Dorel MAXI COSI Peri 180 Manual

Setup and Use
Release carrier from base: The car seat must be side-facing to attach or
remove the car seat from the base. Squeeze rotation handle located at foot end
of base to rotate to side facing position. Carry handle must be locked in upright,
carry position before removing seat from base.
Harness: adjust fit to child: Harness must be at or slightly below shoulders. Adjust non
rethread harness by squeezing adjustment handle at top of headrest and moving to
appropriate locked position.
Harness adjustment for smaller infants: If you cannot
achieve a snug fit with harness, put harness on second loop
located in seating area under padding. Loosen harness fully,
undo fasteners on seat pad located under head pad and pull
towards you. Locate foam under seat pad, undo fastening
strips and remove foam from car seat shell. Unloop harness straps from clip,
attach to second harness strap loops, place clip in center bar on shell. Push firmly
on center clip until it clicks into place on bar. Replace foam and seat pad. These
adjustments should only be used until child is big enough to fit without them.
Buckle: There are two buckle strap positions. Use slot closest to but not
underneath child.
:
Additional padding
have no weight limit in manual. To perform pinch test on harness, undo velcro on
harness pads and move shoulder pads to be able to reach harness. Once pinch
test is complete, reattach velcro on harness pads. Do not remove harness pad
covers completely.
SEE PAGE 2
Important: This information sheet is not a substitute for complete manufacturer's directions and current recall list. #450
SafetyBeltSafe U.S.A., www.carseat.org (800) 745-SAFE ©SafetyBeltSafe U.S.A. 9/24
MAXI COSI (Dorel)
Type: Rear-Facing only
Last date made: Current
First made: 2024
Weight Limits: 4-30 pounds
Height requirements: 32 inches or less AND top of child's head at
least one inch below top of car seat's headrest
Expiration: Restraint expires 8 years from date of manufacture.
Head pillow, buckle cover, body pillow and harness covers
PERI 180
P. 1 of 3
