VIBRAPHONE
CONCERT
YV-4110 ( M ) YV-3910 ( M ) YV-3710 ( M ) YV-2700 ( G )
Owner's Manual
Benutzerhandbuch
Mode d'emploi
Manual de instrucciones
Manual do Proprietário
Руководство пользователя
使用说明书
사용설명서
使用說明書
Be sure to read the "PRECAUTIONS" on page 6.
Die „VORSICHTSMASSNAHMEN" auf Seite 6 lesen.
Veillez à lire les « PRÉCAUTIONS D'USAGE » à la page 6.
Asegúrese de leer "PRECAUCIONES" en la página 6.
Certifique-se de ler as "PRECAUÇÕES" na página 6.
请务必阅读� 6 页的 ���事项�。
6 페이지의 "안전 주의사항" 을 반드시 읽어 주십시오 .
�務必��� 6 頁的「��事項」 �
«
»
. 6.
EN
DE
FR
ES
PT
RU
ZH-CN
KO
ZH-TW

Advertisement

loading
Need help?

Need help?

Do you have a question about the CONCERT YV-4110 and is the answer not in the manual?

Questions and answers

Related Manuals for Yamaha CONCERT YV-4110

Summary of Contents for Yamaha CONCERT YV-4110

  • Page 1 VIBRAPHONE CONCERT YV-4110 ( M ) YV-3910 ( M ) YV-3710 ( M ) YV-2700 ( G ) Owner's Manual Benutzerhandbuch Mode d’emploi Manual de instrucciones Manual do Proprietário Руководство пользователя 使用说明书 사용설명서 使用說明書 Be sure to read the “PRECAUTIONS” on page 6. Die „VORSICHTSMASSNAHMEN“...
  • Page 2 This equipment generates/uses radio The above statements apply ONLY to those products distributed by Yamaha frequencies and, if not installed and used according to the instructions found in Corporation of America or its subsidiaries.
  • Page 3 Information for users on collection and disposal of old equipment and used batteries: These symbols on the products, packaging, and/or accompanying documents mean that used electrical and electronic products and batteries should not be mixed with general household waste. For proper treatment, recovery and recycling of old products and used batteries, please take them to applicable collec- tion points, in accordance with your national legislation.
  • Page 4 PRECAUTIONS Please follow the following instructions to ensure that you are using your vibraphone in a safe manner. A responsible adult should provide proper instruction on how to properly use and treat the instrument before allowing a child to play the instrument. In order to prevent fire, electric shock, or injury, make sure that all precautions described below are followed.
  • Page 5 Doing so can result in pinched hands. Be sure to • Always use an AC adapter that meets Yamaha specifica- hold the side frame when making height adjustments. tions. The use of any other AC adapter could cause damage.
  • Page 6 YV-4110(M) YV-3910(M) YV-3710(M) YV-2700(G) Nomenclature Accidental Tone Bars Controller Natural Tone Bars Fan Belt Large End Small End Slide Leg Rail No. 1 Resonators Slant Shaft (Natural Tone Side) Driver Small Leg Large Leg Resonators Pedal Stay Pedal (Accidental Tone Side) AC Adapter Caster...
  • Page 7 YV-4110(M) YV-3910(M) YV-3710(M) Package Contents The shipping carton for your vibraphone should contain the parts shown below. * The rails and resonators in the packages are folded. Before assembling the instrument, confirm that all listed parts are included. * In the event that a part is missing, please contact the shop where the instrument was purchased. •...
  • Page 8 YV-4110(M) YV-3910(M) YV-3710(M) Package Contents ■ Dividable Parts and Collapsible Parts The larger parts of the YV-4110(M) YV-3910(M) YV-3710(M) are designed to be either collapsible or easy to di- vide into smaller components. When the instrument is broken down, its compact size makes it easy to transport and storage requires a minimum amount of space.
  • Page 9 YV-4110(M) YV-3910(M) YV-3710(M) Assembly • For safety, assembly should be performed by two or more people in a place that provides sufficient space. • Be careful not to pinch your fingers when assembling the instrument. In particular, when assembling the CAUTION rails and resonators, two people should work together while checking each step carefully.
  • Page 10 Rail (2): This rail has a rail clamp and more posts than rail (3) or (4). The clamp side should face the player. Rail (3): This rail has a rail clamp and fewer posts than rail (2). The clamp side should face the audience. Rail (4): This rail has a Yamaha logo. Logo side should face the audience. Post...
  • Page 11 YV-4110(M) YV-3910(M) YV-3710(M) Assembly Attach the sustain damper. Turn the fixing bolt (damper arm axle) of the damper arm attachment counterclockwise until the axle has fully disap- peared in the attachment hole. Align the damper arm hole with the damper arm axle. Turn the fixing bolt of the damper arm attachment clockwise to insert the damper arm axle into the sustain damper arm.
  • Page 12 YV-4110(M) YV-3910(M) YV-3710(M) Assembly Align the holes in both ends of the damper spring stopper with the protrusions of the fittings on the bottom surfaces of rails (2) and (3) and insert the protrusions into the holes. Bottom View Damper Spring Stopper Protrusion Rail (2)
  • Page 13 YV-4110(M) YV-3910(M) YV-3710(M) Assembly Attach the resonators. Insert the resonators from underneath the frame. First, rest the small end and then the large end onto the resonator holders (rubber). NOTICE • Be careful not to confuse the natural tone side and accidental tone side resonators. •...
  • Page 14 YV-4110(M) YV-3910(M) YV-3710(M) Assembly Set the tone bars. (Refer to the illustration of step 3-3 ) Raise the pedal until the knurled part is fully retracted, and fix the center rod by tightening the center rod fixing bolt. Engage the rail clamp on rail (2) and rail (3) with rail (1) and rail (4), respectively. Rail (3) Rail (4) Rail Clamp...
  • Page 15 YV-4110(M) YV-3910(M) YV-3710(M) Assembly Attach the driver. Bottom View Loosen the fixing bolts at the bottom of rails (2) and (3) on the small end, and slide both fittings in the direction of the Bass Side Treble Side large end. Fully insert the driver mount into the support fitting.
  • Page 16 YV-4110(M) YV-3910(M) YV-3710(M) Assembly Connect the driver with the controller. Driver Connect the MOTOR IN terminal of the driver with the MOTOR OUT terminal of the controller using the supplied 8P DIN cable*. To connect them, align the arrow mark ( ) on the plug with the screw next to the jack.
  • Page 17 YV-4110(M) YV-3910(M) YV-3710(M) Assembly 10-2 Wire Clip Adjustment To facilitate packing the unit for shipping, the wire clip is initially set at a low position. For normal use this clip should be adjusted as follows: With the pedal released, loosen the fixing bolt of the wire clip, shift the clip up until distance A in the illustration at right is 1/16"...
  • Page 18 YV-4110(M) YV-3910(M) YV-3710(M) YV-2700(G) Before Playing ■ Power Supply Prepare the supplied AC adapter. • Be sure to use the supplied AC adapter. Using a different adapter may cause damage not covered by the warranty. CAUTION Connect the small plug of the AC adapter to the DC 12-15V IN jack on the controller. Plug the AC adapter into a power outlet.
  • Page 19 YV-2700(G) Package Contents The shipping carton for your vibraphone should contain the parts shown below. * The rails and resonators in the packages are folded. Before assembling the instrument, confirm that all listed parts are included. * In the event that a part is missing, please contact the shop where the instrument was purchased. •...
  • Page 20 YV-2700(G) Assembly • For safety, assembly should be performed by two or more people in a place that provides sufficient space. • Be careful not to pinch your fingers when assembling the instrument. In particular, when assembling the CAUTION rails and resonators, two people must work together while checking each step carefully. Loosen the slide leg fixing bolts of the large and the small leg, and remove the four slide legs.
  • Page 21 YV-2700(G) Assembly Place the large leg, small leg, pedal stay and reinforcement stay so that after assembly each part will be positioned as illustrated. Large Leg Bass Side Reinforcement Stay Audience Side Small Leg Treble Side Pedal Stay Pedal Player Side Connect the large leg and small leg with the pedal stay and the reinforcement stay.
  • Page 22 YV-2700(G) Assembly Connect the slide legs with the small and large legs. • When adjusting the tone bar height, be sure to have two people supporting the frame, one at each end using both hands. CAUTION Treble Side Align the legs from above so that the slide legs slide into the corresponding leg holes.
  • Page 23 YV-2700(G) Assembly Attach the round belt (fan belt). Fan Side Slip the round belt (fan belt) over the fan side pulley first, and then pull it over the flange of the driver pulley. If the belt cannot be mounted because the distance be- tween the pulleys is too wide, or the belt slips due to a pulley distance that is too narrow, loosen the two driver positioning screws (see illustration at right) to adjust...
  • Page 24 * The contents of this manual apply to the latest specifications as of the publishing date. To obtain the latest manual, access the Yamaha website then download the manual file. Since specifications, equipment or separately sold accessories may not be the same in every locale, please check with your Yamaha dealer.
  • Page 25 10-1 Nakazawa-cho, Chuo-ku, Hamamatsu, 430-8650 Japan ©2014 Yamaha Corporation Published 06/2024 2024 年 6 月发行 IPCP-U0 〒 430-8650 静岡県浜松市中央区中沢町 10-1 VHU7520...
