- Page 1 LOTOS TECHNOLOGY PLASMA CUTTER LTP5800D www.uwelding.com ®...
- Page 3 Lotos Technology LTP58 0 0D Quick Setup Instructions Power plug wiring identification: The GREEN wire with the yellow stripe is ground wire. The other two wires have equal usage. They are both hot wires for 240 V. Under 120 V, one is hot and one is netural .
- Page 4 8. Replace your consumables (tip, electrode, and cup) when they become worn out. The correct consumable type for this machine is PCS22, PCS33, PCS77, etc. All accessories and consumables can be purchased at www.uwelding.com or Lotos's authorized resellers.
- Page 5 Plasma Cutter LTP5800D Troubleshooting Flowchat ........16...
- Page 6 Introduction Overview Dear Valued Customer: Thank you for purchasing a Lotos Technology plasma cutter! Feel free to check out our other products at www.uwelding.com. The User Manual documents policies and procedures for proper operation of the equipment. IMPORTANT: Please review this manual thoroughly before attempting to operate the equipment.
- Page 7 S a f e t y R e c o m m e n d a t i o n s - R e a d B e f o r e U s i n g Overview Protect yourself and others from injury by reading and following these precautions. Caution Recommendations •...
- Page 8 • Keep cylinders away from any welding activities or rack to prevent falling or tipping. other electrical circuits. If you encounter any difficulties during set up or operation: • Consult this manual. • Contact Lotos Customer Service by visiting http://www.uwelding.com/contact/. ®...
- Page 9 California Proposition 65 Warnings For Gasoline Engines: Welding or cutting equipment Engine exhaust contains chemicals produces fumes or gases which known to the State of California to contain chemicals known to the State cause cancer, birth defects, or other of California to cause birth defects reproductive harm.
- Page 10 Equipment General Overview The LTP5800D utilizes advanced inverter technology. It converts 50/60Hz frequency to high frequency (over 100 KHz), then applies step-down voltage and current rectification By employing switch power inverter technology, we've significantly reduced the size and weight of the main transformer while increasing efficiency by 30%.
- Page 11 Not Support Not Support *Production cut thickness are the results of Lotos’ laboratory testing. For optimum cut quality, cutting speeds may vary based on different cutting applications. *All the recommended current values are tested under 240 V. While using under 120 V,...
- Page 12 Digital Display Screen A ir Pressure Adjust Ground Connection Pilot Arc Connection Switch Power Plug & Figure 2.1: Front Panel Diagram Air Output Air In C up Power Cord Figure 2.2: Power Cord Plug Connection Figure 2.3: Air Regulator Configuration...
- Page 13 Plasma Cutter LTP5800D Connections First make sure all the connection are corrected (as depicted in the diagram below); Power Ground A ir Compressor Air Compress Ground Clamp Ground Clamp Work Piece Workpiece Torch Torch Figure 2.4: Connecting Cables to Machine...
- Page 14 Digital Screen Instruction Press the button and Switch between 2T/4T mode rotate the knob to adjust PA or PT PA：Pilot arc time PT: Post flow time Press the button to AIR to enter 1) AIR PRESSURE INDICATOR: AIR CHECK mode.
- Page 15 Installation Power Cord Plug Connection (Figure 2.2) 1. Connect the power cord plug to the appropriate voltage outlet. Use proper connections to avoid internal circuit damage. Typically, the ground wire is GREEN with a YELLOW stripe. 2. Ensure a secure connection between the power cord and power switch to prevent oxidation.
- Page 16 Operating the Plasma Cutter 1. Set the air pressure on your compressor to 60 – 65 psi for optimal machine performance. 2. To start cutting, bring the torch tip into direct contact with the workpiece edge. For thicker materials, begin over a pre-drilled pilot hole. Press the torch button to initiate cutting.
- Page 17 6. Replace worn consumables promptly to prevent damage. The following troubleshooting guide is provided for reference only. Lotos Technology will NOT be liable for any injury or damage resulting from these actions. Always disconnect electrical power and air supply before performing inspections or reconnections.
- Page 18 Plasma Cutter LTP5800D Troubleshooting Flowchat Note: If the O.C. light is on before operating the machine, please call us at (408) 739-2329. If the O.C. light is on while operating the machine, stop using the machine for a few minutes until the light is off.
- Page 20 Plasma Cutter LTP5800D Other Accessories PT01 GC01 Ground Cable W G03 N CP243 PC S 2 PC S 3 3 PC S77...
