Mirae ST Puris Evo-CB Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Puris,
Evo-CB Water System
Model : Evo-CB Series
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Puris Evo-CB Series and is the answer not in the manual?

Questions and answers

Related Manuals for Mirae ST Puris Evo-CB Series

Summary of Contents for Mirae ST Puris Evo-CB Series

  • Page 1 Puris, Evo-CB Water System Model : Evo-CB Series User Manual...
  • Page 2 Foreword This manual is provided to serve as the installation, operation and maintenance guide for the Evo-Series LAB Water system models. The manual should be read before attempting any cycle of installation, operation and maintenance. If the instructions in this manual are not followed, the performance of this product or the safety of the user may be compromised.
  • Page 3 Follow the instructions in this manual for correct usage and filter replacement. Failure to do so may result to the malfunction and breakdown of Evo-CB Water System. If any encountered problem persists, contact the Mirae ST customer center for professional assistance.

  • Page 4: Table Of Contents

    Evo-CB Series Contents Section 1. User Manual Outline 1-1. General outline 1-2. Customer Center Section 2. Product Details 2-1. Merits of Evo-CB System 2-2. Water Quality 2-3. Dimensions and Weight 2-4. Installation Environment Section 3. System Installation 3-1. Before Installation 3-2.

  • Page 5: Section 1. User Manual Outline

    Section 1. User Manual Outline 1-1. General Outline This manual guides you through the installation, operation, and maintenance of Mirae ST Evo-CB System. You will find that using Evo-CB system is very simple, if you take the time to read this manual beforehand.

  • Page 6: Section 2. Product Details

    Evo-CB Series Section 2. Product Details 2-1. Merits of Evo-CB System • One-touch tubing lets even the first-time users of the Evo-CB Series to install Evo-CB System easily. • Installation space is minimized by the S-Dispenser, the first one of its kind in Korea. Evo-CB System can be used safely in laboratories.

  • Page 7: Dimensions And Weight

    2-3. Dimensions and Weight • Dimensions - Main System : W350 × D430 × H520(mm) - S Dispenser : W235 × D180 × H635(mm) • Weight - Main System : 20~22.5kg - S Dispenser : 5.0kg 2-4. Installation Environment 2-4.1 Water Supply •...

  • Page 8: Section 3. System Installation

    Evo-CB Series Section 3. System Installation 3-1. Before Installation 3-1.1 Power Supply • Plug in the power cord correctly. • Make sure that the correct level of power is supplied. • Do not open or disassemble the main PCB (Printed Circuit Board). •...

  • Page 9: Unpacking

    3-2. Unpacking • Remove Evo-CB System from its packing and check if all components are there. • Place Evo-CB System on a flat horizontal surface in a safe environment. 3-2.1 Components Puris, Evo-CB Water System Unit : 1SET • Built-in filter - RO Membrane : 1EA (For Dio10, UV, VF, VFT) : 2EA (For Dio 20) - UV Lamp : 1EA (For Dio UV, VF, VFT)
  • Page 10 Evo-CB Series - Connect the 5/16” and 4/1” tubing to the area from which the plug was removed. • Inlet (UP) - Connect the 5/16” tube to the Pure water tank • Feed - Connect the 1/4” tube to the influx. S-DISPENSER S-DISPENSER •...

  • Page 11: S-Dispenser Connection

    3-4. S-Dispenser Connection Take the S-Dispenser out of its box and connect it to the main unit. System settings made on the main unit or S-Dispenser are applied to both units. USB Port Tubing S-Dispenser S-Dispenser 3-5. Pure Water Storage Tank ④...
  • Page 12 Evo-CB Series 3-6. Connecting the System with the Printer • Connect the power cord to the printer and connect the printer to the main unit. Power Cord Cable...

  • Page 13: Section 4. System Operation

    Section 4. System Operation 4-1. Keypad ① LCD monitor ② Quick - Use this button to check the remaining pack level when the filter icon is displayed on the screen. ③ Menu - Use this button to automatically save changes and return to Menu. ④...

  • Page 14: Date And Time

    Evo-CB Series 4-2. Date and Time • The time setting screen is displayed when Evo-CB System is first started. Press △ , ▽ to set the time. • Press Menu to save the changes made and move to Menu. (Before Setting) (After Setting) 4-3.
  • Page 15 4-4.2 Setting • In Settings, UP Auto Standby, UP Circulation, UF Cleaning, Pressure, Temperature, Key Tone, and Password can be set. - UP Auto Standby Evo-UP System is put on standby from circulation mode if not used for longer than a set time (default: 5 min) to prevent idle pump rotation.
  • Page 16 Evo-CB Series 4-5. Pure and Ultra pure water screen • RO Button activates pure water and UP button activates • Quality and temperature are displayed. • The normal range of pure water is 1~25 ㎲ /cm and that of ultra pure water is 18.2 ㏁ -cm. •...

  • Page 17: Quantity Control

    4-6. Quantity Control • Ultrapure water can be collected in units of 100 ㎖ . • Press Run. • Press Vol to open Dispenser Settings. • Press ◀▶ to set the desired quantity. Caution : Pump damage can occur if the maximum volume of a connected pure water tank is exceeded.

  • Page 18: Filter Replace Alarm

    Evo-CB Series 4-8. Filter Replace Alarm • A filter change icon is displayed seven days ahead of the required filter change. Press Quick to view the remaining life span of all filters. 4-9. USB Auto Save • You can save water quality records automatically to a USB memory device. - Insert a USB memory device and press the Menu key in USB Print.

  • Page 19: Section 5. System Maintenance

    Section 5. System Maintenance 5-1. Replacing of the Dico-PC Pack, Dio Pack Ⅲ Open the front door and connect the Quick Connector. Before connecting the pack to the main unit, press down on the top part of the Quick Connector. Caution : If left protruding, the top part of the Quick Connector can damage the O-ring in the main unit.

  • Page 20: Replacing Of The Uv Lamp

    Evo-CB Series 5-3. Replacing of the UV Lamp (For Dio UV, VF, VFT) • Remove the cover from the left side of the system with a screwdriver. • Remove the tubing from the top and bottom. • Removed the clip-fixed UV lamp housing and turn its top counterclockwise to remove the lamp socket from the UV lamp.

  • Page 21: System Resetting After Filter Replacing

    5-5. System Resetting after filter replacing • Select Filter on Menu. • Press ◀▶ to select the replaced filter. • Press △▽ to change USE Time to “1 day” and press Menu to return to Menu. * Filter type can vary by model. Sample model in the photo : Evo-CB DioVFT Caution : Changing USE TIME greatly affects water quality and optimum water quality guaranteed if extended excessively.

  • Page 22: Maintenance

    Evo-CB Series 5-7. Maintenance • Fuse replacing - Switch off the power and remove the power cord. - Assess the power cord unit at the side of the main unit. - Pull forward the part in the middle marked “Fuse” using a screwdriver. - Remove the fuse box with the hand.

  • Page 23: Section 6. System Alerts

    Refer to 5-3. Replace the UF Filter Refer to 5-4. Replace the Final Filter Refer to 5-4. Check the inflowing water temperature. Check the inflowing water temperature. Check the inflowing water pressure. Contact the Mirae ST customer center if problems persist.
  • Page 24 Evo-CB Series...
  • Page 26 We strive to guarantee our customers the complete satisfaction. MIRAE ST CO. LTD not only makes high quality products but we do our best to provide the best after service to our customers. We are always glad to receive feedbacks or any opinions from our customers.

This manual is also suitable for:

Puris evo-cb dio 10Puris evo-cb dio 20Puris evo-cb dio uvPuris evo-cb dio vfPuris evo-cb dio vft
