Page 2 Opening and/or repairing your device can present electric shock, device damage, fire and personal injury risks, and other hazards. Before servicing the product, read the full set of precautions in this document. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page...
Page 3 Use the diagnostic steps and same language to colleagues testing recommended in this and customers. section to identify the source of device problems and issues. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page...
Page 4 Tools and Fixtures Assembly instructions Replacement Parts Display Graphite sheets Repair Flows Mid-frame mmWave Upper mid-frame Rear camera Top speaker Front camera Battery Logic board Mic1 Bracket Bottom speaker Enclosure Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page...
Page 5: Troubleshooting
Connectors Location Mic2 mmWave Logic board Mic1 Top Speaker Enclosure Mic3 Display Bottom Speaker Power Vibrator Front Camera Rear Camera Proximity sensor mmWave Wireless Charge UDFPS Testing Software resources Glossary Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page...
Page 6: Revision History
Update battery alignment instruction @P114 @P115. Update the screw torque force @P20 @P73 @P81 @P100 @P128. Updated UDFPS calibration software download SOP link @P53. Moved the battery cosmetic inspection slide to the precaution section. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page...
Page 7 V1.5 Update Logic board swap No Need to swap RCAM together. @P23, @P92, @P123. 2022 April 2024 Removed proprietary references Added disclaimers Updated tools and fixtures names and part numbers Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page...
Page 9: Important: Before You Begin
Laser Module: Dispose of the battery in a manner in ● Made in Austria. ams AG, Tobelbader Str. 30, accordance with local regulations. 8141 Oberpremstätten, Austria Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page...
Page 11 Swelling or electrolyte leakage Dent Bubbling Imprinted line *These are examples of potentially dangerous battery conditions but don't reflect all possible dangerous conditions. Please follow general safety guidance outlined in this document. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page...
Page 13: Expanded View
Reusable with cleaning SCREW RF Thermal Bottom speaker Enclosure USB-C cowling Battery DISPLAY Not Reusable after disassembly Display SCREW Logic Mic1 RF Graphite sheet Mid-frame Display cowling Module board bracket Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 13...
Page 14 After any repair that requires you to If this process isn’t followed, the touch function of the screen may open the phone, complete the display touch calibration during not work as intended. first boot. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page...
Page 15: Esd Protection
It’s the ESD. Protective bags Avoid touching pins Pack all ESD-sensitive parts Don’t touch pins with use of in metalized protective bags during ESD-safe tools to handle shipping. components. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page...
Page 16 Since thread locking adhesive can’t replaced with a new screw. be reactivated, replace each used screw with a new screw after removal. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 16...
Page 17 There’re two LDI on this device. ● On the underside of the USB-C port, on the cowling. ● On the mid-frame (visible without disassemble the device). ● Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 17...
Page 19 Google-approved fixtures - Pixel 6 Pro Google-approved fixtures are Google tested and are strongly encouraged to ensure high quality and safe repairs. Pixel 6 Pro Assembly Pixel 6 Pro Assembly Pixel 6 Pro Assembly Pixel 6 Pro Assembly Pixel 6 Pro Assembly Pixel 6 Pro Disassembly Enclosure Holder &...
Page 20 Google-approved fixtures Google-approved fixtures are Google tested and are strongly encouraged to ensure high quality and safe repairs. Upper : SIM TRAY EJECTOR Lower : CONNECT DSSY Universal Disassembly Universal Disassembly Universal adsorption Universal Press Fixture Fixture - Universal Universal Scraper...
Page 21: Common Tools
Dust-free Cotton Plastic ESD Tweezers SIM card ejection pin swabs Screwdriver Torx Plus 3M UPUV or AP111 Adjustable type torque Heating plate Spudger (ESD stick) (Isopropyl Alcohol) Primer screwdriver [Optional] Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 21...
Page 22 Google-recommended supplier. Sankol lubricant Masking tape Ionizing air fan Ionizing air fan Table C-Clamp Suction Cup CFD 409Z_V2 Fishing Line Feeler gauge Deglue Machine (Thickness 0.4mm, 13.9kg/30lb) Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 22...
Page 23: Safety Items
Safety items are suggested to ensure high quality and safe repairs. These items don't need to be purchased from a Google recommended supplier. Safety Glasses Heat Resistant Cut Resistant Nitrile or Lint-Free Protective Gloves Protective Gloves Gloves Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 23...
Page 24 Google authorized replacement parts, Performance within product specifications such as aftermarket batteries, may impact ● device safety, reliability and performance. cannot be assured if Google authorized replacement parts are not used. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 24...
Page 25: Replacement Parts
Rear camera Mid-frame_mmWave Enclosure Multiple Part Numbers G949-00228-01 G949-00219-01 G949-00226-01 G949-00227-01 Multiple Part Numbers Mid-frame_Sub-6 mmWave flex Battery Display adhesive USB-C cowling Display cowling G949-00229-01 G949-00230-01 G730-06300-01 G806-05452-03 G853-01046-02 G730-05725-01 Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 25...
Page 26 G806-04783-13 G730-06000-51 G730-05950-01 G730-05758-03 Multiple Part Numbers Bottom speaker Top speaker RF thermal pad SOC thermal pad RF Graphite sheet mmWave thermal pad G806-04854-02 G863-00367-03 G863-00396-01 G806-04615-01 G806-04858-04 G864-00418-01 Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 26...
Page 27 SCREW, HEATSINK FOAM Sub-6 G864-00445-01 G864-00446-01 G250-05752-00 G250-05753-00 G806-05702-01 G250-06026-00 RCAM Cap RCAM UW Cap FCAM Cap RCAM Tele Cap FCAM Film Camera liner G806-06298-01 G806-06299-01 G852-02351-01 G852-02352-01 G852-02355-01 G852-02356-01 Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 27...
Page 28 Back cover Visor Frame Mic protective CG_copper PSA, TOP SPKR protective film protective film protective film protective liner G806-05716-02 G806-06032-01 G806-06300-01 G806-06309-01 G806-06310-01 G806-03591-01 MMWAVE_flex_ SPONGE_Mid CPSA Frame G806-05324-01 G806-06554-01 Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 28...
Page 30 Top speaker rework Reusable with rework Front camera Not Reusable Note: Rear camera/Front camera/Battery are in the after disassembly same layer, you can replace each of them without interference. Battery Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 30...
Page 31 Pixel 6 Pro Assembly order Enclosure Logic board Battery Display Bottom speaker Front camera mmWave Top speaker Mid-frame Assembled without Rear camera Graphite sheets fixture Assembled with fixture Upper mid-frame Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 31...
Page 32 Repair Flows Table of contents Disassembly instructions Display Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 32...
Page 33: Display Replacement
Universal disassembly fixture & Universal Device Clips repair, be sure Ionizing air fan to power off Pixel 6 Pro Enclosure and CG Press Cover & Sponge Align the device. Pixel 6 Pro Enclosure PSA Align & Press Cover Pixel 6 Pro Enclosure Holder & Graphite Align...
Page 34 Use safety gloves to handle damaged displays as some splinter during removal and could cause injury. Apply protective film to broken glass before removal. Review all safety precautions before beginning work. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 34...
Page 35 G806-06310-01 (Visor Frame protective film) Part: G949-00219-01 (Display module) G806-06300-01 (Display front protective film) Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 35...
Page 36 Caution: Heating plate is a Hot Surface. Use caution as it could cause burns. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 36...
Page 37 There is a groove which can help to avoid pressing the power button accidentally. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 37...
Page 38: Open The Lid
Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 38...
Page 39 Insert and keep pulling the gap horizontally. Universal Disassembly ESD pick at that angle. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 39...
Page 40: Remove Cowling
Do not reuse the part (Screw) the device to not function as intended. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 40...
Page 41 G852-02355-01 (Front Cam Cap) Using the Universal Fish line avoids damage the components. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 41...
Page 42 Only apply the copper protective film to reuse a good working, none cracked screen. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 42...
Page 43 Repair Flows Table of contents Assembly instructions Display Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 43...
Page 44 The highlight is where the residual adhesive may exists. IPA to clean the surface. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 44...
Page 45 Do not touch the adhesive. If it gets dirty, change for another one. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 45...
Page 46 04. Adhesive alignment 05. Place another cover Place the adhesive in the Pixel 6 Pro Assembly Enclosure Place the Pixel 6 Pro Enclosure PSA Align & Press Cover-2 on ● ● PSA Align & Press Cover-1 with the ESD tweezers.
Page 47 Place it vertically. Do Not press on RCAM Area(Visor) during the process. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 47...
Page 48 Remove the Pixel 6 Pro Enclosure PSA Align & Press Remove the Enclosure from the Pixel 6 Pro Enclosure PSA ● ● Cover-2 from the Pixel 6 Pro Enclosure PSA Align & Press Align & Press Cover-1 vertically. Cover-1. Take out the Enclosure vertically.
Page 49 Do not remove the 2nd layer of the liner yet. ● Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 49...
Page 50 ● the holder. Pinch point. Keeps hands clear during operation. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 50...
Page 51 (as shown above red figure). Once Primer has been applied, complete assembly in 25 mins. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 51...
Page 52 Part: G806-06298-01 (FCAM film) G806-06032-01 (CG_copper_protective) Part: G852-02183-01 (FCAM Cap) Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 52...
Page 53 Do not touch the display until it turns on fully since display self-calibration is in progress. Display Touch Calibration Details Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 53...
Page 54 Be careful not to puncture the battery when tightening the screw. been replaced Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 54...
Page 55 FCAM should tilt a bit as Fig 1. to ensure concentricity. Fig 2, almost flat, NG Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 55...
Page 56 25. Place in holder Align the Display module on the Enclosure vertically. ● Place the device back in the Pixel 6 Pro Enclosure holder ● and place the Press cover on top. Take the device out from the Holder and press around the ●...
Page 57 Push back the handle to the original position and remove the ● device. Pinch point. Keeps hands clear during operation. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 57...
Page 58 Repair Flows Table of contents Disassembly instructions Graphite sheets Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 58...
Page 59 ESD Tweezers Universal Disassembly ESD G864-00445-01 stick Rear camera Display module ● Universal scraper graphite sheet G864-00446-01 SOC graphite sheet Caution! Review all safety precautions before beginning work. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 59...
Page 60 Be careful not to puncture the battery while Do not reuse the part using the tweezers. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 60...
Page 61 Part: G864-00445-01 (Rear camera graphite sheet) Do not reuse the part Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 61...
Page 62 Repair Flows Table of contents Assembly instructions Graphite sheets Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 62...
Page 63 01. Apply graphite sheet 02. Apply graphite sheet With the device in the Pixel 6 Pro Enclosure holder, place Place the SOC graphite sheet and align it with the 2 ● ● the RF graphite sheet, aligning with the 4 positioning positioning columns on the left.
Page 64 Avoid rolling over the gaskets, as it may deform them. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 64...
Page 65 Remove the 3 blue release liners from each sheet. ● Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 65...
Page 66 Repair Flows Table of contents Disassembly instructions Mid-frame Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 66...
Page 67 ESD tweezers Display module ● Universal Disassembly ESD G949-00229-01 Graphite sheets ● stick Mid-frame_Sub-6 G806-04615-01 G806-04858-04 Thermal pads G250-05753-00 7 x Screws Caution! Review all safety precautions before beginning work. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 67...
Page 68: Screw Cover
01. Screw cover 02. Remove screws Remove 7 Mid-frame Screws with a Torx Plus 3IP ● Place the Pixel 6 Pro Screw cover on the Pixel 6 Pro ● screwdriver. Assembly Enclosure Holder & Graphite Align. The 3 Then remove the Pixel 6 Pro Screw cover.
Page 69 Part: G853-01046-02 (USB-C cowling) Part: G949-00228-01 (Mid-frame_mmWave) Part: G949-00229-01 (Mid-frame_Sub-6) Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 69...
Page 70 Part: G806-04615-01 (RF thermal pad) Part: G806-04858-04 (SOC thermal pad) Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 70...
Page 71 Repair Flows Table of contents Assembly instructions Mid-frame Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 71...
Page 72 Part: G806-04858-04 (SOC thermal pad) This step is for new and reclaim Mid-frame. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 72...
Page 73 Part: G853-01046-02 (USB-C cowling) Part: G949-00228-01 (Mid-frame_mmWave) Part: G949-00229-01 (Mid-frame_Sub-6) Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 73...
Page 74 05. Fasten Mid-frame Place the Pixel 6 Pro Screw cover on the Pixel 6 Pro Assembly ● Enclosure Holder & Graphite Align. Tighten the 7 Screws with a Torx Plus 3IP screwdriver, take out the ● Pixel 6 Pro Screw Cover.
Page 75 Repair Flows Table of contents Disassembly instructions mmWave Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 75...
Page 76 Universal Disassembly ESD G806-05324-01 Graphite sheets ● stick MMWAVE_flex_ CPSA Mid-frame ● G250-05753-00 1 x Screw G806-05702-01 FOAM Sub-6 G806-04854-02 mmWave thermal pad Caution! Review all safety precautions before beginning work. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 76...
Page 77: Disconnect Battery
Using the Universal Fish line avoids damage the components. Using the Universal Fish line avoids damage the components. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 77...
Page 78 03. Remove Screws 04. Remove bracket Place the Pixel 6 Pro Screw cover on the Pixel 6 Pro Remove the bracket with an Universal Disassembly ESD stick ● ● Enclosure holder. Remove the mmWave bracket screw with a Torx Plus 3IP ●...
Page 79 This step is only for Sub-6 Sku. This step is only for mmWave Sku. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 79...
Page 80 Repair Flows Table of contents Assembly instructions mmWave Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 80...
Page 81 Bend the mmWave flex into an L shape where the flex is scored. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 81...
Page 82 (not glossy side) Insert the bracket at an angle. ● Insert Foam Sub-6 into the Enclosure. ● Place Pixel 6 Pro Screw cover on the Pixel 6 Pro Enclosure ● Place the Foam Sub-6 matte side to yourself, not the ● Holder.
Page 83 This step is only for mmWave Sku. The mmWave flex is only for mmWave Sku. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 83...
Page 84 Repair Flows Table of contents Disassembly instructions Upper mid-frame Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 84...
Page 85 Torx plus 3IP screwdriver 1 x Screw ESD tweezers Display module ● Graphite sheets G806-06554-01 ● Mid-frame Sponge_Mid Frame ● mmWave ● Caution! Review all safety precautions before beginning work. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 85...
Page 86 01. Remove screws 02. Remove upper mid-frame Place the Pixel 6 Pro Screw cover on the Pixel 6 Pro Remove the Upper mid-frame with ESD tweezers from the ● ● Enclosure holder. right side, as shown. Remove the 2 screws of the Upper mid-frame with a Torx ●...
Page 87 Repair Flows Table of contents Assembly instructions Upper mid-frame Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 87...
Page 88 Only conduct this step when the device is disassembled. the retaining wall. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 88...
Page 89 03. Fasten Upper mid-frame Place Pixel 6 Pro Screw cover on the Pixel 6 Pro Enclosure ● Holder. Fasten the 2 screws with a Torx Plus (3IP), take out the Pixel 6 ● Pro Screw Cover. Torque force ： 1.6 ± 0.03kgf-cm...
Page 90 Repair Flows Table of contents Disassembly instructions Rear camera Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 90...
Page 91 ● Camera liner Mid-frame ● mmWave ● G852-02351-01 Upper mid-frame ● RCAM Cap G852-02352-01 RCAM UW Cap G852-02356-01 RCAM Tele Cap Caution! Review all safety precautions before beginning work. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 91...
Page 92 01. Remove screws 02. Disconnect camera Place the Pixel 6 Pro Screw cover on the Pixel 6 Pro Loosen 3 Rear camera connectors and disconnect from the ● ● Enclosure holder. Logic board with a Universal Fish line tool. Remove the Rear camera screw with a Torx Plus 3IP ●...
Page 93 If reuse the RCAM, it can only be used for the original device only Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 93...
Page 94 Repair Flows Table of contents Assembly instructions Rear camera Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 94...
Page 95 Ensure that the environment is clean for this process. Ensure that the environment is clean for this process. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 95...
Page 96 03. Attach rear camera 04. Fasten rear camera Place the Rear camera into position, keeping it aligned with Place the Pixel 6 Pro Screw cover on the Pixel 6 Pro ● ● Enclosure holder. the lenses in the enclosure. Tighten Rear camera screw with a Torx Plus 3IP screwdriver, ●...
Page 97 Repair Flows Table of contents Disassembly instructions Top speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 97...
Page 98 ESD stick Display module ● G806-05716-02 Graphite sheets ● Mid-frame Top Spk PSA ● mmWave ● Upper mid-frame ● Rear camera ● Caution! Review all safety precautions before beginning work. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 98...
Page 99 01.Remove screws 02. Remove speaker Rib Broken Place the Pixel 6 Pro Screw cover on the Pixel 6 Pro Remove the Top speaker with an ESD stick. ● ● Enclosure holder. Remove the 2 Top speaker screws with a Torx Plus 3IP ●...
Page 100 Repair Flows Table of contents Assembly instructions Top speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 100...
Page 101 Press it by Universal ESD Stick slightly. ● Part: G806-05716-02 (Top Spk PSA) Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 101...
Page 102 03. Insert top speaker 04. Fasten top speaker Insert it into the Top speaker slot on the Enclosure at an angle Place the Pixel 6 Pro Screw cover on the Pixel 6 Pro ● ● Enclosure holder. of about 10°, making sure to fit it completely.
Page 103 Repair Flows Table of contents Disassembly instructions Front camera Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 103...
Page 104 Display module ● Graphite sheets ● Mid-frame ● mmWave ● Upper mid-frame ● Rear camera ● Top speaker ● Caution! Review all safety precautions before beginning work. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 104...
Page 105 Part: G949-00226-01 (Front camera) Using the Universal Fish line avoids damage the components. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 105...
Page 106 Repair Flows Table of contents Assembly instructions Front camera Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 106...
Page 107 Attach the Front camera with the connector to the Logic ● board. Part: G949-00226-01 (Front camera) Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 107...
Page 108 Repair Flows Table of contents Disassembly instructions Battery Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 108...
Page 109: Battery Replacement
Graphite sheets ● Universal press fixture Mid-frame ● ESD tweezers mmWave ● Feeler gauge Universal adsorption bulb 3M AP111 Primer Table C-Clamp Caution! Review all safety precautions before beginning work. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 109...
Page 110 Caution: Heating plate is a Hot Surface. Use caution as it could cause burns. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 110...
Page 111 Lock the device in position with the screws. ● Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 111...
Page 112 (before adhesive curing). Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 112...
Page 113: Remove Battery
Keep small screws and sharp objects away from the Battery. Do not reuse the part Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 113...
Page 114 Caution: Heating plate is a Hot Surface. Use caution as it could cause burns. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 114...
Page 115 (before adhesive curing). Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 115...
Page 116 Keep small screws and sharp objects away from the Battery. Do not reuse the part Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 116...
Page 117 Repair Flows Table of contents Assembly instructions Battery Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 117...
Page 118 Once Primer has been applied, complete assembly in 25 mins. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 118...
Page 119 Align the Battery at the corners as the figure circles.(Fig1.) ● Place the Pixel 6 Pro Assembly Battery Press on the Pixel 6 ● Gently press the Battery down with the Universal adsorption ● Pro Enclosure holder.
Page 120 Press the handle down for 10 seconds. ● Pinch point. Keeps hands clear during operation. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 120...
Page 121 Repair Flows Table of contents Disassembly instructions Logic board Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 121...
Page 122: Logic Board Replacement
G806-03591-01 Upper mid-frame ● Mic protective liner Rear camera ● Top speaker ● G806-04783-13 Front camera ● P-sensor grommet Battery ● Caution! Review all safety precautions before beginning work. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 122...
Page 123 01. Remove SIM tray 02. Remove screws Remove the SIM tray with a Universal Fish line tool. Place the Pixel 6 Pro Screw cover on the Pixel 6 Pro ● ● Enclosure holder. Remove the 5 Logic board screws with a Torx Plus 3IP ●...
Page 124 Part: G949-00190-01 (Logic board) Using the Universal Fish line avoids damage the components. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 124...
Page 125: Protective Film
Mic protective liner Part: G806-03591-01 ( Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 125...
Page 126 Part: G806-04783-13 (P-sensor grommet) This step is ONLY for the broken/damaged P-sensor grommet. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 126...
Page 127 Repair Flows Table of contents Assembly instructions Logic board Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 127...
Page 128 Logic Board check Before assembly the MLB, check each spring deformed or not. And pay EXTRA ATTENTION to the springs areas during assembly to avoid damaging them. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 128...
Page 129 IPA to gently clean the surface. Part: G949-00190-01 (Logic board) Do not reuse the part Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 129...
Page 130 This step is only for new logic boards or rework the P-sensor grommet. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 130...
Page 131 The Logic board should sit under the retaining wall, as shown ● wall. above. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 131...
Page 132 SIM tray with a dust-free cotton swab. hand. Part: G852-02165-11 (SIM tray) Part: G852-02165-11 (SIM tray) Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 132...
Page 133 09. Screw in logic board 10. Attach connectors UWB flex / FLAM flex Place the Pixel 6 Pro Screw cover on the Pixel 6 Pro Attach the 2 connectors from the Enclosure to the Logic ● ● Enclosure holder. board.
Page 134 Repair Flows Table of contents Disassembly instructions Mic1 Bracket Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 134...
Page 135 ● Mid-frame ● mmWave ● Upper mid-frame ● Battery ● Front and rear camera ● Top speaker ● Logic board ● Caution! Review all safety precautions before beginning work. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 135...
Page 136 ● Part: G730-06000-51 (Mic1 bracket) Do not reuse the part Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 136...
Page 137 Repair Flows Table of contents Assembly instructions Mic1 Bracket Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 137...
Page 138 Bent the dust-free cotton bud to insert the hole and apply. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 138...
Page 139 Press for 3 seconds with an ESD stick. ● Avoid touching the Mic1 membrane during assembly. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 139...
Page 140 Repair Flows Table of contents Disassembly instructions Bottom speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 140...
Page 141 ● Mid-frame ● mmWave ● Upper mid-frame ● Battery ● Front and rear camera ● Top speaker ● Logic board ● Caution! Review all safety precautions before beginning work. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 141...
Page 142 Remove the Bottom speaker with an ESD stick. ● Part: G863-00367-03 (Bottom speaker) Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 142...
Page 143 Repair Flows Table of contents Assembly instructions Bottom speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 143...
Page 144 Part: G863-00367-03 (Bottom speaker) Make sure the speaker goes under the enclosure rim. Graphic Upper Rear Front Logic Mic1 Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board Bracket speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 144...
Page 145 Repair Flows Table of contents Disassembly instructions Enclosure Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 145...
Page 146: Enclosure Replacement
Upper mid-frame ● Battery ● Front and rear camera ● Top speaker ● Logic board ● Mic and bottom speaker ● Caution! Review all safety precautions before beginning work. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 146...
Page 147 Repair Flows Table of contents Assembly instructions Enclosure Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 147...
Page 148 IPA to clean the surface. The highlight is where the residual adhesive exists. Graphic Upper Rear Front Logic Bottom Display Mid-frame mmWave Battery sheet mid-frame camera Speaker camera board speaker Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 148...
Page 149 PSA. Press it by Universal ESD Stick slightly. ● Apply IPA with a cloth afterward. ● Part: G806-05716-02 (Top Spk PSA) Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 149...
Page 150 03. Clean top area Clean any residue in the Top speaker area with an ESD ● stick. Apply IPA with a cloth afterward. ● Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 150...
Page 151 (Fig I) If you see flex lift up like Fig II, please adhere the flex back as Fig I. ● Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 151...
Page 153: Connectors Location
Tele camera connector UWB connector Flam connector UW camera connector Rear camera connector Display connector Battery connector Vibrator Pad Button connector Flash LED connector Bottom SPK Pad WLC&NFC Pad mmWave connector Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 153...
Page 154 Component issue Logic board ● Use a good mic1 bracket and Logic board to ● mic1 bracket cross check with original ones. ● (Fig4) Replace the defective component. ● Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 154...
Page 155 T015: Mic 2 - distorted sound Disassembly Use a good Enclosure and Logic board to cross ● Component check with original ones. Logic board ● issue Replace the defective component. ● Enclosure ● Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 155...
Page 156 Disassembly Use a good Top Speaker and Logic board to ● Component cross check with original ones. Logic board ● issue Replace the defective component. ● Top Speaker ● Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 156...
Page 157: Top Speaker
Top Disassembly ● Speaker and Logic board to cross check with Component Logic board original ones ● issue Top Speaker Replace the defective component. ● ● Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 157...
Page 158: Bottom Speaker
Bottom Disassembly ● Speaker and Logic board to cross check with Component Logic board original ones ● issue Bottom Speaker Replace the defective component. ● ● Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 158...
Page 159 T036: Display backlight issue Component issue Logic board ● T037: Display shadow Replace the defective component. ● Display T038: Display permanent burnin ● T039: Display temporary burnin Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 159...
Page 160 T046: Multi-touch erratic Disassembly Use a good Display and Logic board to cross ● response check with original ones. Component issue Logic board ● Replace the defective component. ● Display ● Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 160...
Page 161 T026: Vibrator failure Disassembly Use a good Mid-frame and Logic board to ● cross check with original ones. Component issue Logic board ● Replace the defective component. Mid-frame ● ● Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 161...
Page 162 Disassembly ● Use a good Battery and Logic board to Component cross check with original ones. ● Logic board issue ● Replace the defective component. ● Battery Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 162...
Page 163 ● Use a good Battery and Logic board to T054: Battery draining fast Component cross check with original ones. ● Logic board issue ● Replace the defective component. ● Battery Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 163...
Page 164: Rear Camera
● If issue is resolved, proceed with Rear T078: Cannot switch camera replacement and assemble device. between cameras T079: Camera damage Disassembly ● If camera issue remains, replace Logic No image board. ● Logic board Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 164...
Page 165: Front Camera
T078: Cannot switch ● Front Camera camera replacement and assemble device. between cameras T079: Camera damage Disassembly ● If camera issue remains, replace Logic No image board. ● Logic board Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 165...
Page 166 T106: 5G_high_band_failure ● If issue is resolved, proceed with mmWave ● mmWave replacement and assemble device. Component issue Disassembly ● If camera issue remains, replace Logic board. ● Logic board Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 166...
Page 167: Proximity Sensor
● Disassemble and check the appearance of Disassembly Proximity sensor without abnormality. ● Logic board (P-sensor Component ● Use a good P-sensor grommet to Logic issue grommet) board to check. ● Replace the defective component. Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 167...
Page 168 J13002(Connectors Location (N) pad has fallen off. Component issue Disassembly Use a good Enclosure and Logic board to cross ● check with original ones. Logic board ● Replace the defective component. ● Enclosure ● Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 168...
Page 169 Disassembly ● Use a good Enclosure and Logic board to Component cross check with original ones. ● Logic board issue ● Replace the defective component. ● Enclosure Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 169...
Page 170 Disassembly ● Use a good Display and Logic board to Component cross check with original ones. ● Logic board issue ● Replace the defective component. ● Display Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 170...
Page 172: Software Resources
Software resources Description Documentation Update or reinstall the software on Pixel devices Link Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page 172...
Page 174: Terminology And Definitions
The radio waves used to build a 5G network, providing fast, reliable mobile data. Liquid Damage Indicator An indicator that turns from white into another color, typically red, after contact with water. Also known as: Liquid damage indicator Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page...
Page 175 The housing that contains the buttons and provides protection for the logic board and other components. Enclosure Also known as: Housing (HSG) rear cover back cover (BC) back glass (BG) Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page...
Page 176 The adhesive that are used to bond enclosure and display module, battery and enclosure, or other parts. Also known as: Pressure Sensitive Adhesive Handset Jack Audio Jack Also known as: Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page...
Page 177 Terminology and definitions Acronym / Term Definition Factory Reset Protection Factory Data Reset Same Unit Repair Return To Vendor SBOM Service Bill of Materials Pixel 6 Pro Repair Manual v2 ©Google 2024 l Page...

Google Pixel 6 Pro Repair Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Google Pixel 6 Pro

Summary of Contents for Google Pixel 6 Pro
