Portable Dehumidifier

User Manual

Read and save these instructions before use

Customer Support:

Assistance Au Client:

Servicio de atencion a clientes:

Web: www.HoneywellAirComfort.com

USA: 1-800-474-2147 | usinfo@jmatek.com

CANADA^: canadainfo@jmatek.com

^ Canada Customer Support service available for models sold in Canada only.

^ Le Service Client Canadien est disponible uniquement pour les modèles vendus sur le territoire Canadien.

^ Servicio de Atención A Clientes en Canadá disponible solo para modelos vendidos en Canadá.

Model / Modèle / Modelo:

TPFIT25WK/ TPFIT25AWK /

TPFIT32WK / TPFIT32AWK

Check the website for FAQ's, usage guides and more!

Consultez le site Web pour les FAQ, les guides

d'utilisation et plus encore !

Consulte el sitio web para ver las preguntas

frecuentes, las guías de uso y mucho más.

www.HoneywellAirComfort.com

Product Registration

Need help?

Do you have a question about the TPFIT25WK and is the answer not in the manual?

Questions and answers

Summary of Contents for Honeywell TPFIT25WK

Page 1 Portable Dehumidifier User Manual Read and save these instructions before use Model / Modèle / Modelo: TPFIT25WK/ TPFIT25AWK / TPFIT32WK / TPFIT32AWK Check the website for FAQ's, usage guides and more! Consultez le site Web pour les FAQ, les guides...
Page 2 Amazon Echo device, to control the unit. Set up the Honeywell Air Comfort App on your smart phone or tablet to connect the Honeywell Smart Portable Dehumidifier for WiFi and Voice control (only available for Smart Dehumidifier models).
Page 3 THANK YOU Thank you for purchasing a Honeywell Portable Dehumidifier. This User Manual is intended to provide you with important information needed to set up, operate, maintain and troubleshoot this product. SAFETY RULES WARNING -- READ AND SAVE THESE INSTRUCTIONS BEFORE USING THIS PRODUCT.
Page 4 SAFETY RULES (CONTINUED) • DO NOT let children play with this appliance, packaging or included plastic bag. • If the unit is damaged or it malfunctions, do not continue to operate it. Unplug the product from the electrical outlet. Refer to the troubleshooting section and contact the customer support center.
Page 5 R32 SAFETY SYMBOL NOTE EXPLANATION This symbol shows that this appliance uses a flammable refrigerant. If the refrigerant WARNING is leaked and exposed to an external ignition source, there is a risk of fire. This symbol shows that the operation manual should be CAUTION read carefully.
Page 6 R32 SAFETY Additional warnings for appliances with R32 refrigerant gas. • Read the instructions carefully before using the appliance. • R32 refrigerant gas complies with UL60335-2-40 / UL60335-1. • This appliance contains a certain number of grams (see rating label at the back of the unit) of R32 refrigerant gas. The maximum refrigerant charge amount is not greater than R32 0.105kg (For TPFIT25) R32 0.11kg (for TPFIT32) based on UL60335-2-40.
Page 7 R32 SAFETY Transportation, marking, and storage for units. Transport of equipment containing flammable refrigerants must comply with local transport regulations. Marketing of equipment using signs must comply with local regulations. Disposal of equipment using flammable refrigerants must comply with national regulations. The storage of equipment should be in accordance with the manufacturer’s instructions.
Page 8 HOW A DEHUMIDIFIER WORKS When the dehumidifier is switched ON, a fan pulls moisture-laden air into the dehumidifier where it passes through dehumidifying coils inside the unit. These coils condense moisture from the air and collect it in the water tank. The dry air is then exhausted from the dehumidifier. The air flows through the air vents of the dehumidifier into the room as dry, warm air.
Page 9 SELECTING A LOCATION - IMPORTANT (CONTINUED) • Place the dehumidifier in an area where the temperature will not drop below 41°F (5°C) • Place the dehumidifier at least 17.7 inches (45 cm) away from other objects (e.g. curtains or furniture) that may restrict airflow from the back or through the air vents of the unit. •...
Page 10 UNPACKAGING THE DEHUMIDIFIER This Dehumidifier is packaged with a colored or transparent tape to secure some parts during transportation. Remove the colored or transparent packaging tape from the unit. Splash 1. Gently pull the water tank from out of the dehumidifier Guard 2.
Page 11 PARTS DESCRIPTION Control Panel Washable Dust Filter Handle 10) Direct Drain Outlet Splash Guard 11) Direct Drain Cap Foam Float 12) Cord Cable Tie Water Tank 13) Power Cord & Plug 14) Continuous Water Drain Tube Water Level Indicator Inner Dia: 0.5 in (1.27cm); Length: 3.28 ft (1 m) Casters Dehumidified Air Exhaust Vent...
Page 12 INSTALL THE CORD WINDER Once you have removed the cord winder accessories from the water tank - follow the steps below. Step 1: Line up the cord winder pieces to the mounting holes. Step 2: Rotate 45-degrees clock-wise. Step 3: Once you hear “click”, then you know the cord winder is ready for use. NOTE: Once the installation of the cord winder has been completed.
Page 13 USE & OPERATION CONTROL PANEL (10) 1) Filter Indicator light 8) Power Control 2) Timer Indicator Light 9) Mode Controls 3) Water Full Indicator Light - Laundry Mode 4) Humidity / Timer Set Controls - Dehumidifying Mode 5) Filter Alert - Comfort Mode 6) Timer Control - Continuous Mode...
Page 14 USE & OPERATION (CONTINUED) FUNCTION BUTTONS WI-FI PAIRING^ Before turning on Dehumidifier, press the button 6 times within 4 seconds to start WIFI pairing mode. The display sreen will show “CF” when in Wi-Fi pairing mode. When the Smart Dehumidifier is connected to the wifi function, the indicator light will be illuminated.
Page 15 USE & OPERATION (CONTINUED) FUNCTION BUTTONS (CONTINUED) Comfort Mode Dehumidifier automatically adjusts dehumidification Relative Humidity (RH) percentage settings based on ambient room temperature, for hassle-free operation. When ambient room temperature is 18°C / 64°F or lower, the dehumidifier adjusts to 55% RH. When ambient room temperature is between 18°C / 64°F and 25°C / 77°F, the dehumidifier adjusts to 50% RH.
Page 16 USE & OPERATION (CONTINUED) TIMER CONTROL The dehumidifier can be set to automatically switch ON or OFF for a selected period of time (between 0.5-24 hour intervals). The Timer hours selection is displayed on the Display Screen. NOTE: Before setting the Timer control, make sure there is power to the unit. Auto-Off Timer: While the unit is running, press , the timer...
Page 17 USE & OPERATION (CONTINUED) AUTO RESTART FUNCTION This unit is equipped with an Auto Restart feature. When there is a power outage, the dehumidifier should automatically resume all its previous settings upon regaining power. If it doesn't, simply Power ON the unit and reset the settings as desired. AUTOMATIC DEFROST Frost may build up on the internal coils of the unit.
Page 18 USE & OPERATION (CONTINUED) DRAINING THE WATER WARNING: Always drain and discard water collected from dehumidification. The water is not clean and cannot be used for drinking. 1. Draining water collected in the Water Tank The condensed water can be collected directly into the water tank. When the water tank is full, the dehumidifier will automatically shut OFF and the indicator will illuminate on the control panel followed by a beeping sound.
Page 19 USE & OPERATION (CONTINUED) DRAINING THE WATER (CONTINUED) 2. Continuous Water Drainage – Using a Continuous Water Drain Tube A continuous water drainage tube is included with this unit. To activate the continuous water draining function, you will require a suitable water drain (e.g. sink or drain hole at floor level) near the dehumidifier.
Page 20 USE & OPERATION (CONTINUED) DRAINING THE WATER (CONTINUED) If there are leaks, the Continuous Water Drain Tube and Cap may have loosened and may not be connected properly. Disconnect, replace and tighten again. Position the other end of the Continuous Water Drain Tube in the sink or drain. Make sure the tube is not bent or kinked which might stop the water flow.
Page 21 USE & OPERATION (CONTINUED) CLEANING & MAINTENANCE WARNING: Always switch OFF the dehumidifier and unplug it from the electrical outlet before attempting any cleaning or maintenance of this product. Appliance Maintenance: • Switch OFF the appliance before disconnecting the power supply. •...
Page 22 TROUBLESHOOTING GUIDE The following troubleshooting guide addresses the most common problems. If problems persist, call customer service. For more troubleshooting steps please visit: https://honeywellaircomfort.com/pages/portable-dehumidifier-faqs PROBLEM POSSIBLE CAUSE SOLUTION No electricity. Check for power. The power cord is not Remove and reconnect the power cord. Dehumidifier properly plugged in.
Page 23 TROUBLESHOOTING GUIDE (CONTINUED) PROBLEM POSSIBLE CAUSE SOLUTION Unit runs but Insufficient time for the the humidity After initial installation, allow 24 hours to maintain dehumidifier to remove level does desired dryness. moisture. not decrease The capacity of your dehumidifier may not be Area to be dehumidified adequate for the room it is used in.
Page 24 TROUBLESHOOTING GUIDE (CONTINUED) PROBLEM POSSIBLE CAUSE SOLUTION Check the connections between the hose and the drain outlet on the unit. See Continuous Water The garden hose/ drain Drainage section. hose may be loose. Check the tube of cap for tighten. Water on the floor You intended to use the...
Page 25 ERROR CODE GUIDE CODE POSSIBLE CAUSE POSSIBLE SOLUTIONS If the display shows “EH” flashing 3 times, it indicates the humidity Sensor may not be working . When this happens, the dehumidifier can still continue to function without Humidity Sensor the sensor, by setting the target humidity and turning off misalignment, manually when it has reached the target setting.
Page 26 Made in China © 2024 JMATEK Limited. All rights reserved. JMATEK North America LLC The Honeywell Trademark is used under license Alpharetta, Georgia 30005 USA from Honeywell International Inc. Honeywell International Inc. makes no Phone : 1-800-474-2147 representations or warranties with respect to this product.

This manual is also suitable for:

Tpfit25awk Tpfit32wk Tpfit32awk
