Plantronics K100 - QUICK START GUIDES Quick Start Manual

NEED MORE HELP?
Project Specifications
24-hour support in USA:
Project: GSG, ACCORDION, PSD, K100, US
1-866-363-BLUE (2583)
Date: 07/07/10
Component: Accordion User Guide
1-year limited warranty details:
www.plantronics.com/warranty
File Name: 83988-51_K100GSG_070710.ai
Art Master Number: 83988-51
Part Number: 83987-51
Scale: 1:1 © 2010 Plantronics, Inc. All Rights Reserved.
Bluetooth is a registered trademark of Bluetooth
Resolution: 300dpi SIG, Inc. and any use by Plantronics is under license.
All other trademarks are the property of their
Links: N/A
respective owners.
83987-51 (07.10) AM 83988-51
Fonts: Gesta Light, Regular, Medium, Bold
Software: CS3
Artmaster: 83988-51
Printing Method: Offset Lithography
Inks:
Process Black
PMS 294
PMS 151
Finishes: OVERALL MATTE VARNISH
Notes:
Designer: Su Gatch/Blanca Castaneda
MULTI-FUNCTION BUTTON
Company: Su Gatch Lettering & Design
• Power on or off (3- to 4-second press)
E-mail: su@sugraphics.com
• Take a call or end it (1 tap)
Phone: 831-464-7224
• Redial (2 taps)
• Transfer audio to or from phone
during call (3-second press)
• Reject a call (press and hold until you
hear tone)
• Initiate phone's voice-dialing (2-second
press until second tone is heard)
• Activate manual pairing (with power off,
press and hold until LED flashes red/blue)
FM BUTTON
• FM transmit on or off (1 tap)
• Find FM channel (press and hold until
station option is announced)
HEAR CALLS THROUGH YOUR CAR STEREO
You can listen to calls through your car 1. READY
stereo speakers by transferring the audio
Ensure that your phone and speakerphone
from the speakerphone to one of five FM
are powered on and connected.
channel options.
If your phone is A2DP-enabled you can also
hear streaming audio like GPS instructions
and music through your car speakers.
We recommend that you transfer audio to
an FM channel before you start driving, and
that you make a routinely clear channel a
preset on your stereo.
Z109
N10687 Suggested placement
TAKE A GOOD LOOK
Microphones LED
• Charging (solid red)
• Powering on or off (2 blue flashes)
• FM transmission (2 purple flashes)
• Missed call (1 purple flash)
• Pairing mode (red/blue flashes)
VOLUME WHEEL
• Increase volume (rotate clockwise)
• Decrease volume (rotate counterclockwise)
MUTE BUTTON
• Mute on or off (1-second tap)
• Night mode: LED on or off (2-second press
until tone is heard)
MICRO USB CHARGING PORT
• With micro USB or car charger:
2.5 hours (100% charge)
• Best performance when fully charged
2. SET 3. CONNECT Keep Your Eyes on the Road:
Press the FM button to enter FM transmit Manually set your radio to the announced FM The controls are easy to find with your
mode. The FM transmit channel will be channel. You are now ready to transmit calls fingertips without looking for them.
announced. and streaming audio like GPS directions from
Before driving, reach up and familiarize
your phone to your car stereo.
yourself with the controls so you can keep
If a radio station suddenly takes over the your eyes on the road when a call comes in.
FM channel, tap the FM button to quickly
The notched Volume wheel is easy to find.
redirect the audio back through the
speakerphone.
The Multi-function button is inside the wheel.
To find another FM channel, while FM is
The Mute button has a raised notch.
turned on, press and hold the FM button
until another channel option is announced,
then tune your radio to the new channel.
CONNECT TO YOUR PHONE
"Pairing" is the process that connects the 1. READY 2. SET
speakerphone to your phone. You can pair
Activate the Bluetooth feature on your First Time:
more phones but can have only one active
phone, then use the phone' s settings to With speakerphone turned off, activate
connection at a time.
add/search/discover new Bluetooth devices. Bluetooth pairing mode by pressing and
holding the Multi-function button to turn on
iPhone®: Settings > General > Bluetooth > On
speakerphone. The LED flashes red/blue to
(starts the search for devices)
indicate pairing mode.
PLT_K100
BlackBerry® smartphone: Settings/options >
Bluetooth: On > Search for devices
VIDEO TUTORIAL FOR USA:
www.plantronics.com/pairing
READY SET CONNECT
TIPS
Sound Your Best:
Clip the speakerphone to your visor where
the two microphones, located on the top
of the unit, can be closest to your face so GET
you can speak in a normal tone of voice and
be heard. STARTED
Avoid a Dead Battery:
Remember to power off the speakerphone
when you exit your car. If you forget, the
K100 ™ Bluetooth®
speakerphone will automatically turn off
after 90 minutes of not having an active In-car Speakerphone
connection.
TIPS
3. CONNECT Listen to the Voice:
You will hear various voice status alerts
Select "PLT_K100" from the list of Bluetooth
when you power on/off, search for FM
devices shown on your phone.
channels or when battery level is low.
If the phone asks for a passcode, enter four
Learn to Share:
zeros (0000). You may see **** on screen.
When powering on, the speakerphone
searches for the last connected phone.
Some phones also ask to confirm the
connection after pairing. If the last connected phone is not within
range, or the Bluetooth feature is turned off
The speakerphone LED will stop flashing
on the phone, then another phone within
red/blue once your phone is successfully
range that has been previously paired with
paired/connected.
the speakerphone can be connected by
tapping the Multi-function button.
