on a flat surface and ensure that the brush plate motor is in the raised position. 2.Turn off the machine key switch. Tennant S960...
- Page 11 Turn off the machine key switch. For safety reasons: When leaving or repairing the machine, park it on a level Figure 15 surface, turn off the machine, and remove the key. Tennant S960...
- Page 12 3.Open the dust box cover, unscrew the 6 hand nuts on the side, unplug the motor connection end, and take out the dust separator. (Figure 19) Figure 16 Figure 17 Figure 18 Figure 19 Tennant S960...
- Page 13 3.Unscrew the transparent cover counterclockwise, clean the filter, and install it clockwise (as shown in Figure 21). Figure 21 Tennant S960...
- Page 14 Only when the brake pedal first, then press the drive operator sits in the seat or adds pressure pedal, and the machine will travel can the machine operate normally, normally. providing safety protection and preventing accidents (Figure 22). Tennant S960...
- Page 15 (pleaserefer to 'Machine Maintenance') Driving the machine slowly on a slope: When going downhill, first adjust the speed control switch to slow down the machine speed, and then sweep the floor when the machine is going uphill instead Figure 26 Tennant S960...
- Page 16 Do not leave the battery in a low battery state (battery charge less than 5%), as this state can seriously affect the battery's lifespan. For long-term storage of machines, please check the battery level every 15 days. Battery level Tennant S960...
- Page 17 2.Turn off the machine, open the hopper by pulling the trigger, pay attention to safety when opening the trigger, prevent the hopper from slipping out, move the hopper and dispose of it. As shown in the figure(Figure 27). Tennant S960...
- Page 18 Replace the side brush and cylindrical brush Check if the filter screen is blocked Poor sweeping effect Check if the cylindrical brush is adjusted to the appropriate position Charge the battery until the charger is turned off Contact Tennant maintenance personnel Tennant S960...
- Page 19 Check the motor brush (check Drive assembly every 100 hours after the first 500 hours of operation) Drive belt Check for damage and wear Note: In extreme dusty conditions, more frequent maintenance may be necessary. Tennant S960...
- Page 20 Precautions for installation and use use. of batteries 1.Check each battery for presence before use to see if there is any damage, cleanliness, clear markings, and clean the battery surface with a dry cloth; Check the open circuit voltage of the battery, Tennant S960...
- Page 21 3.Place the front of the machine against the front of the truck or trailer. 4.Place obstacles behind each drive wheel to prevent the machine from sliding. Tennant S960...
- Page 22 The LED light of the smart charger indicates the working status Battery capacity LED (red) LED (yellow) LED (green) Standby Flash (once every 1 Charging below 50% second) Flash (once every 1 Charging 50% -75% second) Charging 75% Flash (once every 1 -100% second) Full of 100% Tennant S960...
- Page 23 Drive motor 1500 Fan motor Output voltage/ Type Current/A Input voltage/VAC Frequency/Hz Charger 220/110 50/60 (intelligent type) Tires Position Type Size Front wheel x1 Solid 300mm (0D) x 100mm wide Rear wheel x2 Solid 300mm (0D) x 100mm wide Tennant S960...
- Page 24 机器维护 Machine size Standard 1350MM 1380MM Tennant S960...
- Page 25 1350MM 1820MM Tennant S960...
- Page 26 Optional 1890MM 1380MM Tennant S960...
- Page 27 1890MM 1820MM...
- Page 28 Tennant Product Warranty Certificate (Main Card) (This warranty card is the main voucher for warranty services, please keep it properly) Warranty regulations: During the warranty period, any malfunctions that occur during normal use according to the user manual will be repaired free of charge. Please provide the warranty certificate and invoice for the repaired goods to the purchasing unit for free repair.
- Page 29 The mailing address is as follows: Address: Tennant Cleaning System Equipment (Shanghai) Co., Ltd.,Hongqiao Jiahui, Lane 928, Shenhong Road, Minhang District, Shanghai 2.
