- Page 1 Electric Rethermalizer Installation and operating manual * 59589GC02- 2024.10 *Original instructions...
- Page 2 Installation diagram...
- Page 3 Foreword Read the following instructions, including the warranty terms before installing and using the appliance. Visit our website www.electroluxprofessional.com and open the Support section to: Register your product Get hints & tips of your product, service and repair information The installation, use and maintenance manual (hereinafter Manual) provides the user with information necessary for correct and safe use of the appliance.
-
Page 4: Table Of Contents
Contents A WARNING AND SAFETY INFORMATION....................6 General information ........................6 Personal protection equipment ......................7 General safety ..........................7 Protection devices installed on the appliance ..................8 Safety signs to be placed on the appliance or near its area ..............8 Reasonably foreseeable improper use .................... - Page 5 APPLIANCE DISPOSAL........................22 Procedure regarding appliance disposal ..................22...
-
Page 6: Awarning And Safety Information
WARNING AND SAFETY INFORMATION General information canteens, hospitals and in commercial enterprises such bakeries, To ensure safe use of the appliance and a butcheries, etc., not for continuous proper understanding of the manual it is mass production of food. Any other use necessary to be familiar with the terms and is deemed improper. -
Page 7: Personal Protection Equipment
Personal protection equipment Summary table of the Personal Protection Equipment (PPE) to be used during the various stages of the appliance's service life. Stage Protective Safety Gloves Glasses Safety garments footwear helmet ● ○ ○ — — Transport — ● ○... -
Page 8: Protection Devices Installed On The Appliance
Protection devices installed on Disconnect the the appliance appliance from the power supply Guards before carrying out The appliance has: any installation, • fixed guards (e.g. casings, covers, side assembly, cleaning panels, etc.), fixed to the appliance and/ or maintenance or frame with screws or quick-release procedure. -
Page 9: Reasonably Foreseeable Improper Use
Reasonably foreseeable To preserve these conditions, the areas improper use around the appliance must always be: • kept free of obstacles (e.g. ladders, tools, Improper use is any use different from that containers, boxes, etc.); specified in this manual. During appliance operation, other types of work or activities •... -
Page 10: Transport, Handling And Storage
Residual risk Description of Residual risk Description of hazardous situation hazardous situation Chemical Contact with chemical Sudden The operator for normal substances (e.g. closure appliance use could detergent, rinse aid, suddenly and scale remover, etc.) deliberately close the without taking adequate lid/door/oven door (if safety precautions. -
Page 11: Water Connection
• Do not allow oil or grease to come into recommended that service is undertaken contact with plastic parts. Do not allow by Electrolux Professional SpA authorised dirt, fat, food or other residuals to form engineers every 12 months, in accordance deposits on the appliance. -
Page 12: Precautions For Use And Maintenance
– insufficient and/or abnormal capacity of the electrical accordance with Electrolux Professional user and mainte- systems (current/voltage/frequency, including spikes nance documentation made available in paper or electronic and/or outages);... -
Page 13: Ctechnical Data
(1) week of subject to local terms and conditions. delivery unless otherwise agreed; Check on Electrolux Professional website the list of authorized • product with original serial numbers that have been customer care. removed, altered or cannot be readily determined;... -
Page 14: Appliance And Manufacturer's Identification Data
Power unit El. dust and water protection rating CE marking certification group dust and water protection rating Electrolux Professional SpA Viale Treviso 15 33170 Porde- manufacturer none Italy Electrical models Tank capacity (filling Power supply cable Power supply voltage Nominal max. -
Page 15: Keeping The Manual
Customer. port personnel. Manufacturer Electrolux Professional SpA or any other The employer, workplace manager or service technician are service centre authorised by Electrolux responsible for identifying and choosing adequate and suitable personal protection equipment to be worn by operators, in Professional SpA. -
Page 16: Einstallation And Assembly
INSTALLATION AND ASSEMBLY Introduction • for appliances with stainless steel surfaces, remove the protective film very slowly without tearing it, to avoid leaving WARNING glue stuck to the surface; • should this happen, remove the traces of glue with a non- Refer to “Warning and Safety corrosive solvent, rinsing it off and drying thoroughly;... -
Page 17: Electrical Connections
Electrical connections WARNING Before connecting, make sure the mains voltage and frequency match those indicated on the appliance dataplate. Our appliances are equipped with a power cable H07–RN-F 3G 2.5mm rubber-insulated type, with plug IEC 309 3P+N+T 380/480V 32A (version 3P+N) or IEC 309 2P+T 200/250V 32A (version 1P). Protect the cable section outside the appliance with a metal or rigid plastic pipe. -
Page 18: Fnormal Appliance Use
NORMAL APPLIANCE USE WARNING IMPORTANT The Customer must make sure his personnel have Refer to “Warning and Safety understood the instructions received and in partic- ular those regarding work hygiene and safety in use Information“. of the appliance. Characteristics of personnel enabled to Basic requirements for appliance use operate on the appliance •... -
Page 19: At The End Of Work
IMPORTANT Water drain The “PreH“ message can appears on the display. At the end of the working day always empty the tank. It means that the unit is working properly but the water temperature has not yet reach the minium Always wait the water cools down till 80℃... -
Page 20: Maintenance Intervals
Maintenance intervals It is advisable to carry out the checks with the frequency given in the following table: Maintenance, inspections, checks and Frequency Responsability cleaning Ordinary cleaning • Daily • Operator • general cleaning of appliance and surrounding area Mechanical protection devices •... -
Page 21: Tank Cleaning (Daily)
CAUTION Tank cleaning (daily) Every day before starting the usage, IMPORTANT check the the right efficiency of level It is advisable to carry out this operation after the sensors (“S1“, “S2“, “S3“). It is strongly appliance has cooled (the inertia of heating, even if suggested to clean the sensor by a plastic switched off, can damage the tank if empty). - Page 22 Messages Relay output Cause Alarm ON output; the cycle Long power failure duration. resumes from the start of the current phase. External alarm contact if I2F=EAL is active after the Alarm ON. did time interval. External alarm contact if Alarm ON; heater OFF. I2F=BAL is active after the did time interval.
