JUBILEE
CODES
422A . 423A . 424A
(Push)
(Push) (Auto Drive)
OWNER'S HANDBOOK
(English Version)
FROM SERIAL NO: 422A001001, 423A001001, 424A001001
HANDBOOK: 422072 (Rev.1.)
Issue : 10/10/01

Advertisement

loading
Need help?

Need help?

Do you have a question about the JUBILEE and is the answer not in the manual?

Questions and answers

Summary of Contents for Hayter JUBILEE

  • Page 1 JUBILEE CODES 422A . 423A . 424A (Push) (Push) (Auto Drive) OWNER’S HANDBOOK (English Version) FROM SERIAL NO: 422A001001, 423A001001, 424A001001 HANDBOOK: 422072 (Rev.1.) Issue : 10/10/01...
  • Page 2 MAIN FEATURES / SPECIFICATIONS Main Features Primer Bulb. Fuel Filler Cap. Oil Filler Cap and Dipstick. Handlebar Securing Knob. Rope Guide. Engine Start-Grip. Engine Stop lever. Handlebar. Ground Drive Clutch Lever (Auto drive only). Rear Deflector. Grassbag Assembly. Serial Number Decal. Height of Cut Adjuster.
  • Page 3 CONTENTS 1.2 Main Features/Specifications 1.18 Maintenance Schedule 1.3 Contents 1.19 - 1.25 Mower Maintenance 1.19 - Engine 1.4 Introduction 1.19 - Carburettor Adjustments 1.20 - Oil Service 1.5 Warranty 1.20 - Air Cleaner Service 1.21 - Spark Plug Service 1.6 - 1.9 Safety Precautions 1.21 - Keeping Engine Clean 1.21...
  • Page 4 INTRODUCTION Thank you for purchasing a Hayter mower. The following pages are designed to help you gain safe and efficient service from your mower. IMPORTANT: This ‘Owners Handbook’ should be regarded as part of the mower as it gives essential information regarding mower safety, operation, maintenance and specifications. Read and understand this handbook prior to operating your mower for the first time.
  • Page 5 This warranty does not apply to any unit that has been tampered with, altered, misused, abused or used for hire, and will become invalid if non genuine Hayter parts are fitted. This warranty does not cover minor mechanical adjustments unless they are due to defective material or workmanship.
  • Page 6 SAFETY PRECAUTIONS Safety Alert Symbol This safety alert symbol indicates important safety messages. When you see this symbol be alert to the possibility of injury. Carefully read the following and inform others. Your mower is perfectly safe if used correctly. Failure to observe the following precautions may result in serious injury.
  • Page 7 A damaged cutterblade must be replaced immedi- ately with a genuine Hayter replacement part. Operation Do not operate the engine in a confined space where exhaust fumes (carbon monoxide) can collect.
  • Page 8 SAFETY PRECAUTIONS Operation Do not tilt the mower when starting the engine. Do not put hands or feet near or under rotating parts. Never pick up or carry the mower while the engine is running. Never lift the rear deflector while the engine is running. Never touch the exhaust/exhaust guard or cooling fins when the engine is hot.
  • Page 9 Wear strong work gloves when removing and reassembling the cut- terblade. Always replace worn or faulty parts with genuine Hayter parts. Safety Symbols Safety Alert - Be aware to the Danger of severing toes or fin- Danger of being hit by thrown possibility of injury.
  • Page 10 ASSEMBLING THE MOWER Delivery Checklist Remove the mower from the packaging and check that the following items have been supplied correctly. If any items are missing contact, your local Hayter dealer. 1. Engine Handbook. 2. Warranty Reg. Card. 3. Grassbag To prevent accidents cut off the long ribbon attached to the grass- bag and discard.
  • Page 11 MOWER BEFORE STARTING Prevent Engine Damage To prevent engine damage the engine is shipped without oil or petrol. The engine must be filled with the correct grade of oil and petrol before starting the engine. Oil Type Always use high quality detergent oil classified SAE 30 Oil. Never use additives with this oil.
  • Page 12 OPERATING THE MOWER Controls Operate all control levers several times and ensure that the cables move freely. Check that the engine stop and (ground drive clutch levers - Autodrive model) return freely to their rest position when released. Starting - Step 1 Push the primer button 5 times allowing 2 seconds between each push.
  • Page 13 OPERATING MOWER Turning To make a wide turn steer the mower with the handlebar in the direc- tion required. To make a tight turn (release the ground drive clutch lever, Autodrive model), apply downward pressure on the handlebar to raise the front wheels just above ground level and steer in the required direction.
  • Page 14 OPERATING THE MOWER Before Mowing To prevent accidents thoroughly inspect the area and remove all objects which when contacted by the cutterblade could become dangerous projectiles. Inspect the area for hidden obstructions which when contacted by the cutterblade could risk health and safety.
  • Page 15 OPERATING THE MOWER Non-Grassed Areas When moving the mower across non-grassed areas, stop the cut- terblade and set the mower to the maximum height of cut to protect the cutting mechanism. 1.15...
  • Page 16 LAWN CARE CALENDAR To be used as a guide only. January There is very little work to do this month apart from brushing away leaves. Keep off the grass if frozen or waterlogged. February Rake the grass thoroughly. Spike the lawn to aerate and stimulate soil organisms and root growth and apply lawn sand if necessary.
  • Page 17 LAWN CARE CALENDAR August Keep mowing regularly and watering as necessary. Fill any cracks caused by drought with a mixture of sharp sand and soil. In dry weath- er conditions leave the grass longer to help retain ground moisture. September Raise the height of cut to allow the grass to thicken and protect the roots from the winter frost and snow.
  • Page 18 MAINTENANCE SCHEDULE Follow the hourly or calendar intervals, whichever occurs first. More frequent service will be required if working for prolonged periods under dusty, dry conditions, or when airborne debris is present or after extensive operation cutting tall, dry grass. First 5Hrs After the very first five hours change the engine oil Daily...
  • Page 19 MOWER MAINTENANCE To prevent accidents stop the engine, disconnect the spark plug lead before attempting to carry out maintenance procedures on the mower. Engine Finger Guard Carburettor Spark Plug / Lead Exhaust Guard Exhaust Oil filler Cap/ Dipstick Start Grip 1CG422V09A Fuel Cap Air cleaner.
  • Page 20 MAINTENANCE MOWER Oil Service Check the oil level daily before starting the engine and ensure that the correct oil level is maintained. Refer to-‘Before Starting the Mower’ for oil checking and filling instructions. Change the engine oil after the first 5 hours of operation and thereafter according to the ‘Maintenance Schedule’:- 1.
  • Page 21 MOWER MAINTENANCE Spark Plug Service Use only Briggs & Stratton spark tester (1) to check for a spark as shown in the diagram. Replace the spark plug every 100 hours or every season, whichever occurs first. A spark plug wrench is available from any authorised Briggs &...
  • Page 22 MOWER MAINTENANCE Deck Housing Remove grass debris from the top and underside of the deck housing immediately after use. Fertilisers and top dressings are particularly corrosive. Thoroughly clean the mower deck immediately after use on treat- ed grass and store well away from corrosive materials. Securing Nuts &...
  • Page 23 DO NOT rotate tools towards the cut- ting edges to avoid the risk of injury should the tool slip. ALWAYS use genuine Hayter replacement parts. The condition of the cutterblade and its mounting arrangement should be checked regularly for signs of wear or damage. Ensure that the cut- terblade is not bent or cracked.
  • Page 24 MOWER MAINTENANCE Cutterblade Assembly Push Models Assemble the cutterblade (2) with the turned up edges facing towards the engine. Secure the cutterblade using the friction washer (3) and new fixing bolt (4) and tighten to a torque of 54Nm. To prevent accidents never reuse the original fixing bolt. Cutterblade Assembly - Autodrive Model Assemble the cutterblade (2) with the turned up edges facing towards...
  • Page 25 MOWER MAINTENANCE Cutterblade Sharpening Continued. If the cutterblade is not balanced the heavy end will rotate downwards. Sharpen the heavy end until the cutterblade is correctly balanced. 1CG480V25B Storage To store the handlebar unscrew the 2 small securing knobs sufficient- ly to allow it to pivot forwards to rest against the mower.
  • Page 26 TROUBLE SHOOTING PROBLEM POSSIBLE FAULT REMEDY Engine will not turn over Incorrect oil level. Check oil level. Obstruction under deck. Remove obstruction. Engine smokes Excess oil level. Check oil level. Air cleaner cartridge oil Service air cleaner. soaked or blocked. Engine runs then stops Fuel starvation.
  • Page 27 TROUBLE SHOOTING PROBLEM POSSIBLE FAULT REMEDY Engine vibrates excessively Mounting bolts loose. Tighten bolts Cutterblade bolt loose. Tighten bolt Cutterblade out of balance. Balance cutterblade Bent crankshaft. Consult your dealer Uneven cut Undulating ground conditions Change direction of travel Cutterblade worn Sharpen the cutterblade Cutterblade out of balance Balance the cutterblade...
  • Page 28 DECLARATION OF CONFORMITY EC DECLARATION OF CONFORMITY HAYTER LIMITED, Spellbrook, Bishop’s Stortford, Herts CM23 4BU ENGLAND declare that the lawnmowers: Models: Jubilee 43 Jubilee 48 Jubilee 48 Machine Type No. CODE 422A CODE 423A CODE 424A Category: Push Push Auto Drive...
  • Page 29 Key - Woodruff. 1662 Screw - No8 x 1/2" Plastic Pan Hd 09729 Screw - Taptite UNC 3/8" x 11/4". 09349 Decal - Hayter & Royal Warrant. 300157 Decal - Height of Cut. 320006 Lever - Height of Cut. 422036...
  • Page 30 PARTS LIST NO. DESCRIPTION PART NO. ITEM NOTE 422A 423A 424A Cover - Lever Height of Cut. 422034 Quadrant - Height of Cut. 422035 Rivet - Dia. 5/32”. 09317 Rivet 09314 Stub Axle. 424004 Cover - Battery. 422026 Handlebar - Lower. 422001W Setscrew - M8 x 16.
  • Page 31 PARTS LIST NO. DESCRIPTION PART NO. ITEM NOTE 422A 423A 424A Bearing - Wheel 422070 Bolt - 3/8"UNF x 11/2". 09118 Washer - Friction. MU17X137 1 Blade - Adaptor. MU42734 Decal - Engine Stop. 331046 Washer M8 x 17 x 1.6 09475 Screw - Self Tap 09748...
  • Page 32 422A/423A LOWER MAINFRAME 1C422A06A 1.32...
  • Page 33 424A LOWER MAINFRAME 1C422A04A 1.33...
  • Page 34 422A/423A/424A UPPER MAINFRAME 1D42201E 1.34...
  • Page 35 CUSTOMER INFORMATION / NOTES Mower Serial No:................. Engine Model:........Type:........Code:........Notes: 1.35...
