Summary of Contents for U-Prox WDC
- Page 1 U-Prox WDC Wireless magnetic contact sensor...
- Page 2 Turning on and off ..................................... 8 Settings ..........................................9 Adding a device to the security system (registration) ..................9 Basic settings of the U-Prox WDC ............................. 10 Testing the connection ................................17 Remove a device ....................................21 Wireless device states ................................22 Service ..........................................
- Page 3 /web-security.u-prox.systems/ Description and principle of operation U-Prox WDC is a magnetic contact point radio channel sensor designed to monitor the state of structural elements for opening or displacement to detect an attempted intrusion into the premises and to issue an alarm notification to the U-Prox alarm...
- Page 4 The sensor operates only with the U-Prox security system; it cannot be connected to third-party systems. It has a sealed case and is used to protect doors and windows. The device has contacts for connecting an arming LED and an external sensor, such as a reed switch.
- Page 5 Features Sensor (reed switch) Threshold of operation is 7-15 mm, not less than 1 000 000 actuations Power supply 3V, CR123A lithium battery included Service life of a battery up to 5 years Radio communication ISM wireless interface with multiple channels Radio communication ITU region 1 (EU, UA): 868.0...868.6 MHz, parameters...
- Page 6 Installation Selecting the installation location Choose the location of the U-Prox WDC carefully. The device should not be placed on top of other devices: 1. Outdoors or in rooms with unacceptable humidity and temperature In places with a high level of radio interference 3.
- Page 7 WARNING! WHEN THE DEVICE IS INSTALLED CORRECTLY, THE TAMPER WILL BE CLAMPED (LOCKED). Connecting an external sensor It is used in cases where the U-Prox WDC cannot be installed, where flush mounting is required, or to process signals from another external sensor or device. Connecting an external LED...
- Page 8 The LED turns on for up to 15 seconds after the sensor is violated and restored during the exit delay countdown. Turning on and off Move the switch (11) to the ON position - the indicator light will be on. If the device has already been registered in the security system, it switches to the next mode.
- Page 9 Launch the U-Prox Installer application or open the web portal in a browser and log in Select the U-Prox MPX to which you want to add the wireless sensor from the list of devices Press the button () ("Add radio device"), the security center will enter the mode of registering sensors, keypads, etc.
- Page 10 WARNING. THE DEVICE WILL BE ADDED TO THE FIRST FREE ZONE WITH THE LOWEST NUMBER The app will open the settings of the wireless sensor Configure your device Basic settings of the U-Prox WDC Select the device you want to configure from the device list...
- Page 11 "Name" - the name of the device 2. «"Group - selects the security group to which the device belongs. A security group is a logical set of zones of a protected premises (for example, a room, apartment, garage, floor of a building, etc.), a minimum security unit. A security group allows you to manage all zones simultaneously.
- Page 12 "Temperature limits notification" - when the device exceeds the specified temperature limits, it will generate the corresponding events - "Cooling" and "Overheating". Can be used in scenarios "Setting" (zone type) - operating modes of the device depending on the type of a.
- Page 13 • If the system is armed, the entry delay starts when the sensor is triggered. If the system is not disarmed during the delay, the system switches to the Alarm state and sends an alarm notification • When arming, the exit delay will start, and the system will be armed. a.
- Page 14 "Delay to exit (only for the Delayed arming type). The time to leave the premises after arming or disarming. "Delay for entry in Stay Armed mode" (only for the Delayed arming type). Time for disarming (disarming) the security system after entering the premises (arming in Stay, Night mode) "Delay to exit in Stay Armed mode"...
- Page 15 10. "Arming with a broken sensor" - forced arming of a sensor, even if it is broken a. "Forced arming after exit delay" - if the sensor does not recover after the exit delay countdown, the system switches to the Alarm state and transmits an alarm notification b.
- Page 16 12. "LED output settings" - setting up the universal input/output • Pass bypass - the sensor is skipped (bypassed) while the universal input loop is closed • Skip for 1, 3, or 5 minutes - after the universal input loop is broken and restored, the sensor will be skipped for a specified time •...
- Page 17 Testing the connection WARNING. BEFORE PERFORMING THIS STEP, THE DEVICE MUST BE REGISTERED IN THE UPROX SECURITY SYSTEM. Launch the U-Prox Installer application or log in to the U-Prox Installer WEB portal Select a security center from the list...
- Page 18 Select a device from the list Start the test mode and select the test mode - Normal or Grade II Conventional signal testing...
- Page 19 ATTENTION!!! TESTING IS PERFORMED AT AN AVERAGE POWER LEVEL OF RADIO TRANSMITTERS. Signal testing in accordance with Grade II ATTENTION!!! TESTING IS PERFORMED AT REDUCED POWER OF RADIO TRANSMITTERS, IN ACCORDANCE WITH EN 50131-1 To start testing the signal strength of the device, wait for the next communication session with the device, or trigger it or open the case.
- Page 20 Based on the data in the U-Prox Installer or U-Prox Installer WEB mobile application, select a location with an optimal signal strength of at least -95 dBm. You can also use the light indication of the device -LED flashes green (up to -87 dBm) -...
- Page 21 Remove a device Launch the U-Prox Installer application or log in to the U-Prox Installer WEB portal Select a security center from the list Select a device from the list Click the "Delete" button and confirm the deletion...
- Page 22 • ETSI EN 300 220-2 v3.2.1 • EN 50131-1 Grade 2, Class II: EN 50131-1:2006/A1:2009/A2:2017/A3:2020 EN 50131-2-6:2008 EN 50131-5-3:2017 EN 50131-6:2017 Warranty obligations The warranty period for the U-Prox device (excluding batteries) is 2 years from the date of sale.
- Page 23 If the device is not functioning properly, first contact support@uprox.systems, perhaps this issue will be resolved remotely. The scope of delivery 1. U-Prox WDC; 2. Magnet; 3. CR123A battery (pre-installed); 4. Installation kit; 5. Quick start guide...
