InnovaPrep FluidPrep EasyElute Quick Start Manual

EasyElute™ Kit
Figure 1
Figure 2
Vacuum
Tube
Figure 3
Vacuum Tube
User provided
Flow
Pump
Waste
Be sure to keep the sample tube fully immersed in
liquid while filtering. If air gets sucked into the
filter after it's already wetted, it will significantly
reduce or block the flow.
®
Port Cap
Sample Tube
Sample Tube
Sample
®
©InnovaPrep LLC 2009-2024. All rights reserved. Printed in USA
Vacuum Method for Large Volume
1. KIT COMPONENT CHECK (figure 1)
Verify that you have all EasyElute
EasyElute™ Filter
1.
EasyElute™ Elution Buffer canister
2.
Vacuum Tube (12")
3.
Sample Tube with fitting (36")
4.
Two Port Caps
5.
Canister Adapter
6.
A ring stand with clamp is recommended to secure filter
during sampling.
2. SAMPLING SETUP (figure 2)
Remove all of the port covers from the filter.
Firmly push the Vacuum Tube onto one of the side
ports. Firmly twist the fitting of the Sample Tube onto
the end port opposite the vacuum tube.
Place the Port Caps on the open side port and the open
end port.
3. CONNECT TO VACUUM SOURCE (figure 3)
Secure EasyElute™ Filter in a ringstand
with a clamp ensuring that the capped end is up.
Attach vacuum supply tubing from your pump to the
Vacuum Tube on the top side port.
4. COLLECT SAMPLE (figure 3)
Put the Sample Tube into your sample.
Keep tubing submerged *Do not let air enter the Sample
Tube until the sampling is complete.
Turn the pump on a slow setting and allow the sample to
fill the tubing completely.
Once the sample is flowing evenly through the system,
the pump can be adjusted to a higher flow rate.
When you have completed collecting your sample, allow
the pump to continue to run until all of the fluid has
been pulled through the filter and you can see air in the
Vacuum Tube, then stop the pump.
EasyElute™ Quick Guide
Concentratione
parts shown in (figure 1)
TM
.
Rev C
