- Page 1 Puris, Evo-RO Water System Model : Evo-RO Series User Manual...
- Page 2 Foreword This manual is provided to serve as the installation, operation and maintenance guide for the Evo-Series LAB Water system models. The manual should be read before attempting any cycle of installation, operation and maintenance. If the instructions in this manual are not followed, the performance of this product or the safety of the user may be compromised.
- Page 3 Follow the instructions in this manual for correct usage and filter replacement. Failure to do so may result to the malfunction and breakdown of Evo-RO Water System. If any encountered problem persists, contact the Mirae ST customer center for professional assistance.
-
Page 4: Table Of Contents
Evo-RO Series Contents Section 1. User Manual Outline 1-1. General outline 1-2. Customer Center Section 2. Product Details 2-1. Merits of Evo-RO System 2-2. Water Quality 2-3. Dimensions and Weight 2-4. Installation Environment Section 3. System Installation 3-1. Before Installation 3-2. -
Page 5: Section 1. User Manual Outline
Section 1. User Manual Outline 1-1. General Outline This manual guides you through the installation, operation, and maintenance of Mirae ST Evo-RO System. You will find that using Evo-RO system is very simple, if you take the time to read this manual beforehand. -
Page 6: Section 2. Product Details
Evo-RO Series Section 2. Product Details 2-1. Merits of Evo-RO System • One-touch tubing lets even the first-time users of the Evo-RO Series to install Evo-RO System easily. • Evo-RO System’s quiet pump is perfect for all environments. • The 4.3” wide graphic display allows the checking of pure water quality, filter condition, storage tank level, and many others. -
Page 7: Dimensions And Weight
2-3. Dimensions and Weight • Dimensions - Main System : W350 × D430 × H520 (mm) • Weight - Main System : 18~19kg 2-4. Installation Environment 2-4.1 Water Supply - Reverse osmosis water : <250 ㎲ /cm - Temperature : 5-40 ℃ - Pressure : 0.07-6bar - Chlorine : ≤3ppm - Fouling Index(SDI) : ≤12... -
Page 8: Section 3. System Installation
Evo-RO Series Section 3. System Installation 3-1. Before Installation 3-1.1 Power Supply • Plug in the power cord correctly. • Make sure that the correct level of power is supplied. • Do not open or disassemble the main PCB (Printed Circuit Board). •... -
Page 9: Unpacking
3-2. Unpacking • Remove Evo-RO System from its packing and check if all components are there. • Place Evo-RO System on a flat horizontal surface in a safe environment. 3-2.1 Components Puris, Evo-RO Water System Unit : 1SET • Built-in filter - RO Membrane : 1EA (For RO Dico10, ROP Dico10) 2EA (For RO Dico20, ROP Dico20) 3EA (For RO Dico50) - Page 10 Evo-RO Series - Connect the 5/16” and 1/4” tubing to the area from which the plug was removed. DRAIN PRODUCT FEED • Feed - Connect the 1/4” tube to the influx. • Product - Connect the 1/4” tube to the tank. •...
-
Page 11: Pure Water Storage Tank
3-4. Pure Water Storage Tank ④ ⑤ ⑥ ③ ② ① Level sensor connection of the system ① Drain – Locate the 3/8” tube to the drainage. ② UP Inlet – Connect the 5/16” tube to the main unit (when UP System or CB System is in use). ③... -
Page 12: Section 4. System Operation
Evo-RO Series Section 4. System Operation 4-1. Keypad ① LCD monitor ② Quick - Use this button to check the remaining pack level when the filter icon is displayed on the screen. ③ Menu - Use this button to automatically save changes and return to Menu. ④... -
Page 13: Date And Time
4-2. Date and Time • The time setting screen is displayed when Evo-RO System is first started. Press △ , ▽ to set the time. • Press Menu to save the changes made and move to Menu. (Before Setting) (After Setting) 4-3. -
Page 14: Menu Setting
Evo-RO Series 4-4. Menu Setting ※ This item is the factory default setting, so you do not need to reset. 4-4.1 Quality • The unit of Pure water can be set in quality. (The above example is based on the ROP model. For the case of the RO model, the RO POST QUALITY item does not appear.) The unit of conductivity is ㎲... - Page 15 4-4.2 Setting • In the Setting item, it is possible to configure Standby Wash, Run Wash, Water Input Temperature, Level Sensor, Key Tone, and Password. - Standby Wash Automatic washing is performed for three minutes once every 120 minutes. - Run Wash RO membrane is automatically washed for three minutes once every 60 minutes.
-
Page 16: Pure Water Production Window
Evo-RO Series 4-5. Pure water (RO) production window 00:06:34 • Activate Pure warer by pressing the RUN button. • Quality and temperature of Pure water are displayed. • The normal range of pure water is 1-25 ㎲ /cm. • The specific resistance of the post is displayed, and its normal range is 5-15 ㏁ .cm (applicable only to the ROP model) 4-6. -
Page 17: Usb Auto Save
4-8. USB Auto Save • You can save water quality records automatically to a USB memory device. - Insert a USB memory device and press the Menu key in USB Print. Remove the USB memory device and insert it again at a desired time and press the Menu key in USB Print to save. - Water quality records are saved in Excel format on the hour from the start and the end of this function. -
Page 18: Section 5. System Maintenance
Evo-RO Series Section 5. System Maintenance 5-1. Replacing of the Dico-PC Pack, PO Pack Open the front door and connect the Quick Connector. Before connecting the pack to the main unit, press down on the top part of the Quick Connector. Caution : If left protruding, the top part of the Quick Connector can damage the O-ring in the main unit. -
Page 19: System Resetting After Filter Replacing
5-3. System Resetting after filter replacing • Select Filter on Menu. • Press ◀▶ to select the replaced filter. • Press △▽ to change USE Time to “1 day” and press Menu to return to Menu. * Filter type can vary by model. Sample model in the photo : Evo-ROP Dico10 Caution : Changing USE TIME greatly affects water quality and optimum water quality guaranteed if extended excessively. -
Page 20: Maintenance
Evo-RO Series 5-5. Maintenance • Fuse replacing - Switch off the power and remove the power cord. - Assess the power cord unit at the side of the main unit. - Pull forward the part in the middle marked “Fuse” using a screwdriver. - Remove the fuse box with the hand. -
Page 21: Section 6. System Alerts
Replace the PC Pack Refer to 5-1. Replace the RO Membrane Refer to 5-2. Replace the PO Pack (ROP model) Refer to 5-1. Check the inflowing water pressure. Check the inflowing water temperature. Contact the Mirae ST customer center if problems persist. - Page 22 Evo-RO Series...
- Page 24 We strive to guarantee our customers the complete satisfaction. MIRAE ST CO. LTD not only makes high quality products but we do our best to provide the best after service to our customers. We are always glad to receive feedbacks or any opinions from our customers.
