PT4900-PTZ-V2
Professional 19" High-Bright PTZ-Compatible Teleprompter
OVERVIEW
Ikan's professional teleprompter series is designed for a quick and easy setup to work efficiently in studio or broadcast applications. The
included teleprompter hood fully encloses the PTZ camera allowing it to move freely inside the hood. The teleprompter features a 65/35
reflective glass that makes the reflection easier to see for the presenter. The lightweight aluminum teleprompter has multiple 1/4-20" and 3/8-
16" threads for mounting to a tripod or pedestal. The monitor includes HDMI, Composite, and VGA video inputs. Its high bright screen ensures
clear visibility in any lighting condition. An intuitive image flip button allows for easy adjustment of the display orientation. The monitor also
features a wide viewing angle.
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com
Quick Start Guide
Advertisement
Related Manuals for Ikan PT4900-PTZ-V2
Summary of Contents for Ikan PT4900-PTZ-V2
- Page 1 OVERVIEW Ikan’s professional teleprompter series is designed for a quick and easy setup to work efficiently in studio or broadcast applications. The included teleprompter hood fully encloses the PTZ camera allowing it to move freely inside the hood. The teleprompter features a 65/35 reflective glass that makes the reflection easier to see for the presenter.
- Page 2 Step 10 Locate the threaded clinch studs on the Hood Attachment Frame and fasten the included nuts to the clinch studs. Step 11 Fasten all six of the nuts to the threads on the hood frame to secure the hood to the teleprompter. www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
- Page 3 What’s Included Tall Riser DSLR/Mirrorless Riser Short Riser Monitor Sled Base Glass Frame Holder Bracket Glass w/ Rod Clamps Hood Attachment Frame Glass Holder Standard Hood Glass Frame Screws 15mm Rod Clamps 15mm Rods Large Riser Bracket www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
- Page 4 What’s Included PTZ Camera Riser PTZ Hood www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
- Page 5 Teleprompter Assembly Setup Step 1 Step 2 Place the Hood Attachment Frame over the Glass Holder. Then place the Secure the Glass Holder by fastening the knurled nuts to the screws as glass against the Glass Holder. Make sure the screws pass through the pictured below.
- Page 6 Step 5 After the monitor mounts are attached, adjust the 15mm rods to accommodate the monitor. Leave about 1 inch of room for the teleprompter bracket. Make sure the 15mm rods go through both set of monitor mounts. Please ensure that all screws are properly tightened after inserting the monitor. *SAFETY NOTE* Make sure to leave at least 2 inches of the rods inside the teleprompter base.
- Page 7 Step 8 Fold the flaps of the Hood alongside the edges of the Hood Attachment Frame. The flaps of the Hood are magnetic so they will automatically attach. Connect the bottom part of the hood by attaching the magnetic flap to glass frame holder. Connect the Velcro straps to the sides of the hood. Step 9: Connecting the PTZ Riser to PTZ Cameras Connect the PTZ Camera Riser to the PTZ camera plate first, by aligning the screw...
- Page 8 Step 10 Set the PTZ camera inside the hood by aligning the screws on the riser plate to the slot on the Base. Once the screws are aligned, Slide the riser plate into the Base. Step 11 To prevent light from leaking through the hood, seal both zippers down, attach the Velcro straps along the back and sides of the hood. Connect the cables to the back of your PTZ camera by putting them through the slot on the back of the PTZ Hood.
- Page 9 Step 12 Mount your own tripod plate to the bottom plate by aligning the 1/4-20 and/or 3/8-16 screws and fastening them to the Bottom Plate. It is recommended that you connect your tripod plate to front of the Bottom Plate so that you can balance your teleprompter easier. Once your tripod plate is connected to the Bottom Plate, mount the tripod plate to your tripod head.
- Page 10 Step 14 To secure your teleprompter system, insert the included headless screws into the threads behind and in front of the Base. Step 15 The headless screws should be inserted to the threads as pictured below. www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
- Page 11 Monitor Ports Monitor Menu Settings Video Config Contrast (White Level) Brightness (Black Level) Tint (Chroma Hue) Chroma (Chroma Saturation) Sharpness (Detail) RGB Setup – Manually configure RGB Return System Config Menu Duration – Set duration of how long menu stays on screen Video Ratio –...
- Page 12 Watch our VIDEO TUTORIAL on how to assemble PT4900-PTZ-V2 Teleprompters https://ikancorp.com/pt4900-PTZ-v2-tutorial-videos/ Specifications Optional Accessories PT4U-G Replacement Glass for PT4900-PTZ-V2 M19W-V2 19” Talent Monitor Add On Kit for PT4900-PTZ-V2 PT-PEDAL Teleprompter Foot Control Pedal PT-CONTROLLER Teleprompter Rotary Controller PT-CASE-4U Rolling Hard Case for PT4900-PTZ-V2 Teleprompter...
- Page 13 Foam Case To make your teleprompter more portable, we packed it in a reusable, high-quality foam. The shape and size of the foam was designed to fit into Ikan’s PT-CASE-4U. ** DO NOT THROW AWAY FOAM CASE ** www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
- Page 14 Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company. • Damage caused by natural disaster, abnormal voltage, and environmental factors, etc. ©2024 Ikan International. All rights reserved. www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
