PT4900-P2P
P2P Interview System with 2x 19" High Bright Teleprompter and HDMI Connection Cables
Features
Includes two teleprompters
Monitor that supports image flip (vertical and horizontal)
High-quality American-made 70/30 beam splitter glass
Monitor built in an aluminum chassis
Screen readable from up to 25'
Works with many different sized cameras
Easy balancing with adjustable base
Perfect size for portability and view-ability
Ships in reusable foam for easy transport
Monitor has a dedicated button that can be set to flip the image: horizontal, vertical, or both
PrompterPro software for MAC & PC is FREE with this teleprompter
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com
Quick Start Guide
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ikan PT4900-P2P
Summary of Contents for Ikan PT4900-P2P
- Page 1 Quick Start Guide PT4900-P2P P2P Interview System with 2x 19” High Bright Teleprompter and HDMI Connection Cables Features Includes two teleprompters Monitor that supports image flip (vertical and horizontal) High-quality American-made 70/30 beam splitter glass Monitor built in an aluminum chassis Screen readable from up to 25′...
- Page 2 What’s Included 2x Large Riser 2x DSLR/ 2x Medium Riser 2x Monitor Mirrorless Riser 2x Bottom Plate 2x Base 2x Glass Frame Holder 2x Glass Bracket w/ Rod Clamps 2x Hood Attachment Frame 2x Glass Holder 2x Hood 2x Glass Frame 4x 15mm Rods 2x Large Riser 2x 15mm Rod...
- Page 3 Teleprompter Assembly Setup Step 1 Step 2 Place the Hood Attachment Frame over the Glass Holder. Then place the Secure the Glass Holder by fastening the knurled nuts to the screws as glass against the Glass Holder. Make sure the screws pass through the pictured below.
- Page 4 Step 5 After the monitor mounts are attached, adjust the 15mm rods to accommodate the monitor. Leave about 1 inch of room for the teleprompter bracket. Make sure the 15mm rods go through both set of monitor mounts. Please ensure that all screws are properly tightened after inserting the monitor. *SAFETY NOTE* Make sure to leave at least 2 inches of the rods inside the teleprompter base.
- Page 5 Step 8 Fold the flaps of the Hood alongside the edges of the Hood Attachment Frame. The flaps of the Hood are magnetic so they will automatically attach. Step 9 To prevent light from leaking through the hood, seal both zippers down. www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
- Page 6 Step 10 Slide in the Riser plate of your choice by aligning the screws on the riser plate to the slot on the Base. Once the screws are aligned, Slide the riser plate into the Base. Step 11 Slide in the Riser plate of your choice by aligning the screws on the riser plate to the slot on the Base. Once the screws are aligned, Slide the riser plate into the Base.
- Page 7 Step 12 Mount your own tripod plate to the bottom plate by aligning the 1/4-20 and/or 3/8-16 screws and fastening them to the Bottom Plate. It is recommended that you connect your tripod plate to front of the Bottom Plate so that you can balance your teleprompter easier. Once your tripod plate is connected to the Bottom Plate, mount the tripod plate to your tripod head.
- Page 8 Step 15 To secure your teleprompter system, insert the included headless screws into the threads behind and in front of the Base. Step 16 The headless screws should be inserted to the threads as pictured below. www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
- Page 9 Foam Case To make your teleprompter more portable, we packed it in a reusable, high-quality foam. The shape and size of the foam was designed to fit into Ikan’s PT-CASE-V2. ** DO NOT THROW AWAY FOAM CASE ** www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
-
Page 10: Monitor Ports
Monitor Ports Monitor Menu Settings Video Config Contrast (White Level) Brightness (Black Level) Tint (Chroma Hue) Chroma (Chroma Saturation) Sharpness (Detail) RGB Setup – Manually configure RGB Return System Config Menu Duration – Set duration of how long menu stays on screen Video Ratio –... -
Page 11: Specifications
Watch our VIDEO TUTORIAL on how to assemble Ikan Professional Teleprompters https://youtube.com/playlist?list=PLcjaK5n9Y8ctrbYS3t2g4nyx2uADOXjuF Specifications PT4900-P2P Aspect Ratio Backlight Brightness 1000 nits Build Material Aluminum Chassis Diagonal 19” Input Signal Composite BNC, VGA, HDMI Input Voltage DC 12v / 4A Power Consumption Reading Range 25’... -
Page 12: Learn More
Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company. • Damage caused by natural disaster, abnormal voltage, and environmental factors, etc. ©2022 Ikan International. All rights reserved. www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
