Summary of Contents for DDC BU-65570i2-300

Page 1 DDC BU-65570i2-300 MIL-STD-1553 Two Dual-Channel Tester / Simulator Card Limited Availability Used and in Excellent Condition Open Web Page https://www.artisantg.com/87794-2 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
Page 2 105 Wilbur Place, Bohemia, New York 11716-2482 For Technical Support - 1-800-DDC-5757 ext. 7382 or 7234 Headquarters, N.Y., U.S.A. - Tel: (631) 567-5600, Fax: (631) 567-7358 West Coast, U.S.A. - Tel: (714) 895-9777, Fax: (714) 895-4988 Southeast, U.S.A.
Page 3 RECORD OF CHANGE Revision Date Pages Description Jan., 2000 Original Issue Oct., 2000 62-142 Function Definitions corrected Aug, 2002 Software section removed, Fig 13 modified Feb, 2003 New Figure 1, and Table 1 Data Device Corporation BU-65570/2i Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 4 TABLE OF CONTENTS TABLE OF CONTENTS....................III LIST OF FIGURES......................V LIST OF TABLES ......................VI HOW TO USE THIS MANUAL..................VII TEXT USAGE............................VII SYMBOLS AND ICONS ......................... VII SPECIAL HANDLING AND CAUTIONS ....................VIII TRADEMARKS ............................. VIII INTRODUCTION ......................1 WHAT IS INCLUDED IN THIS MANUAL? ....................
Page 5 INTERRUPTS ............................25 BC Interrupt Generation............................ 26 RT Interrupt Generation ............................ 26 Monitor Interrupts ............................. 26 OTHER FEATURES..........................27 Variable Amplitude Transceiver ........................27 IRIG-B support ..............................27 IRIG-B Specifications............................28 Monitor DMA to Host Buffer ........................... 29 Software Control Of Bus Configuration ......................29 Discrete Outputs..............................
Page 6 LIST OF FIGURES Figure 1. 25-Pin “J1” Discrete I/O Connector (As viewed from BU-65570/72i Card Edge)6 Figure 2. Found New Hardware ..................9 Figure 3. Search for Driver ..................10 Figure 4. Specify Driver Location................. 10 Figure 5. Found Driver....................11 Figure 6.
Page 7 LIST OF TABLES Table 1. Supplied I/O Connector Components ..............6 Table 2. J2: 1553 Bus 'D' Connector ................7 Table 3. J1: Discrete I/O....................8 Data Device Corporation BU-65570/2i Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 8 TEXT USAGE • BOLD– text that is written in bold letters indicates important information and table, figure, and chapter references. • BOLD ITALIC– will designate DDC Part Numbers. • Courier New– is used to indicate code examples. • <…> - Indicates user entered text or commands.
Page 9 H O W T O U S E T H I S M A N U A L The Reference icon indicates that there is related material in this manual or in another specified document. The Disk Icon describes information that is related to software. SPECIAL HANDLING AND CAUTIONS The BU-65572iX-300 uses state-of-the-art components, and proper care should be used to ensure that the device will not be damaged by Electrical Static Discharge (ESD),...
Page 10 There is additional capability to synchronize the onboard time tags of all of the operating cards with one command. Included with each BU-65572iX PCI Card is the DDC Menu and the Runtime Library with example source. The library supports ‘C’ and LabVIEW programming.
Page 11 TECHNICAL SUPPORT In the event that problems arise beyond the scope of this manual, you can visit the DDC web site and review the FAQ page. If you still have questions you can get in touch with DDC by calling: U.S.A.
Page 12 DDC makes no other warranty of any kind, either expressed or implied, and no warranty that the program product is free of errors. DDC and its authorized dealers shall not be liable for the cost of any repair of correction required for defective DDC program product material except as stated in this paragraph.
Page 13 These updates will be made available on our web site from time to time. Prior to calling DDC for updated material, please visit our web site for the latest versions.
Page 14 HARDWARE INSTALLATION The BU-65572iX card is a PCI Target device and may be inserted into any PCI 2.1, or higher, compatible slot. When installing the card, the following should be observed: NEVER insert or remove the card with the power turned on. ALWAYS take proper precautions to guard against static damage.
Page 15 H A R D W A R E I N S T A L L A T I O N DISCRETE I/O CONNECTOR “J1” PINOUTS This connector (Soldered on the board) is a 25-pin “Subminiature D Connector” (Amp P/N 747846-4). Pin numbering designations for “J1” are shown below. Figure 1.
Page 16 H A R D W A R E I N S T A L L A T I O N CARD PINOUT This section describes pinouts for the card. The card has two connectors, a DB-9 that is used for 1553 Bus I/O and a DB-25 that is used for discrete, power and IRIG.
Page 17 H A R D W A R E I N S T A L L A T I O N Description Chassis Ground Chassis Ground Chassis Ground IRIG Mod Channel 1 Discrete Out 1 Channel 1 Discrete Out 2 Channel 1 Discrete Out 3 Channel 1 Discrete Out 4 Channel 2 Discrete Out 1 Channel 2 Discrete Out 2...
Page 18 DRIVER INSTALLATION WINDOWS 95/98 For a Windows 95/98 installation continue with the following installation instructions. If using another operating system, skip to the relevant installation section. 1) Install the card as described in the beginning of the HARDWARE INSTALLATION section. 2) Turn on the computer.
Page 19 D R I V E R I N S T A L L A T I O N Figure 3. Search for Driver 5) Highlight Search for the best driver for your device (Recommended) radio button. 6) Click on the Next button. Figure 4.
Page 20 D R I V E R I N S T A L L A T I O N 7) Insert the BUS-69068 Installation Disk. Select the Floppy disk drives option. NOTE: If you are installing the software from a CD, highlight CD-ROM drive check box and uncheck the Floppy disk drives check box.
Page 21 D R I V E R I N S T A L L A T I O N Figure 6. Finished Install of Driver Click on the Finish button to confirm the installation. Figure 7. Confirm Driver Installation Click on the Finish button to close the Add New Hardware Wizard.
Page 22 D R I V E R I N S T A L L A T I O N packages include the DDC 1553 Card Manager, which is used to configure the card and assign a device ID. Data Device Corporation BU-65570/2i Manual Artisan Technology Group - Quality Instrumentation ...
Page 23 8) Follow any instructions that may appear on the screen. The computer will need rebooted device driver run. 9) Once rebooted, proceed with the DDC 1553 Card Manager instructions. Data Device Corporation BU-65570/2i Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 24 D R I V E R I N S T A L L A T I O N WINDOWS 2000 For a Windows 2000 installation continue with the following installation instructions. If using another operating system, skip to the relevant installation section.
Page 25 D R I V E R I N S T A L L A T I O N Figure 9. Search for Driver 5) Click on Search for a suitable driver for my device. 6) Click on the Next button. Figure 10.
Page 26 D R I V E R I N S T A L L A T I O N 9) Click on the Next button to locate the BU-65572iX-300 device driver. Figure 11. Found Driver 10) Click on the Next button to install the device driver. Figure 12.
Page 27 12) Continue configuring the device by installing the BUS-69068S0 RTL software or the BUS-69065S0 TestSim Menu. Both software packages include the DDC 1553 Card Manager, which is used to configure the card and assign a device ID. Data Device Corporation BU-65570/2i Manual Artisan Technology Group - Quality Instrumentation ...
Page 28 Windows Registry. The card information stored in the Registry is accessed and controlled through the use of the DDC 1553 Card Manager. The DDC 1553 Card Manager can be used to view the status of installed cards, and map an installed card to a device number.
Page 29 HARDWARE OPERATION GENERAL The BU-65572iX is the next generation DDC PCI Tester/Simulator which can simultaneously simulate a MIL-STD-1553 BC, all RTs, and an intelligent MT simultaneously on two 1553 buses. Full error detection features are provided in all modes of operation. In addition, user specified errors including bit count and Manchester II errors may be injected in BC and any of the emulated RT modes.
Page 30 H A R D W A R E O P E R A T I O N frame symbols identify special operations that should be performed at that point. For example the symbol ‘END_OF_MINOR’ specifies that the BC must stop message processing until the minor frame time counter expires.
Page 31 H A R D W A R E O P E R A T I O N asynchronous messages after the END_OF_MAJOR frame symbol and insert the message into the running frame by calling the insert message routine. The hardware does all of the work. Once the frame has been defined and the BC is running, asynchronous messages inserted...
Page 32 H A R D W A R E O P E R A T I O N RT MODE The BU-65572iX can simultaneously simulate the operation of 31 unique remote terminals (RTs) plus a broadcast address for each of the installed channels.
Page 33 H A R D W A R E O P E R A T I O N The BU-65572iX supports three types of response errors: no response, a late response, or a response on the wrong bus. No response errors may be programmed for a single bus (Bus A or Bus B) or for both buses.
Page 34 H A R D W A R E O P E R A T I O N message until the value of ‘last’ is reached, at which point the current table number will rollover to the value of first. The incrementing of the current data table is accomplished through the use of an intermessage routine.
Page 35 H A R D W A R E O P E R A T I O N As interrupts are generated, the BU-65572iX device driver will acknowledge the interrupt by clearing the computer hardware and then enter an interrupt vector onto a queue that can contain up to 64 interrupt actions.
Page 36 H A R D W A R E O P E R A T I O N (approximately 2K words). This allows for either real-time analysis or mass collection/storage of monitored data. OTHER FEATURES Variable Amplitude Transceiver The BU-65572iX provides variable amplitude transceivers for each 1553 channel installed on the card.
Page 37 • 1st word is time-of-year in BCD notation including days, hours, minutes, seconds, and fractions of seconds • DDC Usage - Mode B, Not using Straight Binary Seconds • Range = 1 Second to 1 Year • The initial time 0h 0m 0s January 1 of the present year •...
Page 38 H A R D W A R E O P E R A T I O N Monitor DMA to Host Buffer The BU-65572iX is fully compliant to the PCI standards for both Target and Master applications. As a PCI master, the BU-65572iX is capable of performing DMA block data transfers from the monitor buffers on the card to a user buffer in the host memory.
Page 39 H A R D W A R E O P E R A T I O N Discrete Outputs This new Tester/Simulator design will include four discrete outputs per channel. These four outputs are set to logic ‘1’ and cleared to logic ‘0’ by use of eight new intermessage routines.
Page 40 APPENDIX A Figure 14. Bus Configuration Figure 14 shows a common bus configuration using the BU-65572i2 card. The top half of the picture shows how to hook up the BU-65572i2 card to a Transformer coupled bus using bus couplers. The Bottom half of the picture shows how to hook up the BU-65572i2 card to a Direct Coupled bus.
Page 41 ..........5 Bus Controller (BC) Mode ......19 Monitor (MT) Mode........24 caution icon..........vii Courier New..........vii note icon ............. vii DDC 1553 Card Manager ......18 disk icon.............viii PCI Interrupt #INTA ............ 24 pinouts ............6 electrical static discharge ......viii Plug-and-Play Configuration......
