Page 2 Opening and/or repairing your device can present electric shock, device damage, fire and personal injury risks, and other hazards. Before servicing the product, read the full set of precautions in this document. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 3 Use the diagnostic steps and same language to colleagues testing recommended in this and customers. section to identify the source of device problems and issues. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 4 Liquid damage indicators Tools and Fixtures Assembly instructions Replacement Parts Display Graphite sheets Repair Flows Mid-frame mmWave Rear camera Top speaker Front camera Battery Logic board Bottom speaker Mic1 Bracket Enclosure Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 5 Connectors Location mmWave Top Speaker Mic3 Mic2 Logic board Enclosure Bottom Speaker Top Speaker Vibrator Display Rear Camera Power mmWave Front Camera Wireless Charge Proximity sensor UDFPS Testing Software resources Glossary Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 6 Change the Midframe Screw Qty from 7 to 8. @P.78 Add the callout for the thermal rework. @P.83 Add the Note for exceptional case for coaxial cable reuse while only changing either Ant1 board or Ant4 board. @P.155 Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 7 (yellow highlight for this version change) V2.1 Feb, 2023 This is Only applying to when there is” Sidekey damage”. Add replacement parts: sidekey GPN:G949-00361-00. @P.37 @P.172 Disassemble the Sidekey @P.177 Assemble the Sidekey @P.180 Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 8 Add the caution avoiding scratching the outside of the display flex against the midframe. @P.67~68 Modify the Troubleshooting for Mic3 @P.192 June 2024 Removed proprietary references Added disclaimers Updated tools and fixtures names and part numbers Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 10 Laser Module: Dispose of the battery in a manner in ● Made in Austria. ams AG, Tobelbader Str. 30, accordance with local regulations. 8141 Oberpremstätten, Austria Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 12 Swelling or electrolyte leakage Dent Bubbling Imprinted line *These are examples of potentially dangerous battery conditions but don't reflect all possible dangerous conditions. Please follow general safety guidance outlined in this document. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 14 Reusable with Coaxial Bottom cleaning SIM Tray Mid-frame mmWave cable #8 speaker Not Reusable after disassembly Display RF Thermal Logic Coaxial Enclosure USB-C cowling Display cowling Battery Module board cable #1 Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 15 After any repair that requires you to If this process isn’t followed, the touch function of the screen may open the phone, complete the display touch calibration during not work as intended. first boot. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 16 It’s the ESD. Protective bags Avoid touching pins Pack all ESD-sensitive parts Don’t touch pins with use of in metalized protective bags during ESD-safe tools to handle shipping. components. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 17 Since thread locking adhesive can’t replaced with a new screw. be reactivated, replace each used screw with a new screw after removal. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 18 There’re two LDI on this device. ● In the SIM card slot, on the mid-frame (visible without ● disassembling the device). Another on mid-frame (disassemble to inspect). ● Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 20 Google-approved fixtures - Pixel 7 Pro Google-approved fixtures are Google tested and are strongly encouraged to ensure high quality and safe repairs. Pixel 7 Pro Battery Pixel 7 Pro Cleaning Pixel 7 Pro Cleaning Pixel 7 Pro Enclosure Pixel 7 Pro Enclosure PSA...
Page 21 Google-approved fixtures Google-approved fixtures are Google tested and are strongly encouraged to ensure high quality and safe repairs. Upper : SIM TRAY EJECTOR Lower : CONNECT DSSY Universal Disassembly Universal Disassembly Universal adsorption Universal Press Fixture Fixture - Universal Universal Scraper...
Page 22 Dust-free Cotton Plastic ESD Tweezers SIM card ejection pin swabs Screwdriver Torx Plus 3M UPUV or AP111 Adjustable type torque Heating plate ESD stick (Isopropyl Alcohol) Primer screwdriver [Optional] Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page 22...
Page 23 Google-recommended supplier. Sankol lubricant Masking tape Ionizing air fan Ionizing air fan Table C-Clamp Suction Cup CFD 409Z_V2 Fishing Line Feeler gauge Deglue Machine (Thickness 0.4mm, 13.9kg/30lb) Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page 23...
Page 24 Safety items Safety items are suggested to ensure high quality and safe repairs. These items don't need to be purchased from a Google recommended supplier. Safety Glasses Heat Resistant Cut Resistant Nitrile or Lint-Free Protective Gloves Protective Gloves Gloves Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 25 Google authorized replacement parts, Performance within product specifications such as aftermarket batteries, may impact ● device safety, reliability and performance. cannot be assured if Google authorized replacement parts are not used. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 26 Display module Enclosure G949-00300-01 G949-00298-01 G949-00299-01 Multiple Part Numbers Multiple Part Numbers Multiple Part Numbers Mid-frame_sub6 mmWave module Ant4 Board Battery Display cowling Trim PSA G730-06100-01 G806-06898-03 G949-00301-01 G949-00302-01 G949-00303-01 G949-00304-01 Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 27 Top Speaker Sim Tray G864-00520-01 G853-01223-01 G863-00403-04 G806-06257-03 G250-05753-00 Multiple Part Numbers Bottom Speaker Screw MMwave bracket sub6 bracket Mic1 Bracket mmWave thermal pad G863-00402-03 G730-06101-13 G250-06333-00 G730-06099-11 G730-06099-12 G806-06083-01 Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 28 Replacement parts cleaning FOAM Sub-6 Spring ANT7 Grounding SOC thermal pad RF thermal pad Coaxial cable #1 G806-06182-01 G853-01244-01 G853-01233-02 G806-06020-01 G806-04615-11 G821-00811-53 Coaxial cable #4 Coaxial cable #8 G821-00814-50 G821-00812-01 Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 29 Replacement parts cleaning Ant1 Adhesive Ant1 Board Top spk Adhesive Mmwave_flex_CPSA_1 Mmwave_flex_CPSA_2 Mmwave_flex_CPSA_3 G806-07334-01 G806-07335-01 G806-07336-01 G806-06207-01 G806-06332-01 G949-00347-00 Sidekey Volume button KAPTON G949-00361-00 Multiple Part Numbers G806-06364-01 Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 30 Visor film FCAM film G852-01898-01 G852-02360-01 G852-02270-01 G852-02350-01 G806-07704-01 G806-07703-01 copper G_liner_Service BG film RCAM liner UW RCAM liner tele RCAM liner protective film G806-07706-01 G806-07705-01 G806-07707-01 G806-07708-01 G806-07710-01 G806-07709-01 Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 31 Reusable Reusable Not Reusable without with cleaning after disassembly Replacement parts cleaning Mic protective liner G806-03591-01 Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 33 To replace the battery: Remove the display, graphite sheets, mid-frame, then the battery To remove the logic board: Remove the display, graphite sheets, mid-frame, mmWave, rear camera, top speaker, front camera, battery, then the logic board Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 34 To reinstall the battery: Battery, mid-frame, graphite sheets, then display To reinstall the logic board: Logic board, battery, front camera, top speaker, rear camera, mmWave, mid-frame, graphite sheets, then display Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 35 Repair Flows Table of contents Disassembly instructions Display Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 36 Ionizing air fan repair, be sure Pixel 7 Pro Enclosure Holder power off Pixel 7 Pro Enclosure PSA Align & CG Press Cover the device and Pixel 7 Pro Battery Press disconnect Pixel 7 Pro Cleaning Cover CG...
Page 37 Use safety gloves to handle damaged displays as some splinter during removal and could cause injury. Apply protective film to broken glass before removal. Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 38 Apply protective film to broken glass before removal. Review all safety precautions before beginning work. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 39 Caution: Heating plate is a Hot Surface. Use caution as it could cause burns. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 40 There is a groove which can help to avoid pressing the power button accidentally. beginning work. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 41 Don't insert ESD Universal Disassembly ESD stick beyond recommended distance into device. This is to avoid inserting tools between glass, display and trim. Refer to the NG and OK picture, in Fig4. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 42 Reattach the Display front protective film after taking out the device from the fixture. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 43 Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 44 ● Be careful not to stretch the display flex, to prevent part damage. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 45 Do not reuse the part Using the Universal Fish line tool avoids damage the components. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 46 No need to apply one to a damaged screen that will be replaced. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 48 Use an Universal Disassembly ESD stick or Deglue Machine ● ● Pixel 7 Pro Cleaning Cover CG and place the cover. to clean the residual glue out of the Display. Use a Deglue Machine to clean the residual glue out of the ●...
Page 49 Do not touch the adhesive. If it gets dirty, change for another one. Once Primer has been applied, complete assembly in 25 mins. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 50 Adhesive alignment Enclosure to adhesive Align by the two alignment posts Place the adhesive in the Pixel 7 Pro Enclosure PSA Align & Vertically place the Enclosure into the pocket in the indicated ● ● CG Press Cover with the ESD tweezers.
Page 51 Activate the PSA Remove Enclosure Gently press the all around adhesive by hands, to enhance Remove the Enclosure from the Pixel 7 Pro Enclosure PSA ● ● the bonding between Enclosure and adhesive. Align & CG Press Cover vertically. Take out the Enclosure vertically.
Page 52 Remove the liner (1st layer) 1st layer liner 2nd layer liner Pick the tab here Place the Enclosure in the Pixel 7 Pro Enclosure Holder. Slowly pull the liner to avoid lifting the adhesive, with the pull ● ● tab as the figure shown.
Page 53 (as shown above red figure). Once Primer has been applied, complete assembly in 25 mins. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 54 Enclosure Location : Top Speaker spring/MLB spring A & B). panel self calibration is in progress. Follow the instruction below: Calibration Note Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 55 This step is only performed if the display or the mainboard has Make sure the trim snaps do not contact the adhesive. been replaced Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 56 Part: G806-07704-01 (FCAM Film) G806-07710-01 (copper protective film) Part: FCAM Cap G852-02360-01 ( Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 57 Press the top side middle first, and then follow on 2 long sides and bottom side. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 58 Place in holder Place in holder Place it in the Universal press fixture and press the handle Place the device in the Pixel 7 Pro Enclosure Holder and place ● ● down for 30 seconds. the Press cover on top.
Page 59 Repair Flows Table of contents Disassembly instructions Graphite sheets Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 60 Tools Parts Remove the Pixel 7 Pro Enclosure Holder G864-00520-01 following ESD Tweezers Graphite sheets items first: Universal scraper Display module ● Caution! Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 61 Be careful not to puncture the battery while using the tweezers. Do not reuse the part. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 62 Repair Flows Table of contents Assembly instructions Graphite sheets Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 63 ANT7 spring MLB spring A Bottom Speaker spring A MLB spring B Bottom Speaker spring B Mid-frame spring Bottom Speaker spring C Visually check the spring before attaching the graphite. ● Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 64 Adhere graphite sheet Use the Universal Scraper and roll the top side of graphite ● With the device in the Pixel 7 Pro Enclosure Holder, place ● sheet. Ensure there are no air pockets. Use the smaller the Graphite sheet, align by the outline of Enclosure.
Page 65 Remove the release liner with the ESD tweezers. ● Avoid rolling over the gaskets/springs, as it may deform them. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 66 Repair Flows Table of contents Disassembly instructions Mid-frame Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 67 Pixel 7 Pro Screw Cover items first: Torx plus 3IP screwdriver ESD tweezers Universal Disassembly ESD Display module ● stick Graphite sheets ● Caution! Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 68 Mid-frame replacement- Cont. Parts G853-01223-01 G806-04615-11 USB-C Cowling RF thermal pad G949-00300-01 Mid-frame_mmWave G949-00301-01 Mid-frame_Sub-6 G250-05753-00 Screws *8 G806-06020-01 SOC thermal pad Caution! Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 70 Screw cover Remove screws Remove 8 Mid-frame Screws with a Torx Plus 3IP screwdriver. Place the Pixel 7 Pro Screw Cover on the Pixel 7 Pro ● ● Enclosure Holder. The 2 alignment pins are to avoid Then remove the Pixel 7 Pro Screw Cover.
Page 71 Remove USB-C cowling with ESD tweezers. ● Remove Mid frame with ESD tweezers by gripping it in the ● center, as shown above. Part: G853-01223-01 (USB-C cowling) Part: G949-00300-01 (Mid-frame_mmWave) Part: G949-00301-01 (Mid-frame_Sub-6) Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 72 Repair Flows Table of contents Assembly instructions Mid-frame Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 73 This step is for new and reclaim Mid-frame. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Caution! Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page Review all safety precautions before beginning work.
Page 74 Part: G853-01223-01 (USB-C cowling) Fig2, press down like the Fig3. Part: G949-00300-01 (Mid-frame_mmWave) Part: G949-00301-01 (Mid-frame_Sub-6) Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 75 Fasten Mid-frame Check P-sensor foam is flat. Place the Pixel 7 Pro Screw Cover on the Pixel 7 Pro Enclosure Holder. ● Tighten the 8 Screws with a Torx Plus 3IP screwdriver, take out the ● Pixel 7 Pro Screw Cover.
Page 76 Repair Flows Table of contents Disassembly instructions mmWave Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 77 Torx plus 3IP screwdriver ESD tweezers Universal Disassembly ESD Display module ● stick Graphite sheets ● Universal Fish line tool Mid-frame ● Caution! Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 78 G730-06099-11 G806-07335-01 mmwave_flex_CPSA_2 bracket mmWave G730-06099-12 sub-6 bracket G806-07336-01 mmwave_flex_CPSA_3 G250-05753-00 Screw G806-06182-01 FOAM Sub-6 G806-06083-01 mmWave thermal pad Caution! Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 79 This step is only for mmWave Sku. Using the Universal Fish line tool avoids damage the components. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 80 Remove Screws Remove bracket Place the Pixel 7 Pro Screw Cover on the Pixel 7 Pro Remove the bracket with an ESD Tweezers. ● ● Enclosure Holder. Remove the mmWave bracket screw with a Torx Plus 3IP ● Part: G730-06099-11 (bracket mmWave) screwdriver, then remove the Pixel 7 Pro Screw Cover.
Page 81 This step is only for Sub-6 Sku. This step is only for mmWave Sku. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 83 This step is only for mmWave Sku. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Caution! Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page Review all safety precautions before beginning work.
Page 84 Bend the mmWave flex into an L shape where the flex is scored. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 85 This step(tear off the blue liner) is only for mmWave Sku. This step is only for Sub-6 Sku. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 86 Fasten mmWave bracket Connect to Logic board Place Pixel 7 Pro Screw Cover on the Pixel 7 Pro Enclosure ● Connect mmWave flex and battery flex to the Logic board. ● Holder. Fasten the mmWave bracket screw with a Torx Plus (3IP), ●...
Page 87 Repair Flows Table of contents Disassembly instructions Rear camera Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 88 ESD tweezers Universal Disassembly ESD Display module ● stick Graphite sheets ● Universal Fish line tool Mid-frame ● Ionizing air fan mmWave ● Caution! Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 89 Screw * 2 RCAM liner tele G853-01244-01 Spring G806-07708-01 RCAM liner UW G852-02350-01 G806-07709-01 RCAM Cap RCAM liner G852-02270-01 RCAM UW Cap Caution! Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 90 Remove screws Remove front cam connector Place the Pixel 7 Pro Screw Cover on the Pixel 7 Pro Remove the Spring with ESD tweezers. ● ● Enclosure Holder. Remove the two Rear camera screws with a Torx Plus 3IP ●...
Page 91 Using the Universal Fish line tool avoids damage the components. Using the Universal Fish line tool avoids damage the components. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 92 Ensure that the environment is clean for this process. Make sure the camera socket is clear from dust and debris. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 93 Repair Flows Table of contents Assembly instructions Rear camera Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 94 Ensure that the environment is clean for this process. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Caution! Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page Review all safety precautions before beginning work.
Page 95 Fasten the 2 RCAM screws with a Torx Plus 3IP screwdriver, then ● ● remove the Pixel 7 Pro Screw Cover. as the Fig4 shows. Part: G949-00299-01 (Rear camera) Torque force ： 1.2 ± 0.03kgf-cm Part: G853-01244-01 (Spring), G250-05753-00 (Screw) This left flex area cannot be pressed, as the arrow in figure.
Page 96 Check every connector is attached fully to the Logic board. Check every connector is attached fully to the Logic board. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 97 Repair Flows Table of contents Disassembly instructions Top speaker Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 98 ● Universal Fish line tool Mic protective liner Mid-frame ● Ionizing air fan mmWave ● G806-06207-01 Rear camera ● Top spk Adhesive Caution! Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 99 Remove screws Remove Top Speaker Fig1 Fig2 Place the Pixel 7 Pro Screw Cover on the Pixel 7 Pro Since the Top Speaker is adhered by adhesive, follow the steps ● ● Enclosure Holder. below: Pry it in the direction shown in the Fig1 for 3 to 5 times.
Page 100 Paste the Mic protective liner on Mic3 hole of the ANT1. ● Mic protective liner Part: G806-03591-01 ( Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 101 Repair Flows Table of contents Assembly instructions Top speaker Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 102 Part: G806-06207-01 (Top speaker Adhesive) Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Caution! Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page Review all safety precautions before beginning work.
Page 103 Fasten top speaker Fig1 Fig2 Insert it into the Top speaker slot on the Enclosure at an Place the Pixel 7 Pro Screw Cover on the Pixel 7 Pro ● ● angle of about 10~15°, making sure to fit it completely. (Fig2) Enclosure Holder.
Page 104 Repair Flows Table of contents Disassembly instructions Front camera Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 105 ESD tweezers Front camera items first: Display module ● Graphite sheets ● Mid-frame ● mmWave ● Rear camera ● Top speaker ● Caution! Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 106 Part: G949-00298-01 (Front camera) Using the Universal Fish line tool avoids damage the components. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 107 Repair Flows Table of contents Assembly instructions Front camera Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 108 ● Part: G949-00298-01 (Front camera) Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Caution! Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page Review all safety precautions before beginning work.
Page 109 Repair Flows Table of contents Disassembly instructions Battery Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 110 Display module ● Universal press fixture Graphite sheets ● ESD tweezers Mid-frame ● Feeler gauge Universal adsorption bulb 3M AP111 Primer Table C-Clamp Caution! Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 111 The intent of the pull jacket is to pull on battery for release, not to cut through the adhesive. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 112 Heating plate is a Hot Surface. Use caution as it could cause burns. The table should be sturdy. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 113 The battery may be easier to remove, as soon as you lift up the battery after leave heat plate (before adhesive cools). Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 114 Keep small screws and sharp objects away from the Battery. Do not reuse the Battery. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 115 Repair Flows Table of contents Assembly instructions Battery Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 116 Once Primer has been applied, complete assembly in 25 mins. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Caution! Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page Review all safety precautions before beginning work.
Page 117 Align the Battery at the corners as the figure circles.(Fig1.) ● Place the Pixel 7 Pro Battery Press on the Pixel 7 Pro ● Gently press the Battery down with the Universal ●...
Page 118 Press together in fixture Press together in fixture Place the Pixel 7 Pro Enclosure Holder in the Universal Return the handle to the original position and remove the Pixel ● ● press fixture. 7 Pro Enclosure Holder. Press the handle down for 10 seconds.
Page 119 Repair Flows Table of contents Disassembly instructions Logic board Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 120 Rear camera ● Sankol lubricant CFD 409Z_V2 Top speaker ● Dust-free Cotton swabs Front camera ● Universal Coaxial Cable Tool Battery ● Caution! Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 121 G821-00812-01 Coaxial cable #4 (Black) G250-06333-00 Screw *4 G821-00811-53 Coaxial cable #1 (Black) G853-01233-02 ANT7 Grounding Multiple Part Numbers Sim Tray G806-03591-01 Mic protective liner Caution! Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 122 ● Part: G250-06333-00 (Screw) Part: G853-01233-02 (ANT7 Grounding) Do not reuse the part. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 123 ANT1 & ANT4 Board & Logic Board. Be careful to avoid scratching the Enclosure. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 124 Cable Tool. This head to unbuckle the head. This head to unbuckle the head. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 125 Disconnect the Cable Remove the screw Release the 3 coaxial cable (#4 #1 #8) from the tunnel of Place the Pixel 7 Pro Screw Cover on the Pixel 7 Pro ● ● Enclosure Holder. the Enclosure. Remove the 4 Logic board screws with a Torx Plus 3IP ●...
Page 126 Be careful to avoid damaging components on the logic board. Using the Universal Fish line tool avoids damage the components. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 127 This head to unbuckle the head. It is recommended to complete this step in EVA sponge. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 128 It is recommended to complete this step on an EVA sponge to avoid damage. an EVA sponge to avoid damage. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 129 Repair Flows Table of contents Assembly instructions Logic board Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 130 Before assembly the MLB, check each spring deformed or not. And pay EXTRA ATTENTION to the springs areas during assembly to avoid damaging them. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 131 EVA sponge to avoid damage. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Caution! Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page Review all safety precautions before beginning work.
Page 132 This step recommended to be done done on an EVA sponge. on an EVA sponge. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 133 Peel off the Mic1 mylar from the Logic board. ● Mic protective liner Part: G806-03591-01 ( Do not reuse the part Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 134 Do not reuse the part Also avoid damaging the spring of the Bottom Speaker. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 135 ● above. Part: (SIM tray) Multiple Part Numbers Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 136 Insert SIM tray Screw in logic board Hold SIM socket Slightly hold the Logic board and insert the SIM tray with your Place the Pixel 7 Pro Screw Cover on the Pixel 7 Pro ● ● right hand. Enclosure Holder.
Page 137 Assemble Coaxial cable #1 to the tunnel of ANT1 Board. ● Part: G821-00811-53 (Coaxial cable #1) This head to buckle the head. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 138 Part: G821-00814-50 (Coaxial cable #8) This head to buckle the head. This head to buckle the head. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 139 Part: G853-01233-02 (ANT7 Grounding) Check every connector is attached fully to the Logic board. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 140 Tighten the screw with a Torx Plus (3IP) screwdriver, as ● shown. Torque force ： 1.2 ± 0.03kgf-cm Part: G250-06333-00 (Screw) Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 141 ANT1 coaxial coaxial cable into Fall off NG cable the clip broken Cable Head Check ANT8 coaxial cable start Check each coaxial cable. Here are some examples for the references. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 142 Once fastening it into the buckle the head of Coaxial cable to ANT4, visually check the head the coaxial cable. If the head is broken or damaged(link), it’s necessary to change the new coaxial cable. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 143 Repair Flows Table of contents Disassembly instructions Bottom speaker Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 144 ● Graphite sheets ● Mid-frame ● mmWave ● Rear camera ● Top speaker ● Front camera ● Battery ● Logic board ● Caution! Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 145 Remove the Bottom speaker with an ESD tweezers. ● Part: G863-00402-03 (Bottom speaker) Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 146 Repair Flows Table of contents Assembly instructions Bottom speaker Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 147 Make sure the speaker goes under the enclosure rim. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Caution! Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page Review all safety precautions before beginning work.
Page 148 Repair Flows Table of contents Disassembly instructions Mic1 Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 149 ● Mid-frame ● mmWave ● Rear camera ● Top speaker ● Front camera ● Battery ● Logic board ● Bottom speaker ● Caution! Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 150 Remove the Mic1 bracket with an Universal Disassembly ● ESD stick. Part: G730-06101-13 (Mic1 bracket) Do not reuse the part Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 151 Repair Flows Table of contents Assembly instructions Mic1 Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 152 Bend the dust-free cotton bud to insert the hole and apply. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Caution! Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page Review all safety precautions before beginning work.
Page 153 Avoid touching the Mic1 membrane during assembly. Avoid touching the Mic1 membrane during assembly. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 154 Repair Flows Table of contents Disassembly instructions Enclosure Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 155 Top speaker ● ESD Universal Disassembly ESD Front camera ● stick Battery ● Logic board ● Bottom speaker ● Mic1 Bracket ● Caution! Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 156 G949-00303-01 G949-00361-00 ANT4 Sidekey G250-06333-00 Multiple Part Numbers Volume button Screw * 4 G806-06257-03 P-sensor grommet G949-00347-00 ANT1 Board G806-06332-01 ANT1 Adhesive Caution! Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 157 Remove the screw (ANT4) Remove the ANT4 Place the Pixel 7 Pro Screw Cover on the Pixel 7 Pro Remove the ANT4 Board with a ESD Tweezers. ● ● Enclosure Holder. Remove the screw with a Torx Plus 3IP screwdriver, then ●...
Page 158 Remove the Psensor grommet Remove the screw (ANT1) Remove the Psensor grommet from ANT4 board. Place the Pixel 7 Pro Screw Cover on the Pixel 7 Pro Enclosure ● ● Holder. Remove the screw with a Torx Plus 3IP screwdriver, Part: G806-06257-03 (Psensor grommet) then remove the Pixel 7 Pro Screw Cover.
Page 159 Part: G949-00347-00 (ANT1 Board) , G806-06364-01 (kapton) Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 160 Part: (Sidekey) G250-06333-00 (screw) This step applies only when there is Sidekey damage. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 161 Multiple Part Numbers This step applies only when is a Volume Button issue. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 162 Repair Flows Table of contents Assembly instructions Enclosure Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 163 The highlight is where the residual adhesive exists. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Caution! Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page Review all safety precautions before beginning work.
Page 164 This step only applies when there is” Sidekey damage”. During the process, don’t touch the spring. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 165 Algn the two alignment holes and press it. ● Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 166 Clean any residue in the Battery area with an Universal ● Disassembly ESD stick. Apply IPA with a cloth afterward. ● Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 167 Using a new groment(not to reuse old one) if replace new ANT4 board. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 168 Screw in ANT4 Paste Ant1 Adhesive Place the Pixel 7 Pro Screw Cover on the Pixel 7 Pro Paste the Ant1 Adhesive according to the red alignment line , ● ● and column to ANT1 board.The release liner cannot be Enclosure Holder.
Page 169 Use the ESD Tweezers to close the piano buckle (the black button is Enclosure. ● shown, do it gently, (Fig2) Place the Pixel 7 Pro Screw Cover on the Pixel 7 Pro Enclosure ● Use ESD Tweezers to paste the kapton to the connector. (Fig3), refer ●...
Page 170 ● the graphite sheet or other components, and the Flex tail align on enclosure edge. If you see flex NG in right position like, please contact your google ● representative. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 171 Multiple Part Numbers This step only applies when there is” Volume Button issue”. Graphic Rear Front Logic Bottom Mic1 Display Mid-frame mmWave Battery sheet Camera Speaker Camera board Speaker Bracket Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 173 Front camera connector Display connector Battery connector USB Port Sidekey pad WC & NFC Pad Bottom Speaker Pad Vibrator pad mmWave connector Caution! Review all safety precautions before beginning work. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 174 (Fig4) Component issue Logic board ● Use a good mic1 bracket and Logic board to ● mic1 bracket cross check with original ones. ● Replace the defective component. ● (Fig3) Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 175 T015: Mic 2 - distorted sound Disassembly Use a good Enclosure and Logic board to cross ● Component check with original ones. Logic board ● issue Replace the defective component. ● Enclosure ● Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 176 ● Disassembly Use a good Ant1 Board and Logic board to ● Component cross check with original ones. Logic board ● issue Replace the defective component. ● Enclosure(Ant1 Board) ● Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 177 If sound quality is still poor, use a good Top Disassembly ● Speaker and Logic board to cross check with Component Logic board original ones ● issue Top Speaker Replace the defective component. ● ● Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 178 If sound quality is still poor, use a good Bottom Disassembly ● Speaker and Logic board to cross check with Component Logic board original ones ● issue Bottom Speaker Replace the defective component. ● ● Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 179 T036: Display backlight issue If issue is resolved, apply adhesive and fit new Display Flickering ● ● T037: Display shadow Display module. Color issues T038: Display permanent burnin T039: Display temporary burnin Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 180 Use a good Display and Logic board to cross check ● T037: Display shadow with original ones. T038: Display permanent burnin Component issue Logic board ● T039: Display temporary burnin Replace the defective component. ● Display ● Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 181 T046: Multi-touch erratic Disassembly Use a good Display and Logic board to cross ● response check with original ones. Component issue Logic board ● Replace the defective component. ● Display ● Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 182 T026: Vibrator failure Disassembly Use a good Mid-frame and Logic board to ● cross check with original ones. Component issue Logic board ● Replace the defective component. Mid-frame ● ● Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 183 Disassembly ● Use a good Battery and Logic board to Component cross check with original ones. ● Logic board issue ● Replace the defective component. ● Battery Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 184 ● Use a good Battery and Logic board to T054: Battery draining fast Component cross check with original ones. ● Logic board issue ● Replace the defective component. ● Battery Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 185 T115:UW RCAM no preview T116:Ultrawide Rear Camera Photo quality T117:Ultrawide Rear Camera Disassembly ● If camera issue remains, replace Logic video quality No image board. ● Logic board Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 186 T079: Camera damage T110: FCAM crashes T113: FCAM no preview Disassembly ● If camera issue remains, replace Logic No image board. ● Logic board Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 187 T106: 5G_high_band_failure ● If issue is resolved, proceed with mmWave ● mmWave replacement and assemble device. Component issue Disassembly ● If camera issue remains, replace Logic board. ● Logic board Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 188 ● Disassemble and check the appearance of Disassembly Proximity sensor without abnormality. ● Logic board (P-sensor Component ● Use a good P-sensor grommet to Logic issue grommet) board to check. ● Replace the defective component. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 189 ● then retest. Disassembly Use a good Enclosure and Logic board to cross ● check with original ones. Component issue Logic board ● Replace the defective component. ● Enclosure ● Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 190 Disassembly ● Use a good Enclosure and Logic board to Component cross check with original ones. ● Logic board issue ● Replace the defective component. ● Enclosure Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 191 Disassembly ● Use a good Display and Logic board to Component cross check with original ones. ● Logic board issue ● Replace the defective component. ● Display Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 192 (2) While one side of the volume button can now be grasped with your finger for removal. Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 193 ● Quality Check : by pressing each side of Volume Up the volume button 20 times. Volume Down Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 195 Software resources Description Documentation Update or reinstall the software on Pixel devices Link Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 197 The radio waves used to build a 5G network, providing fast, reliable mobile data. Liquid Damage Indicator An indicator that turns from white into another color, typically red, after contact with water. Also known as: Liquid damage indicator Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 198 The housing that contains the buttons and provides protection for the logic board and other components. Enclosure Also known as: Housing (HSG) rear cover back cover (BC) back glass (BG) Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 199 The adhesive that are used to bond enclosure and display module, battery and enclosure, or other parts. Also known as: Pressure Sensitive Adhesive Handset Jack Audio Jack Also known as: Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...
Page 200 Terminology and definitions Acronym / Term Definition Factory Reset Protection Factory Data Reset Same Unit Repair Return To Vendor SBOM Service Bill of Materials Pixel 7 Pro Repair Manual v3 ©Google 2024 l Page...

This manual is also suitable for:

Pixel 7

Google Pixel 7 Pro Repair Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Google Pixel 7 Pro

Summary of Contents for Google Pixel 7 Pro

This manual is also suitable for:
