[Please read this installation & operation manual before install and use this
AW-BK901 Conventional Reflective Beam Detector
Installation and Operation Manual
AW-BK901 Conventional Reflective Beam Detector
Page 1
ASENWARE LTD.
Address: 8-701,Dongfangming Industry Zone, Dabao Road., Baoan, Shenzhen, China-518101
Contact Ana Wu Mobile:86-136-3251-2808 email:sales08@asenware.com
Advertisement
Related Manuals for ASENWARE AW-BK901
Summary of Contents for ASENWARE AW-BK901
- Page 1 [Please read this installation & operation manual before install and use this AW-BK901 Conventional Reflective Beam Detector Installation and Operation Manual AW-BK901 Conventional Reflective Beam Detector Page 1 ASENWARE LTD. Address: 8-701,Dongfangming Industry Zone, Dabao Road., Baoan, Shenzhen, China-518101 Contact Ana Wu Mobile:86-136-3251-2808 email:sales08@asenware.com...
- Page 2 Please read this installation & operation manual before install and use this device AW-BK901 Conventional Reflective Beam Detector Product Safety To prevent severe injury and loss of life or property, read the instruction carefully before installing the beam detector to ensure proper and safe operation of the system.
- Page 3 Please read this installation & operation manual before install and use this device AW-BK901 Conventional Reflective Beam Detector Table of Content Introduction ................................4 Overview ................................4 Main Features ..............................4 Technical Specification ............................. 5 Product Appearance ............................6 Principle of the Beam Detector ......................... 6 Installation Procedures ............................
- Page 4 The AW-BK901 has four adjustable operational range of between 8 to 20, 40, 70 and 100 meters beside with three adjustable sensitivity setting ranges from 2.6 dB to 4.8 dB to meet the specific environmental requirement.
- Page 5 Please read this installation & operation manual before install and use this device AW-BK901 Conventional Reflective Beam Detector Technical Specification Part Number AW-BK901 Standard Listed LPCB Pending Compliance EN 54-12 Fire Detection and Alarm Systems BS 5839 Part 1:2002 Specification...
- Page 6 Product Appearance Principle of the Beam Detector The AW-BK901 reflective optical beam smoke detector incorporates a light transmitter and the detector on the same unit. The light path is created by reflecting light emitted from the transmitter off a retro- reflector, meaning it is reflects light back to its source with a minimum of scattering, which is placed opposite the detector.
- Page 7 Please read this installation & operation manual before install and use this device AW-BK901 Conventional Reflective Beam Detector Installation Procedures Mounting Details Figure 2: Detector Diagram LED Indicators LED Indicators Color Function Fire Illuminates when at least one fire alarm event occur.
- Page 8 Please read this installation & operation manual before install and use this device AW-BK901 Conventional Reflective Beam Detector 1. Under flat spare area. If the ceiling height is less than 8 meters, the beam detector should be installed 0.5 meter to 1 meter below the ceiling level. Refer to Figure 3.
- Page 9 Figure 7: Wiring Terminals Programming Sensitivity and Span The AW-BK901 sensitivity and the operation range can be adjusted through hand held programmer on project site. The programmer can be purchased separately. It is mandatory for the commissioning personnel have programmer tool in order to adjust the detector according to the site situation and environmental requirement.
- Page 10 Please read this installation & operation manual before install and use this device AW-BK901 Conventional Reflective Beam Detector Figure 8: Connection with the programmer 2. Switch on the programmer, then press button “1” to view the address [for addressable system use only], code and sensitivity level.
- Page 11 Please read this installation & operation manual before install and use this device AW-BK901 Conventional Reflective Beam Detector must be powered off. Reference: Beam Pathway Length Span 1: 8 to 20 meters Short Path Span 2: 20 to 40 meters Short Path...
- Page 12 Please read this installation & operation manual before install and use this device AW-BK901 Conventional Reflective Beam Detector Commissioning Preparation 1. Make sure both beam detector and reflective mirror are properly and securely mounted. 2. Make sure that the line of sight is clear and both beam detector and reflective mirror are in placed with correct axis angle.
- Page 13 Please read this installation & operation manual before install and use this device AW-BK901 Conventional Reflective Beam Detector Keep the detector run for at least 20 seconds then proceed to the next step. Step 5: Testing Fire Signal a. Using supplied Opaque/Translucent materials, block the half of the beam detector with the translucent portion of the material.
- Page 14 Please read this installation & operation manual before install and use this device AW-BK901 Conventional Reflective Beam Detector Self-diagnosis on Optical Signal The detector has functions of checking emitting, receiving and amplifying circuit. When there is fault with these three parts of circuit during operation, the detector will generate fault information.
- Page 15 Please read this installation & operation manual before install and use this device AW-BK901 Conventional Reflective Beam Detector Appendix 1 Limitation of Smoke Detectors The smoke detector is designed for triggering and initiating emergency re equipment’s, but it only functions when matching with other equipment’s. Installation of this smoke detector must conform electrical codes and standards in your country.
