Summary of Contents for Mirae ST E-Duo13 UV
- Page 1 www.miraest.co.kr E-Duo Series User Manual...
- Page 2 E-Duo Series User Manual …E-Duo Series User Manual...
- Page 3 - USB Data output MAINTENANCE Filter’s lifetime Installation Filters - Installation of MA Pack, MB Pack, PI Pack - Installation of RO Membrane - Installation of POU Filters - Installation of UV Lamp TROUBLE SHOOTING ORDER INFORMATION mirae ST … 03...
- Page 4 INTRODUCTION Configuration E-Duo Series consists of Main System,M-POUs(dispensers) and ResTank ※ It can be vary depending on models. M-POU Ⅰ M-POU Ⅱ (TypeⅠ) (TypeⅡ, only for E-Duo12 series) Dispensing button POU Filter Model : E-Duo12 VFT Main System ResTank …E-Duo Series User Manual...
- Page 5 ※ E-Duo Series provides below POU Filters. Pyrogen-free water for removing of pyrogens(endotoxin), Rnase, Duo-UF Filter 27304 Dnases. Duo-Metal Filter 27305 Removes specific heavy metals and micro-particles. Final filterⅠ 20304 Filters for bacteria-free and particulate-free water Final filterⅡ(M-POUⅡ) 27206 mirae ST … 05...
- Page 6 INTRODUCTION Specifications E-Duo13 UV E-Duo13 VF E-Duo12 VF E-Duo12 VFT Type Ⅰ 2.0L/min 2.0L/min 2.0L/min 2.0L/min Flow Rate Type Ⅱ 2.0L/min 2.0L/min (up to) Type Ⅲ 22L/hr 22L/hr 22L/hr 22L/hr Type Ⅰ 18.2㏁.cm 18.2㏁.cm 18.2㏁.cm 18.2㏁.cm Resistivity Type Ⅱ 5-15㏁.cm 5-15㏁.cm...
- Page 7 TypeⅢ water conductivity Hardness <350 ppm as CaCO Free Chlorine <0.05 ppm Cl Silica <30 ppm SiO Carbon Dioxide(CO <30 ppm Fouling Index <10 <2 ppm Temperature 4 - 40 °C Surrounding Clean Laboratory environment mirae ST … 07...
- Page 8 INSTALLATION Precautions before installation ▶ Power Supply •Plug in the power cord correctly. •Check if the power supply is correct. •Careless opening or disconnection of the part connected to the main board may cause program errors or malfunctions. ▶ Location •The device should be placed on a table in the laboratory or on a well-leveled surface.
- Page 9 Duo-PI Pack Final filter Ⅰ Final filterⅡ(M-POU Ⅱ) Duo-UF Filter M-POU Ⅰ M-POU Ⅱ M-POU Ⅲ Option Option Option Option ResTank(35L, 75L) 35L or 75L with level sensor, tank cork Installation Kit Power cable, Tubing, User manual mirae ST … 09...
- Page 10 INSTALLATION Installing the Main system •Place the device where it will be installed and then install it in the following order •The installation location must be a place where water intake and drainage are possible. •For smooth supply of entering water, this system should be located next to or below a water tank.
- Page 11 INSTALLATION M-POU Cable USB Port (Conneting to the main system) ResTank Level sensor (Connecting to the main system) mirae ST … 11...
- Page 12 INSTALLATION Tubing Connection(E-Duo 13 UV,VF) M-POUⅠ FEED, DRAIN Main System Main System M-POU Ⅰ(IN) M-POU Ⅰ(IN) M-POU Ⅱ(OUT) M-POU Ⅱ(OUT) M-POUⅡ,Ⅲ(IN) M-POUⅡ,Ⅲ(IN) M-POUⅡ, Ⅲ(OUT) M-POUⅡ, Ⅲ(OUT) DRAIN DRAIN FEED FEED UP (IN) UP (IN) RO (PRODUCT) RO (PRODUCT) ResTank M-POUⅢ Main System Main System M-POU Ⅰ(IN)
- Page 13 RO (PRODUCT) RO (PRODUCT) ResTank M-POUⅡ Main System Main System M-POU Ⅰ(IN) M-POU Ⅰ(IN) M-POU Ⅱ(OUT) M-POU Ⅱ(OUT) M-POUⅡ,Ⅲ(IN) M-POUⅡ,Ⅲ(IN) M-POUⅡ, Ⅲ(OUT) M-POUⅡ, Ⅲ(OUT) DRAIN DRAIN FEED FEED UP (IN) UP (IN) RO (PRODUCT) RO (PRODUCT) DRAIN mirae ST … 13...
- Page 14 SOFTWARE 1. Main Screen (Standby mode) 2023-01-04 PM03:00 Ⓡ Quality Setting Filter Ⓓ Calibration USB Print Administrator 2. Icons Press the button to produce Type3(RO) Press the button to produce Type1(UP) water. and Type2(Post) water. Move the cursor Save your changes Go to the next page …E-Duo Series User Manual...
- Page 15 ▶ Clean the RO membrane. (5-minute activation every 60 minutes) ▶ While the system is in standby mode, when the water tank is under 80% full, the system will restart. ▶ You can turn on/off the touch sound. mirae ST … 15...
- Page 16 SOFTWARE ③ Filter You can check the replacement cycle and number of days of use of each filter. After replacing the filter, press the Zero button to reset the number of days of use.( For items without a Zero button, the number of days of use is automatically reset after the replacement of the filter.) Final Pack...
- Page 17 In administrator, you can change the date and time and system settings. The password is “0000”. 2023 - 00 - 00 PM 00:00 2023 - 00 - 00 PM 00:00 2023-01-01 1 2 : 0 0 : 0 0 mirae ST … 17...
- Page 18 OPERATION ① Initial screen 1. Displayed MIRAE ST and model. E-DUO 12 VF 2. When the device is operated for the first time, the screen to set the date and time will appear. Touch the desired location to make the number pad shown on the right display. Press the 1/E button to change to the English keyboard.
- Page 19 USB drive. After connecting to the USB port of USB Print ? M-POUⅠ,Ⅱ, and Ⅲ, press USB PRINT on the menu screen and touch the YES button on the next screen to save to the USB drive. mirae ST … 19...
- Page 20 MAINTENANCE ① Filter lifetime Duo-MA Pack 120 days Duo-RO Membrane(2ea) 365 days Duo-MB Pack 180 days Duo-PI Pack 180 days Duo-UV Lamp 365 days Final filterⅠ 180 days Final filterⅡ(M-POUⅡ) 180 days Duo-UF Filter 180 days ※ The above replacement cycle may vary depending on the water quality and used amount. ②...
- Page 21 *If you turn it too hard, the dispenser part may be damaged. 4. After replacement, the number of days of use is automatically reset. * When the tubing is connected in the wrong direction, the water does not come out. mirae ST … 21...
- Page 22 MAINTENANCE 4. Installation of UV Lamp Connector ▶ Lamp head ▶ Lamp Housing ▶ UV Lamp 1. Open the hand screws of the left door of the system. 2. Remove the lamp head from the cradle and separate the connector from the lamp. 3.
- Page 23 Duo-PI Pack 37101 27303 M-POU I 37301 Duo-UV Lamp 27301 M-POU II Final filter Ⅰ 37201 20304 M-POU III 37101 Final filter Ⅱ 27206 ResTank 35L Duo-UF Filter 30735 27304 ResTank 75L 30775 Duo-Metal Filter 27305 mirae ST … 23...
- Page 24 Mirae ST Co.,Ltd Office : #505,136,LS-ro,Dongan-gu, Anyang-si, Gyeonggi-do, Korea 14118 Tel : 031.8091.0132 Fax : 031.8091.0141 Http : www.miraest.co.kr E-Mail : puris@mrst.kr We are trying to ensure the full satisfaction of our customers. We will do my best to make it convenient to use the device.
